Summary of Contents for TW Audio B10

  • Page 1 Operating Manual...
  • Page 2 The dimensions of our “smallest” let not assume such a performance. But the B10 wouldn’t be a TW AUDiO sub if it hadn’t more to offer: Its newly developed long excur- sion cone driver with an uncompromising 3" dual voice coil and optional passive cross-...
  • Page 3 TW AUDiO also shall not assume liability for any secondary damage (property damage and/or personal injury) nor for the failure to comply with this operating manual. TW AUDiO reserves the right to make changes that take into account the latest engi- neering advancements.
  • Page 4: Table Of Contents

    Operating Manual B10 Content Safety | Intended use .....................1 Overview ........................3 Components ........................3 Variants ..........................4 Operating modes ........................ 4 Technical data ........................6 Data sheet .......................... 6 Wiring diagram ........................6 Setting up the loudspeaker ..................8 Setup ..........................8 Connecting cables ......................
  • Page 5: Safety | Intended Use

    Note the operation modes described in this operating manual. Other uses are not permissible. TW AUDiO GmbH shall not be held liable for any damage that ensues from unintended use. Loudspeakers generate an electromagnetic field. Persons with pacemakers are not per- mitted to remain in the immediate vicinity of loudspeakers as the electromagnetic fields can cause pacemakers to malfunction.
  • Page 6 WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
  • Page 7: Overview

    Operating Manual B10 2. Overview 2.1 Components B10 passive B10 active Figure 2.1 - Overview 10" cone driver 15 mm multiplex housing – Warnex texture paint surface finish Cabinet flange M20 for attaching a distance rod Milling for rubber feet for safely stacking loudspeakers...
  • Page 8: Variants

    B10A (ACTIVE model) and B10P (PASSIVE model). 2.2.1. B10A / B10P model The standard version of the B10 loudspeaker is the B10A variant which can only be op- erated in "ACTIVE" mode. It comes with a standard connection panel. The separation takes place in the amplifier DSP.
  • Page 9 Operating Manual B10 Two input channels are required for operation in STEREO mode. The left input is assigned to pin 1 +/-, the right input to pin 2 +/-. If only 1-channel cables are used (PIN1+/-), PIN 1 can be inserted into the INPUT socket for the left input, and PIN 1 into the reversed socket for the right input.
  • Page 10: Technical Data

    Operating Manual B10 3. Technical data 3.1 Data sheet Variant B10A B10P 1x 10" LF Components 40 - 400 Hz 40 - 200 Hz Frequency response Program/peak power 700 / 1400 W 700 / 1400 W handling 1x 6Ω or 2x 12Ω, 1x 8Ω...
  • Page 11 Operating Manual B10 Version: B10P B10P MONO MODE S1 / TOP A ON TOP OUTPUTS Never connect these TOP A outputs to an amplifier Risk of TOP A TOP B damage Only switch ON with TOP connected INPUT PIN 1+...
  • Page 12: Setting Up The Loudspeaker

    (1/2) are correct. Incorrect connection results in a significant change in the loudspeaker sound characteristics and may damage the compression driver. The pin connections of the B10 loudspeaker can be found in section 3.2 “Wiring dia- gram” on page 6.
  • Page 13: Operation

    Operating Manual B10 4.3 Operation It is only possible to operate the B10A loudspeaker using a DSP controller. TW AUDiO recommends operating the B10P loudspeaker on a DSP controller. TW AUDiO only rec- ommends using presets developed by TW AUDiO. The TW AUDiO system racks are ideal for this purpose.
  • Page 14: Transport And Storage

    Operating Manual B10 5. Transport and storage To enable a single person to transport several multiple B10 loudspeakers, TW AUDiO recommends using the QDB10 quad dolly. NOTE When transporting and storing the unit, it is important to ensure that the surface and front grill of the loudspeaker are not damaged.
  • Page 15: Ec Conformity Declaration

    Operating Manual B10 6. EC Conformity Declaration Copy and translation of the original EC Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives.
  • Page 16: Disposal

    TW AUDiO products that bear the trash can symbol shown here are only permitted to be disposed of by TW AUDiO. The loudspeaker owner is legally responsible for the disposal of used devices that do not bear this symbol.
  • Page 17 TW AUDiO GmbH Osterholzallee 140-2 71636 Ludwigsburg Germany P: + 49 71 41-48 89 89 0 F: + 49 71 41-48 89 89 99 E: info@twaudio.de W: www.twaudio.de...
