- Page 1 IM3032 09/2022 REV06 CV 425 & 510 OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland www.lincolnelectric.eu...
-
Page 2: Table Of Contents
12/05 THANK YOU! For choosing the QUALITY of the Lincoln Electric products. Please check packaging and equipment for damage. Claims for material damaged in shipment must be notified immediately to the dealer. For ease of use, please enter your product identification data in the table below. Model Name, Code & Serial Number can be found on the machine rating plate. -
Page 3: Technical Specifications
Technical Specifications NAME INDEX CV 425 K14080-1A CV 510 K14081-1A INPUT Input Voltage U EMC Group / Class Frequency CV 425 230 / 400V±10% II / A 50 / 60 Hz 3 - phases CV 510 Input Power at Rated Cycle Input Amperes I cos φ... -
Page 4: Eco Design Information
Equivalent model / Idle power consumption K14080-1A CV 425 74,2% / 300W No equivalent model K14081-1A CV 510 73,2% / 400W No equivalent model Idle state occurs under the condition specified in below table IDLE STATE Condition Presence MIG mode... - Page 5 Typical gas usage for MIG/MAG equipment: DC electrode positive Wire Wire Feeding Gas flow Material type diameter Shielding Gas Current Voltage [m/min] [l/min] [mm] Carbon, low 0,9 ÷ 1,1 95 ÷ 200 18 ÷ 22 3,5 – 6,5 Ar 75%, CO alloy steel Aluminium 0,8 ÷...
-
Page 6: Electromagnetic Compatibility (Emc)
Lincoln Electric. Before installing the machine, the operator must check the work area for any devices that may malfunction because of electromagnetic disturbances. -
Page 7: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. - Page 8 WELDING SPARKS CAN CAUSE FIRE OR EXPLOSION: Remove fire hazards from the welding area and have a fire extinguisher readily available. Welding sparks and hot materials from the welding process can easily go through small cracks and openings to adjacent areas. Do not weld on any tanks, drums, containers, or material until the proper steps have been taken to insure that no flammable or toxic vapors will be present.
-
Page 9: Installation And Operator Instructions
Installation and Operator Instructions Read this entire section before installation or operation Input Supply Connection of the machine. WARNING Location and Environment Only a qualified electrician can connect the welding This machine will operate in harsh environments. machine to the supply network. Installation the outlet However, it is important that simple preventative plug to power lead and connecting the welding machine measures are followed to assure long life and reliable... - Page 10 4. Low Inductance Negative Output Socket: For connecting a work lead. 5. High Inductance Negative Output CV 510 Socket: For connecting a work lead. 6. Wire Feeder Receptacle: 14-pins receptacle for wire feeder. Provides connections for auxiliary power of wire feeder.
- Page 11 Technical Service Center or Lincoln Electric. Repairs Connect the wire feeder to the power source: and modifications performed by unauthorized service or insert the positive welding cable into the output personnel will cause, that the manufacturer’s warranty...
- Page 12 Electric for advice or information about their use of our products. We respond to our customers based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with respect to such information or advice.
-
Page 13: Weee
12/05 Part list reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. -
Page 14: Accessories
Accessories K10347-PG-xxM Source/wire feeder cable (gas). Available in 5, 10, 15m. K10347-PGW-xxM Source/wire feeder cable (gas and water). Available in 5, 10 or 15m. K14009-1 Socket Kit. K14082-1 AV Meter Kit. K14071-2 Grill Kit. K14037-1 Cooler COOLARC 25. English English...
