TW Audio VERA S33 Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VERA S33
Operation manual

Advertisement

Table of Contents
loading

Related Manuals for TW Audio VERA S33

Summary of Contents for TW Audio VERA S33

  • Page 1 VERA S33 Operation manual...
  • Page 2 It goes without saying that a wide range of different setups can be achieved with the VERA S33. Featuring the same system width and a compatible rigging mechanism, the VERA S33 can be inconspicuously integrated in the VERA36 array.
  • Page 3 Operation manual VERA S33 This symbol in combination with the signal word “Tip” identifies additional information or notes that will simplify working with TW AUDiO products on the basis of practical experience. Notes on the products Before using the device, carefully read the operating manual and keep it with the Read manual VERA S33 loudspeaker.

  • Page 4: Table Of Contents

    Operation manual VERA S33 Content 1. Safety | Intended use ...................... 5 2. Overview ........................7 Components ......................7 Operation modes ..................... 8 2.2.1 Cardiod ......................8 2.2.2 Endfire ........................ 8 3. Technical specifications ....................9 Data sheet ....................... 9 Connection diagram ....................

  • Page 5: Safety | Intended Use

    1. Safety | Intended use Please adhere to the following safety instructions to avoid risks when operating loudspeakers. The VERA S33 loudspeaker was developed for use in professional sound systems. The loudspeaker may only be used by trained and qualified personnel.
  • Page 6 WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.

  • Page 7: Overview

    Operation manual VERA S33 2. Overview Components Figure 2.1 - Overview Rigging tracks (4 pieces) 18“ cone driver (front) M20 pole mount flange for attaching a distance rod 15 mm Multiplex enclosure – polyurea surface finish Ergonomic carrying handles (two each, left and right) Rubber feet (4 pieces) 15“...

  • Page 8: Operation Modes

    Operation manual VERA S33 Operation modes The VERA S33 can be operated in one of two modes. The operating mode is selected by choosing the preset in the system amplifier. 2.2.1 Cardiod In Cardioid mode, the focus is on maximum sound pressure reduction behind the loudspeaker setup, with partial forward-facing level addition.

  • Page 9: Technical Specifications

    Operation manual VERA S33 3. Technical specifications Data sheet Drivers 1x 18“ LF front / 1x 15“ LF rear Frequency response 33 - 120 Hz 2400 / 4800 W 18“ Power handling (program/Peak) 2000 / 4000 W 15“ Impedance 8 Ω 18“ / 8 Ω 15“...

  • Page 10: Commissioning

    Operation manual VERA S33 4. Commissioning Setup The VERA S33 loudspeaker is designed to be used as a single loudspeaker as well as for array operation. Make sure that all system structures are located on a firm, level surface and that the surface...
  • Page 11 WARNING Please note that only centered loads are allowed to be placed on the M20 pole mount flange – figure 2.1 – Item 2. WARNING Figure 4.2.1 - system setup VERA S33...
  • Page 12 Operation manual VERA S33 Figure 4.2.2 - VERA S33 – improper installation Figure 4.2.3 - VERA S33 – improper wall mounting...

  • Page 13: Rigging Tracks

    Operation manual VERA S33 Rigging tracks Please note that several VERA S33 loudspeakers should be only flown vertically in relation to each other! WARNING Please note that the VERA S33 loudspeakers must be mechanically correctly connected with each other. This may only be done via the front and rear rigging tracks (see figure 2.1 - pos.5)
  • Page 14 Operation manual VERA S33 Make sure that no multiple VERA S33 loudspeakers are flown horizontally! WARNING Figure 4.3.2 - improper use VERA S33 horizontal...

  • Page 15: Operation

    NOTE Using the wrong preset or a preset not provided by TW AUDiO preset can destroy the speaker. Make sure that the amplifier’s specifications meet the requirements. Using an amplifier that doesn’t meet the specifications can destroy the loudspeaker.

  • Page 16: Connecting The Cable

    (1/2) are correct. Incorrect connection can lead to a significant change in the loudspeaker’s sound characteristics and may damage the driver. The pin connections of the VERA S33 loudspeaker can be found in section 3.2 (“Connection dia- gram”) on page 9.

  • Page 17: Transport And Storage

    Operation manual VERA S33 5. Transport and Storage Due to the VERA S33 loudspeaker weighing over 40 kg [88 lbs.], three persons are required to handle and transport the unit. To allow a single person to transport up to two VERA S33 loudspeakers, TW AUDiO recom- mends using the QDB30 quad dolly.

  • Page 18: Ce Conformity Declaration

    Operation manual VERA S33 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives.

  • Page 19: Disposal

    It is prohibited to dispose of used electrical equipment with household refuse. All TW AUDiO GmbH products are so-called B2B-products. This means that they are sold by a commercial business to a commercial business. TW AUDiO products that bear the trash can symbol shown here may only be disposed of by TW AUDiO.
  • Page 20 Operation manual VERA S33 TW AUDiO GmbH Osterholzallee 140 71636 Ludwigsburg Germany Phone : + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
