ASSEMBLY

• To hire an authorized service technician to
assemble this product, call 1-800-445-2480.
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
1. Go to www.proform.com/registration on your
computer and register your product.
• activates your warranty
• saves you time if you ever need to contact
Customer Care
• allows us to notify you of upgrades and offers
Note: If you do not have internet access, call
Customer Care (see the front cover of this
manual) and register your product.
2. With the help of another person, place some
sturdy packing materials under the rear of the
Frame (1) so that the Frame is lifted off the floor.
Have the other person hold the elliptical to
prevent it from tipping.
If there are shipping supports attached to the
rear of the Frame (1), remove the screws attach-
ing the shipping supports. Discard the screws
and the shipping supports.
Attach the Rear Stabilizer (70) to the Frame (1)
with two M10 x 120mm Screws (84).
Then, remove the packing materials and lower
the elliptical.
• In addition to the included tool(s), assembly
requires the following tool(s):
one Phillips screwdriver
Assembly may be easier if you have a set of
wrenches. To avoid damaging parts, do not use
power tools.
1
2
70
84
7
1
