Main Eco Compact Combi 25 Installation And Service Manual page 15

Tab.9 Electrical specifications
Main Eco Compact Combi
Nominal electrical power supply voltage
Nominal electrical power supply frequency
Nominal power consumption when firing
External fuse rating
Internal fuse rating
Tab.10 Other specifications
Main Eco Compact Combi
Degree of protection against humidity (EN 60529)
Dimensions (height / width / depth)
Tab.11 Connections
Main Eco Compact Combi
Gas inlet
Heating flow
Heating return
Cold water inlet
Hot water outlet
Pressure relief discharge
Condensate discharge drain plastic waste pipe
Tab.12 Clearances
Main Eco Compact Combi
Above casing
Below casing (min)
Front — for servicing
Front — for operation
Sides LH
Sides RH
Tab.13 Weights
Main Eco Compact Combi
Packaged boiler
Boiler lift weight (dry)
Installed weight (dry)
Important
Dynamic (nominal) inlet pressure (Natural gas — G20) 20mbar
3
with a CV of 37.78 MJ/m
25
V 230
Hz 50
68
W
Amp 3
Amp F2A H250V
Important
Boiler must be connected to an earth supply.
25
IP IPX5D
mm
25
mm 22
mm 22
mm 22
mm 15
mm 15
mm 15
mm 21.5
25
mm 178
mm 200
mm 450
mm 5
mm 5
mm 5
25
kg 32.2
kg 29.2
kg 30.2
3 Technical specifications
30
230
50
68
3
F2A H250V
30
IPX5D
H 700/W 390/D 285
30
22
22
22
15
15
15
21.5
30
178
200
450
5
5
5
30
32.2
29.2
30.2
15
