601 Power Drive
The REED 601 Power Drive is a portable,
electric-motor-driven, heavy-duty power drive
which provides power for threading pipe and
conduit up to 1 1/4" in diameter.
Made in Spain
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS.
FAILURE TO FOLLOW ALL INSTRUCTION LISTED
INSIDE MAY RESULT IN ELECTRIC SHOCK, FIRE,
AND/OR SERIOUS PERSONAL INJURY.
PHONE: 800-666-3691 or 814-452-3691
REED MANUFACTURING COMPANY
1425 West Eighth St.
www.reedmfgco.com
Pipe Tools & Vises
Since 1896
• Automatize the pipe threading process
• Light-weight
• 601V (#05242) Safety Vise included
• New technology
• Dropheads available in sizes from
1/4" to 1 1/4", order dropheads separately
• CSA and CE approved
SAVE THESE
INSTRUCTIONS!
Erie, PA
16502
USA
Fax: 800-456-1697 or 814-455-1697
Catalog No. 601PD
Item Code #05240
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for REED Power Drive 601
Summary of Contents for REED Power Drive 601
- Page 1 Pipe Tools & Vises Since 1896 Catalog No. 601PD 601 Power Drive Item Code #05240 The REED 601 Power Drive is a portable, • Automatize the pipe threading process electric-motor-driven, heavy-duty power drive • Light-weight which provides power for threading pipe and •...
- Page 2 ON. A wrench or a key that is left attached to a rotating part of • Electrical shock or burns from contact with wires, motor or other the tool may result in personal injury. power drive parts. 601 Power Drive Reed Manufacturing Co.
- Page 3 NOTE: Die head must be installed from the gear shifter side only. CRUSHED OR BROKEN. • Do not wear gloves. 2. Secure pipe in portable TriStand (Reed R450+ #02306) vise or • Keep sleeves and jackets buttoned. bench vise, if available.
- Page 4 Send the machine to a Reed Authorized Service Center or the clean rag. Reed factory for greasing every 500 hours of use. It is best to blow dust off the machine after work is over. NOTE: Power units for threading power drives are warranted for a period of one year from date of purchase.
