- Page 1 Ai-HB 050A/ Ai-HB 075A/ Ai-HB 100A/Ai-HB 125A/ Ai-HB 150A / Ai-HB 175A /Ai-HB 200A Ai-HB G2 Series Battery Quick Installation Guide Android...
-
Page 3: General Information
The contents of this guide may be updated or revised due to product development. The information in this guide is subject to change without notice. The latest version of this document and the manual for installation, commissioning, configuration and decommissioning are to be found in PDF format at www.solplanet.net. SAFETY 2.1 Intended use The product is a battery system for residential and works with the solar hybrid invert- ers. - Page 4 laws, regulations or standards that apply to the installation, electrical safety and use of the product. 2.2 Important safety instructions The product has been designed and tested in accordance with international safety requirements. As with all electrical or electronical devices, there are residual risks despite careful construction.
- Page 5 ！ WARNING Risk of injury due to weight of product！ Injuries may result if the product is lifted incorrectly or dropped while being trans- ported or mounted. • Transport and lift the product carefully. Take the weight of the product into account.
- Page 6 2.3 Symbols on the label Beware of a danger zone! This symbol indicates that the product must be additionally grounded if additional grounding or equipotential bonding is required at the installation site. Beware of high voltage and operating current！ The product operates at high voltage and current. Work on the product must only be carried out by skilled and authorized electricians.
- Page 7 PARALLEL SYSTEM WIRING DIAGRAM P- P+ Terminal resistor … （1≤N≤4） Ai-HB 050A/075A/100A/125A/150A/175A/200A QG0048_Ai-HB 050-200A_EN_540-300266-00_0223...
-
Page 8: Eu Declaration Of Conformity
AISWEI New Energy Technology (Yangzhong) Co., Ltd. confirms herewith that the products described in this document are in compliance with the fundamental requirements and other relevant provisions of the above mentioned directives. The entire EU Declaration of Conformity can be found at www.solplanet.net. QG0048_Ai-HB 050-200A_EN_540-300266-00_0223... - Page 9 OVERVIEW Object Description Battery control unit(BCU) Battery Module 指示逆变器当前的工作状态 LED指示灯 Base SOC Light Circuit Breaker Link port out Link port in On/off Grounding QG0048_Ai-HB 050-200A_EN_540-300266-00_0223...
-
Page 10: Scope Of Delivery
SCOPE OF DELIVERY 6.1 BCU and Base Package Quick installation Positive cable and Hanger×2 BCU and Base×1 guide×1 negative cable×1 M6×16 M8×40 Expansion M5X12 Screw×2 Terminal resistor×1 Hexagon screw ×1 Anchor Bolt×2 6.2 Battery Module Package Battery Module×1 M5×25 Screw×2 QG0048_Ai-HB 050-200A_EN_540-300266-00_0223... -
Page 11: Mounting Environment
MOUNTING ENVIRONMENT +50℃ -20℃ IP65 RH.+5%~+95% max.3000m × × × √ √ √ ≥350mm ≥350mm QG0048_Ai-HB 050-200A_EN_540-300266-00_0223... - Page 12 ≥350mm ≥350mm ≥350mm ≥350mm DIMENSIONS Unit： mm MOUNTING N.W: 15kg QG0048_Ai-HB 050-200A_EN_540-300266-00_0223...
- Page 13 N.W: 30.5kg 2≤N≤8） 4N.m Φ8mm 90° 50mm QG0048_Ai-HB 050-200A_EN_540-300266-00_0223...
-
Page 14: Protective Grounding
4N.m PROTECTIVE GROUNDING L=E+(2~3)mm ≥10mm² · copper wire QG0048_Ai-HB 050-200A_EN_540-300266-00_0223... -
Page 15: Battery Connection
BATTERY CONNECTION QG0048_Ai-HB 050-200A_EN_540-300266-00_0223... - Page 16 The following information is needed to provide necessary assistance: ——Battery model ——Battery control unit and module series number ——Fault code ——Installation location EMEA Service email: service.EMEA@solplanet.net APAC Service email: service.APAC@solplanet.net LATAM Service email: service.LATAM@solplanet.net Aiswei Greater China Service email: service.china@aiswei-tech.com...
- Page 20 AISWEI Technology CO., Ltd...
