- Page 1 VERA S30 Operation manual...
- Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this user manual...
- Page 3 Quality warranties or assurance of suitability for a certain type of use based on the technical specifications, dimensions and weights are not granted by TW AUDiO. TW AUDiO also shall not assume liability for any secondary damage (property damage and/or personal injury) nor for the failure to comply with this operating manual! TW AUDiO reserves the right to update this document based on recent developments.
-
Page 4: Table Of Contents
Operation manual VERA S30 Content 1. Safety | Intended use ...................... 5 2. Overview ........................7 Components ......................7 3. Technical specifications ....................8 Data sheet ....................... 8 Connection diagram ....................8 4. Commissioning ....................... 9 Setup ........................9 M20 pole mount flange .................... 9 Rigging ........................ -
Page 5: Safety | Intended Use
When using and assembling TW AUDiO loudspeakers, only use materials specified by TW AUDiO. These tasks must be performed by qualified personnel. Adhere to the applicable safety regulations. When setting up loudspeakers, ensure that they are not exposed to the following ambient... - Page 6 WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
-
Page 7: Overview
M20 pole mount flange for attaching a distance rod Rigging plate for attaching accessory parts Milling for rubberfeet for safely stacking loudspeakers Dolly latch base to attach the TW AUDiO B30 front dolly Rubber feet (8 pieces) 15“ cone drivers... -
Page 8: Technical Specifications
Operation manual VERA S30 3. Technical specifications Data sheet Drivers 2x 15“ LF Frequency response 35 - 200 Hz Power handling (program/Peak) 2000 / 4000 W Impedance 8 Ω Max. SPL / 1 m 133 dB Dimensions (h x w x d) 706 x 446 x 800 mm [27.80 x 17.56 x 31.50 in] Weight 42 kg [92 lbs]... -
Page 9: Commissioning
WARNING Make sure the speakers are securely fastened to prevent personal injury and property damage. WARNING TW AUDiO recommends using only the accessories specified by TW AUDiO for securing and mounting loudspeakers. NOTE M20 pole mount flange... - Page 10 Operation manual VERA S30 Before setting up the system outdoors, consider unexpected wind conditions at the opera- tion site! Disassemble your system immediately when wind speeds exceed 8 bft (34 to 40 kn / 62 to WARNING 74 kph / 38.5 to 46 mph) and secure the system components! Make sure that there are no persons in the immediate vicinity of the system structure! Make sure that the system structures are not operated over the audience at wind speeds in excess of 6 bft (22 to 27 kn / 39 to 49 kph / 24.2 to 30.45 mph) and that there are no persons...
- Page 11 Operation manual VERA S30 Figure 4.2.2 - VERA S30 – improper installation Figure 4.2.3 - VERA S30 – improper wall mounting...
-
Page 12: Rigging
CBH30, CBQ30 and BLT24. NOTE With our simulation software EASE Focus you can plan system setups with the VERA S30 loudspeaker. EASE Focus is available as a free download from the TW AUDiO web- site at www.twaudio.com. 4.3.1 Setup of flown VERA S30 with CBH30, in vertical orientation Note that the VERA S30 loudspeakers are mechanically connected. -
Page 13: Setup Of Flown Vera S30 With Cbq30, In Horizontal Orientation
Operation manual VERA S30 4.3.2 Setup of flown VERA S30 with CBQ30, in horizontal orientation Note that the VERA S30 loudspeakers are mechanically connected. This is done via the lateral rigging tracks (see figure 2.1 - pos. 3)! Please also note that with a vertical system structure with the CBQ30 suspension rail and the WARNING BLT24 boxlink cable on both sides, up to six loudspeakers can be mounted. -
Page 14: Operation
NOTE Using the wrong preset or a preset not provided by TW AUDiO preset can destroy the speaker. Make sure that the amplifier’s specifications meet the requirements. Using an amplifier that doesn’t meet the specifications can destroy the loudspeaker. -
Page 15: Transport And Storage
Due to the VERA S30 loudspeaker weighing over 20 kg [44 lbs.], two persons are required to handle and transport the unit. To transport the unit with a single person, TW AUDiO recommends using the FDB30 front dolly. Alternatively, up to four VERA S30 loudspeakers can also be transported in a QDB30 quad dolly. -
Page 16: Ce Conformity Declaration
Operation manual VERA S30 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. -
Page 17: Disposal
It is prohibited to dispose of used electrical equipment with household refuse. All TW AUDiO GmbH products are so-called B2B-products. This means that they are sold by a commercial business to a commercial business. TW AUDiO products that bear the trash can symbol shown here may only be disposed of by TW AUDiO. - Page 18 Operation manual VERA S30 TW AUDiO GmbH Osterholzallee 140 71636 Ludwigsburg Germany Phone : + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
