- Page 1 T30i Operation manual...
- Page 2 90° × 50° constant directivity horn. This results in a precise and dynamic voice and musical reproduction at already low volume. As the T30i is compatible with all TW AUDiO subwoofers, those can also be used for more sub bass.
- Page 3 This symbol in combination with the signal word “Tip” identifies additional information or notes that will simplify working with TW AUDiO products on the basis of practical experience. Notes on the products Before using the device, carefully read the operating manual and keep it with the T30i loudspe- Read manual aker.
-
Page 4: Table Of Contents
Operation manual T30i Content 1. Safety | Intended use ...................... 5 2. Overview ........................7 Components ......................7 3. Technical specifications ....................8 Data sheet ....................... 8 Connection diagram ....................8 4. Commissioning ....................... 9 Setup ........................9 M10 threaded inserts ....................9 Rotating the HF horn ..................... -
Page 5: Safety | Intended Use
1. Safety | Intended use Please adhere to the following safety instructions to avoid risks when operating loudspeakers. The T30i loudspeaker was developed for use in professional sound systems. The loudspea- ker may only be used by trained and qualified personnel. - Page 6 Operation manual T30i Ensure that the loudspeaker is not exposed to permanent thermal overloads. Thermal over- loads may cause a fire and result in serious personal injury and property damage. WARNING Note that TWAMBO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
-
Page 7: Overview
Operation manual T30i 2. Overview Components Figure 2.1 - Overview 15“ cone driver Rotatable horn with 1,4“ compression driver Front grill 18 mm Multiplex enclosure - Warnex textured paint surface M10 threaded insert for attaching accessories (8 pieces) Type label... -
Page 8: Technical Specifications
Operation manual T30i 3. Technical specifications Data sheet Drivers 2x 15“ LF / 1x 1,4“ HF Frequency response 34 - 20000 Hz 4000 / 8000 W LF Power handling (program/Peak) 160 / 320 W HF 4 Ω LF Impedance 8 Ω HF Coverage (h x v) 90°... -
Page 9: Commissioning
3. Please note that once the countersunk screws are removed, water and moisture may enter into the enclosure. NOTE 4. For the T30i loudspeaker M10 threaded inserts, various TW AUDiO accessories can be mounted. For each product refer to the instructions. (If you have further questions, please contact TW AUDiO Support.) WARNING 5. -
Page 10: Rotating The Hf Horn
To adjust the dispersion pattern, the T30i loudspeaker’s HF horn can be rotated. Proceed as follows: 1. Place the T30i loudspeaker on its back, with the speaker grill facing up. Make sure to place the speaker on a clean, non-slippery surface. -
Page 11: Operation
Before connecting the loudspeaker to the amplifier, ensure that the right preset has been loaded. NOTE Using a wrong, out dated or a preset not provided by TW AUDiO can lead to destruction of the speaker. Make sure that the amplifier’s specifications meet the requirements. Using an amplifier that doesn’t meet the specifications can destroy the loudspeaker. -
Page 12: Transport And Storage
Operation manual T30i 5. Transport and Storage Due to the T30i loudspeaker weighing over 20 kg [44 lbs.], two persons are required to handle and transport the unit. Ensure that the front grill of the loudspeaker is not damaged during transport and storage. -
Page 13: Disposal
Operation manual T30i 7. Disposal It is prohibited to dispose of used electrical equipment with household refuse. All TWAMBO GmbH products are so-called B2B-products. This means that they are sold by a commercial business to a commercial business. TWAMBO products that bear the trash can symbol shown here may only be disposed of by TWAMBO. - Page 14 Operation manual T30i TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
