COMBINATION NOTCHER, COPER & SHEAR
OPERATION, PARTS & MAINTENANCE MANUAL
Model:
Serial #:
Roper Whitney / 2833 Huffman Blvd. / Rockford, IL 61103 / 815-962-3011 / Fax 815-962-2227
MODEL NO. PS-66
Purchased From:
Date Received:
An American Tradition Since 1910
www.roperwhitney.com
Advertisement
Related Manuals for Roper Whitney PS-66
Summary of Contents for Roper Whitney PS-66
- Page 1 MODEL NO. PS-66 COMBINATION NOTCHER, COPER & SHEAR OPERATION, PARTS & MAINTENANCE MANUAL Model: Purchased From: Serial #: Date Received: An American Tradition Since 1910 Roper Whitney / 2833 Huffman Blvd. / Rockford, IL 61103 / 815-962-3011 / Fax 815-962-2227 www.roperwhitney.com...
- Page 2 FOREWORD This manual has been prepared for the owner and operators of Roper Whitney No. PS-66 machine. Its purpose, aside from operations instructions, is to promote safety through the use of accepted operating procedures. Read all instructions thoroughly before operating the machine.
-
Page 3: Safety Labels
SAFETY LABELS Do not operate the machine without the proper safety label in place. If your machine is missing the following label please contact Roper Whitney Co. or your authorized Roper Whitney distributor to order. - 3 -... - Page 4 OPERATING INSTRUCTIONS FOR PS-66 PEXTO COMBINTATION NOTCHER, COPER & SHEAR WARNING: Before operating, machine must be bolted to work bench. If floor stand has been provided, machine must be bolted to floor stand with bolts provided. Stand must be securely lagged to floor.
- Page 5 g. Set lower left hand blade so that the notched front edge of the lower left hand blade just touches the front corner of the lower right hand blade. Set for normal clearance of .002” between upper and lower blades and at the beveled surface of the notch. Tighten lower left hand blade screws securely.
- Page 6 PS-66 PARTS IDENTIFICATION CHART - 6 -...
- Page 7 PS-66 PARTS IDENTIFICATION CHART - 7 -...
- Page 8 PS-66 NOTCHER, COPER & SHEAR PARTS LIST REFER TO PARTS IDENTIFICATION CHART INDEX PART NO. PART NAME 740060139 Base 611012283 SHC Screw 1/2-13 x 3” (Short Frame) 611012281 SHC Screw 1/2-13 x 2 1/2” (Long Frame) 601012131 HHC Screw 5/16-18 x 3/4” (Thumb)
- Page 9 PS-66 NOTCHER, COPER & SHEAR TAB BLADE KIT REFER TO PARTS IDENTIFICATION CHART INDEX PART NO. PART NAME 684012173 LHSC Screw 3/8-16 x 3/4” (Upper Tab Blade) 350700106 L. H. Upper Tab Blade 350700105 R. H. Upper Tab Blade 350700104 L.
