Summary of Contents for AIREDALE Ecotel TCU5
- Page 1 I N S T A L L A T I O N & M A I N T E N A N C E M A N U A L Ecotel Outdoor Upflow Telecom Unit TCU5 - TCU19D 5KW - 19KW...
- Page 2 Any spare part supplied by Airedale under warranty shall be warranted for the unexpired period of the warranty or 3 months from delivery, whichever period is the longer.
-
Page 3: Table Of Contents
The equipment has been designed and manufactured to meet international safety standards but, like any mechanical/electrical equipment, care must be taken if you are to obtain the best results. Service and maintenance of Airedale equipment should only be carried out CAUTION by Technically trained competent personnel. -
Page 4: Warranty
Replaced faulty parts have been returned to Airedale within 21days of replacement for evaluation. Any spare part supplied by Airedale under the warranty shall be warranted for the unexpired period of the warranty or 3 months from delivery whichever period is the longer, with the exception of compressors on which a further 12 months warranty is granted. -
Page 5: General Description
The unit is despatched having been pre-commissioned ready for offering up to the appropriate services. CE DIRECTIVE Airedale certify that the equipment detailed in this manual conforms with the following EC Directives: Electromagnetic Compatibility Directive (EMC) 2004/108/EC... -
Page 6: Installation Data
ECOTEL™ OUTDOOR Upflow Telecom Unit Installation Data DIMENSIONS (MM) WEIGHTS (KG) Operating TCU5 TCU8 TCU11 TCU15 TCU15D TCU19D External Mounting Brackets with Fixing Slots FRONT REAR DISCHARGE AIR APERTURE Control Panel Access (Top Hinged) Cable Entry 2 x 25mm Compressor Access UNIT RETURN... - Page 7 Remove packing and check that the unit is exactly as ordered. Any discrepancy to order, or transit damage, should be reported to Airedale immediately. Airedale recommends that whenever possible, the packaging is left covering the unit, to protect it from damage and general site debris. ...
- Page 8 Ensure there are no protrusions to the grille openings, which may foul the damper movement. *Airedale recommends the use of Dow Corning 794 or equivalent. ELECTRICAL All mains and interconnecting wiring should be carried out to National and Local codes.
-
Page 9: General Specification
Upflow Telecom Unit ECOTEL™ OUTDOOR General Specification ELECTRICAL DATA Electrical Supply Data Nominal Run Amps 11.4 10.9 18.7 Maximum Start Amps 27.8 49.8 56.0 81.1 56.1 87.8 Recommended Mains Fuse Max Mains Incoming Cable Size (1) mm² 1.50 1.50 1.50 2.50 1.50 Mains Supply... - Page 10 ECOTEL™ OUTDOOR Upflow Telecom Unit Electrical Data INTERCONNECTING WIRING Mains Incoming Supply 400V/3PH+N/50Hz ± 10% or 230V/3PH+N/50Hz Auxiliary Alarm TCU 5-19D Alarm Return Air >35°C Volt Free Alarms Open On General Alarm Indication Fail ...
-
Page 11: Operating Data
Upflow Telecom Unit ECOTEL™ OUTDOOR Operating Data CONTROL - GENERAL microprocessor controller has been specifically designed to provide the control information necessary to operate the unit in an energy efficient manner. An optional real time clock (RTC) offers energy savings and will time / date stamp alarms. The unit will operate in 1 of 4 modes: Free Cooling - using outside air only Free Cooling and DX Cooling - using outside air and DX cooling... - Page 12 ECOTEL™ OUTDOOR Upflow Telecom Unit Operating Data UNIT OPERATION High Ambient Mode - "Mechanical Low Ambient - "Mechanical Cooling Low Ambient Mode - "Free Cooling" Cooling" & Combined free cooling" Precision Air Conditioning Installation & Maintenance: 6559595 IM V1.10.0 11/15...
-
Page 13: Start Up Data
Upflow Telecom Unit ECOTEL™ OUTDOOR Start Up Data Each Ecotel Outdoor unit leaves Airedale’s manufacturing facility fully charged and GENERAL pre-commissioned. PRE-START CHECKS General Once the whole system has been installed it is most important that the following pre-start checks are made: ... -
Page 14: Controls
ECOTEL™ OUTDOOR Upflow Telecom Unit - Controls OPTIONAL KEYPAD OPERATION When one or more alarm is active the ALARM button will illuminate red. Pressing the ALARM button once will indicate information regarding ALARM any active alarms. Pressing the ALARM button twice will reset any active alarms. Pressing the PRG button will select the main navigation menu. - Page 15 Upflow Telecom Unit ECOTEL™ OUTDOOR - Controls Navigation The display is used for Viewing Unit Operating Status and Adjusting Customer Control Settings by allowing the operator access to a series of Menus & sub-menus. Each screen has a code in the top right hand corner for navigation and diagnostics reference.
-
Page 16: Troubleshooting
ECOTEL™ OUTDOOR Upflow Telecom Unit Troubleshooting FAULT POSSIBLE CAUSE REMEDY/ACTION Unit not operating - Power Off. Main/local isolator off Check all isolators from mains to unit. Mains Fuse(s) failed. Check all mains fuses. Replace after correcting fault. Check for loose wire. Unit not operating - Power On. - Page 17 Upflow Telecom Unit ECOTEL™ OUTDOOR Troubleshooting FAULT POSSIBLE CAUSE REMEDY/ACTION Low Room Temperature. Damper not operating correctly. Damper jammed in full free cooling position during low ambient conditions. Compressor operating too long Check sensors. Sensors incorrectly set or faulty. Reset, repair or replace. Low airflow.
- Page 18 ECOTEL™ OUTDOOR Upflow Telecom Unit Troubleshooting FAULT POSSIBLE CAUSE REMEDY/ACTION Loss of duty. Low refrigerant charge. Check for leaks, rectify and recharge. Expansion valve faulty. Replace valve. HP switch tripped. Fan failed. Replace faulty item. Condenser clogged or dirty. Clean condenser. Refer to Maintenance Head pressure too high.
-
Page 19: Maintenance
Entry to the other side of the condenser coil and damper actuator is possible by removing the condenser fan panel and unplugging the condenser fan lead. (Please note a special tool is required to remove the securing bolts, Airedale part no. 515-596). SERVICE CHECKS -... - Page 20 ECOTEL™ OUTDOOR Upflow Telecom Unit Maintenance CONDENSER COIL Clean the condenser coil with a stiff bristled hand brush. If dirt has accumulated over a long period, or tends to be greasy or sticky, then it may be necessary to use a water hose (NOT High Pressure) or chemical pressure hose. Take care not to damage the fins and comb out if they have become damaged in any way.
-
Page 21: Parts Identification
Upflow Telecom Unit ECOTEL™ OUTDOOR Parts Identification TCU15D Shown Precision Air Conditioning Installation & Maintenance Manual: 6559595 IM V1.10.0 11/15... - Page 22 Second Stage Compressor (TCU15D & TCU19D) Condensate Tube SPARES For ease of identification when ordering spares or contacting Airedale about your unit, please quote the unit type, unit serial number and the date of manufacture, which can be found on the unit serial plate.
- Page 24 Head Office: Airedale International Air Conditioning Ltd Leeds Road Rawdon Leeds LS19 6JY United Kingdom Tel: +44 (0) 113 239 1000 Fax: +44 (0) 113 250 7219 e-mail: enquiries@airedale.com website: www.airedale.com PART NO: ISSUE DATE 901-061 IM E 01/06/01 11/07/01...
