Pro-Form 905 CST User Manual page 14

12. Identify the Left and Right Handrail Covers (87, 8).
Slide the Left Handrail Cover (87) up against the
console assembly (F) and tighten a #8 x 3/4"
Screw (4) into the bottom of the Left Handrail
Cover. Be careful not to overtighten the
Screw.
Attach the Right Handrail Cover (8) in the
same way.
13. Orient the Storage Latch (98) as shown. Attach
the Storage Latch to the Left Upright (89) with
two 1/4" x 4 1/2" Screws (6) and two 1/4" Star
Washers (26) ; start both Screws, and then
tighten them.
12
F
87
4
13
98
14
8
4
6
26
89
