Page 1
OWNER’S MANUAL LG CORDLESS HANDY-STICK CLEANER This manual contains important information and instructions for the safe use and maintenance of the vaccum cleaner. Please read all of the information on page 3, 4, 5 for your safety. Please keep this manual in an easily accessible place for future reference.
Table of contents Important safety instructions ................3~5 Components and functions ..................6 How to use ......................7~15 Assembling vacuum cleaner ....................7 Assembling Charger .......................8 Using the Product ......................9~11 Charging ..........................12 Cleaning Dust bin .........................13 Assembling Dust bin ......................14 Cleaning Nozzle ........................15 Troubleshooting Guide ...................16...
2. Children should be supervised to ensure that they do not play with the appliance. 3. If the supply cord is damaged, it must be replaced by LG Electronics Service Agent in order to avoid a hazard. 4. This appliance can be used by children aged from 8...
Page 4
• If the supply cord is damaged, it must be off the power switch of the main body, pull out the replaced by the manufacturer, its authorised power plug, and contact LG Electronics Service service agent or similarly qualified persons in Agent to avoid hazard.
Page 5
ImporTanT safeTy InsTrucTIons CAUTION • Do not use this cleaner on anything other than • If a foreign object is attached to the bottom rated voltage. surface of dust bin, remove it before using the It may cause fire and unrepairable product product.
components and functions Stick power button Finger hanger - Place your finger here Speed button for comfortable use. Handy release buttons Main body Handy Power/Turbo/ Standard switch Battery indicator Built-in brush Dust bin release button Cleaning brush Charging stand Charging indicator Anti-tangle brush LED lighting Components:...
How to use Assembling vacuum cleaner Upper body part Lower body part ➊ Assembling the Upper and Lower body parts ➋ Fasten the fixing screw Attach upper body part to the lower body part in There is a fixing hole on the rear side arrow direction as shown in the figure.
How to use Using the Product Handle power button Battery Projection indicator Speed button (High or Low) Handy Power/Turbo/ Standard switch Groove Battery indicator Make sure the assembly part has docked correctly. Press the power button to turn on the product. Place the rear bottom of the main body •...
Page 10
How to use Using the Product The anti-tangle brush is ideal for cleaning short-furred carpet or a normal timber floor surface. ① It is not recommended to vacuum a carpet with long fur. ② If you vacuum a long piled carpet, it may cause the anti-tangle brush to stop rotating. –...
Page 11
How to use Using the Product For the convenience of the user,a built-in brush is attached to the hand held cleaner. When using the hand held cleaner alone, refer to the following instructions. Using built-in brush Retracting the built-in brush Pull out the built-in brush until it secures into place at Firmly slide the built-in brush in the the bottom of the vacuum cleaner in the arrow direction.
How to use Charging Battery indicator Charging indicator ➊ If the voltage gets low during ➋ The charging time may vary depending on the battery operation, the power is condition. automatically turned off to When the minimum amount of charge is left, it takes about protect the battery.
How to use Cleaning Dust bin Dust bin release button ② ③ Dust bin filter ① Prefilter Dust bin Dust separator Dust separator ⑤ ④ Cleaning brush Clean and dry ① To detach the dust bin, push and hold the Helpful tip release button and pull it in arrow direction.
How to use Assembling Dust bin Prefilter Dust bin filter Dust separator Dust separator ① ② ③ Dust bin ① Assemble the prefilter and large dust separator. When assembling them, make sure that the protrusion of the prefilter looks like the picture in the circle. ②...
How to use Cleaning Nozzle Anti-tangle brush Hook Hook Belt ➌ Clean the brush when ➊ As showing in the ➋ Lift the anti-tangle brush brush is tangled with figure, press the hook to in the arrow direction hairs and threads. release the anti-tangle and detach it from the - Use another vacuum...
Troubleshooting Guide If there is an abnormality in the product, check the following items first before requesting for a service center or calling the store. A service cost will be charged if the appliance has a user related malfunction, or no malfunction is found.
