H. WEISS MACHINERY & SUPPLY
PHONE: (718) 605-0395 - www.hweiss.com
NO. 0617
BEADING MACHINE
OPERATING INSTRUCTIONS AND PARTS IDENTIFICATION
ROPER WHITNEY
2833 HUFFMAN BLVD., ROCKFORD, ILLINOIS 61103-3990 * 815/962-3011 * FAX 815/962-2227
Website: www.roperwhitney.com * Email: info@roperwhitney.com
Advertisement
Related Manuals for Roper Whitney 0617
Summary of Contents for Roper Whitney 0617
- Page 1 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com NO. 0617 BEADING MACHINE OPERATING INSTRUCTIONS AND PARTS IDENTIFICATION ROPER WHITNEY 2833 HUFFMAN BLVD., ROCKFORD, ILLINOIS 61103-3990 * 815/962-3011 * FAX 815/962-2227 Website: www.roperwhitney.com * Email: info@roperwhitney.com...
- Page 2 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com NO. 0617 BEADING MACHINE The No. 0617 Beading Machine is a deep throat design that is shipped with standard spacing collars and gauges for all operations except flanging. Rolls are ordered separately. SPECIFICATIONS: Capacity Mild Steel....18 Gauge...
-
Page 3: Installation
Immediately upon receiving the crimping and beading machine, check it very carefully for damage or loss of parts in transit. Since all equipment is sold F.O.B., the Roper Whitney Company plant, our responsibility for transit damage ceases when the transportation company signs the bill of lading indicating that it has received all of the items listed on the bill of lading in good condition. -
Page 4: Repair Parts
H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com Depth of bead can be limited by the check nuts on the adjusting screw. The positioning gauge is adjustable to locate the bead in relation to the end of the material being worked. LOWER HORN ADJUSTMENT: To adjust lower horn the lower horn set screw, which is located directly below oil hole on back side of machine, must be loosened FIRST. - Page 5 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com NO. 0617 BEADING MACHINE LUBRICATION 1. Use any standard lubrication industrial oil. 2. Use any standard machine bearing grease, such as Mobil Grease Special or Texclad 2. - 5 -...
- Page 6 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com...
- Page 7 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com NO. 0617 PARTS IDENTIFICATION LIST ITEM NO. PART NO. PART NAME 764560158 Roll Nut 764680164 Upper Shaft 243700017 Front Box Assembly (Consists of Front Box & Bunting Bushing which can only be purchased as...
- Page 8 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com NO. 0617 ROLL CHART 3” CENTERS ROLL ROLL GAUGE SPACING ROLL STYLE CATALOG NO. REQ’D COLLAR DIAGRAM 3/16” 350000086 259700035 381700092 350000087 1/4” 350000088 259700035 381700092 350000089 5/16” 350000090 259700035...
- Page 9 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com NO. 0617 ROLL CHART 3” CENTERS ROLL ROLL GAUGE SPACING ROLL STYLE CATALOG NO. REQ’D COLLAR DIAGRAM 3/16” 350000086 259700035 381700092 350000087 FLATTENING 1/4” 350000098 259700034 381700092 350000099 5/16” 350000096...
- Page 10 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com NO. 0617 ROLL CHART 3” CENTERS ROLL ROLL GAUGE SPACING ROLL STYLE CATALOG NO. REQ’D COLLAR DIAGRAM 350000070 259700034 381700092 350000071 350000072 350000073 FURNACE COLLAR EDGING 350000074 259700034 381700092 350000075...
