Summary of Contents for TW Audio i Series
- Page 1 VERA S32i Operation manual...
- Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this user manual...
- Page 3 Failure to comply with this safety instruction can lead to product damage. NOTE This symbol in combination with the signal word “Tip” identifies additional information or notes that will simplify working with TW AUDiO products on the basis of practical experience. Notes on the products Read manual...
-
Page 4: Table Of Contents
Operation manual VERA S32i Content 1. Safety | Intended use ...................... 5 2. Overview ........................7 Components ......................7 Operation modes ..................... 8 2.2.1 Cardiod ......................8 2.2.2 Endfire ........................ 8 3. Technical specifications ....................9 Data sheet ....................... 9 Connection diagram .................... -
Page 5: Safety | Intended Use
When using and assembling TW AUDiO loudspeakers, only use materials specified by TW AUDiO. These tasks must be performed by qualified personnel. Adhere to the applicable safety regulations. When setting up loudspeakers, ensure that they are not exposed to the following ambient... - Page 6 WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
-
Page 7: Overview
Operation manual VERA S32i 2. Overview Components Figure 2.1 - Overview Splay link (2 pieces) – enclosed separately Hexagon socket head cap screw M8x16-12.9 (9 pieces) – enclosed separately Lock washer VS-8-1.4301 (9 pieces) – enclosed separately Bracket (2 pieces) – enclosed separately Front grill Rigging tracks (2 pieces) 15 mm Multiplex enclosure - Warnex textured paint surface... -
Page 8: Operation Modes
Operation manual VERA S32i Operation modes The VERA S32i can be operated in one of two modes. The operating mode is selected by choosing the preset in the system amplifier. 2.2.1 Cardiod In Cardioid mode, the focus is on maximum sound pressure reduction behind the loudspeaker setup, with partial forward-facing level addition. -
Page 9: Technical Specifications
Operation manual VERA S32i 3. Technical specifications Data sheet Drivers 1x 18“ LF front / 1x 14“ LF rear Frequency response 38 - 120 Hz 2400 / 4800 W 18“ Power handling (program/Peak) 1400 / 2800 W 14“ Impedance 8 Ω 18“ / 8 Ω 14“ Max. -
Page 10: Commissioning
Make sure that all system structures are located on a firm, level surface and that the surface can bear the total weight! WARNING Make sure the speakers are securely fastened to prevent personal injury and property damage. WARNING TW AUDiO recommends using only the accessories specified by TW AUDiO for securing and mounting loudspeakers. NOTE... -
Page 11: Rigging
This may only be done via the splay links and brackets (see figure 2.1 - pos.1 to pos.4)! WARNING EASE Focus simulation software can be used to plan line arrays with VERA S32i loudspeakers. EASE Focus is available as a free download from the TW AUDiO website at www.twaudio.com. VERA RF600i pos.4 pos.2 and pos.3 pos.4... - Page 12 Operation manual VERA S32i Make sure that no multiple VERA S32i loudspeakers are flown horizontally! WARNING Figure 4.3.2 - improper use VERA S32i horizontal...
-
Page 13: Connection Options
NOTE Using the wrong preset or a preset not provided by TW AUDiO preset can destroy the speaker. Make sure that the amplifier’s specifications meet the requirements. Using an amplifier that doesn’t meet the specifications can destroy the loudspeaker. -
Page 14: Connecting The Cable
Operation manual VERA S32i Connecting the cable To create a cable connection with an amplifier rack from TW AUDiO, proceed as follows. Ensure that the cable cross sectional area is sufficient (at least 1.5 mm²) to avoid power losses. TW AUDiO recommends using the loudspeaker cables available from TW AUDiO. -
Page 15: Transport And Storage
Operation manual VERA S32i 5. Transport and Storage Due to the VERA S32i loudspeaker weighing over 40 kg [88 lbs.], three persons are required to handle and transport the unit. When transporting and storing the unit, it is important to ensure that the surface and front grill of the loudspeaker are not damaged. -
Page 16: Ce Conformity Declaration
Operation manual VERA S32i 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. -
Page 17: Disposal
It is prohibited to dispose of used electrical equipment with household refuse. All TW AUDiO GmbH products are so-called B2B-products. This means that they are sold by a commercial business to a commercial business. TW AUDiO products that bear the trash can symbol shown here may only be disposed of by TW AUDiO. - Page 18 Operation manual VERA S32i TW AUDiO GmbH Osterholzallee 140 71636 Ludwigsburg Germany Phone : + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
