REED Double Squeeze PE User Manual

USER MANUAL
Double
Squeeze
Squeeze Tools
PRIOR TO USE
• Only trained personnel should use this tool. Read and
understand instructions before operating. A mock squeeze-
off is recommended for users not familiar with the squeeze
procedure and the anatomy of the tool.
• Verify all parts are clean and free of debris that
may hinder operation.
• REED PE Squeeze Tools are to be used on
polyethylene (PE) pipe only.
• Manual REED Squeeze Tools must be operated by
hand and without the use of power tools.
• The use of additional leverage (i.e. cheater bars) is not
needed. The tool was designed to give adequate leverage
with the incorporated slide handle.
1425 West 8th Street Erie, PA 16502 USA
PE
™
REED MANUFACTURING
Phone: 800-666-3691 or +1 814-452-3691
www.reedmfgco.com
PES4DB
PES4DBM
TOOL OPERATION REMINDERS
• When satisfactory flow control cannot be obtained with one
tool, REED recommends a double squeeze-off. This means
using two squeeze tools in series.
• Be aware of the recommended squeeze/release rates to
avoid pipe damage (2 inches/min. [51 mm/min.] squeeze
and ½ inch/min. [13 mm/min.] release). Rates should be
slowed further in colder weather. Consult the local utility for
recommendations regarding squeeze and release rates.
• A squeeze should be performed a minimum of 12 inches
(305 mm) or 3 times the pipe diameter (whichever is greater)
from fittings, fusions, or previously squeezed pipe. Refer to
ASTM standard designation F1041-02 for more information.
WARNING
Cold temperatures can affect the pipe integrity during the
squeeze. Squeeze and releases rates need to be slowed in
temperatures below 50 ̊ F [10°C]. Cold temperatures can affect
the squeeze (below 50 ̊ F [10°C]) and result in a less than
desirable flow control. Give adequate time for the pipe to relax
during the squeeze (5-15+ minutes) and perform a double
squeeze-off if necessary.
