- Page 1 CLEANING ROBOT Before using, please carefully read the Safety Precautions pages to allow for safe operation of the product. After reading the operation manual, please keep it in an easily accessible location. *M : Ultra microfiber mop (option) VR5901LVM VR5902LVM www.lg.com...
- Page 2 FEATURES Images of the ceiling and floor are obtained from the sensors of the upper and lower cameras, and through this, the location of Roboking will be confirmed, therefore, elaborate cleaning can be accomplished for every part of the room. Camera sensor (upper, lower section) As the height of the Roboking is low (90mm), even the underside of a framed...
-
Page 3: Table Of Contents
CONTENTS BEFORE USING ADDITIONAL INFORMATION Safety Precautions 28~30 Troubleshooting Included with Product Before You Call for Service Parts Descriptions Button Functions REFERENCE ITEMS Display Status Information Product Specifications Before You Start Open Source Software Notice Overview HOW TO USE How to Install the Home Station How to Turn the Power Supply On and Off. -
Page 4: 2~4 Safety Precautions 28~30
Doing so can cause fire or product failure. electric shock, fire or product failure. If the power cord is broken, do not plug it in. Take the product to an LG Electronics Authorised service repairer. Do not place the home station and Always use a dedicated outlet. - Page 5 SAFETY PRECAUTIONS WARNING Do not allow children or pets to play Do not touch the power plug with with or rest upon the Roboking at any wet hands. time. Do not use the Roboking while Doing so can cause electric shock. an object is hanging from it.
- Page 6 Doing so can cause product failure. put any water or detergent on the Roboking. If liquids get inside of the Roboking, turn off the power supply and contact an LG Elec- tronics sales agent or customer care center. When the robot cleaner is operating,...
-
Page 7: Included With Product
After reading the operation manual, please keep it in an easily accessible location. *M : Ultra microfiber mop (option) VR5901LVM VR5902LVM www.lg.com Dust bin filter (spare) Quick guide Operation manual Brush for cleaning Filter Ultra microfiber mop... - Page 8 PARTS DESCRIPTION - Roboking Plan view Manipulation button Dust bin cover button Dust bin cover State indication lamp Upper camera sensor Detecting sensor of home station & receiving sensor of remote controller Front view Ultrasonic sensor Obstacle detecting sensor window Rear view Ventilation port Bottom view...
- Page 9 PART DESCRIPTION – HOME STATION / DUST BIN Home station Power lamp Charging terminal Reset button Power cord fixing groove Dust bin Dust bin handle Dust bin cover Suction port cover Sponge filter Dust bin cover opening button HEPA filter Figures can be different from actual objects.
- Page 10 BUTTON FUNCTIONS – Roboking • Use the TIMER button to start cleaning after a set amount of time has elapsed. • The timer can be set from 1 to 12 hours. TIMER • The timer button only works when the Roboking is attached to the home station. Always attach Roboking to the home station when setting the timer function •...
-
Page 11: Button Functions
BUTTON FUNCTIONS – REMOTE CONTROL Charging Start The Roboking will start cleaning The Roboking will move to the home station for charging. Directional button Stop The Roboking will move as If the Roboking is in operation it desired by the user: to front, will be stopped. -
Page 12: Display Status Information
DISPLAY STATUS INFORMATION Spot cleaning • Indicates when the Roboking is in spot cleaning mode. (page 19) Battery and timer hour indication Spatial expansion cleaning • When in Stand by without any • Indicates when the Roboking is in timer setting, the remaining battery spatial expansion cleaning mode. -
Page 13: Before You Start
BEFORE YOU START Check these items before cleaning • Do not use this device in a room where a child is left alone. The child could be injured. • Remove fragile or unnecessary objects from the room to be cleaned. Especially, remove expensive ceramics and valuables from the floor. -
Page 14: Overview
OVERVIEW Install the home station. (page 13) Insert the power cord plug into an outlet and locate the station against a wall. If power is not supplied to the home station, the Roboking will not charge. Turn on the power supply of the Roboking. (page 14) Turn on the power switch located on the bottom of the Roboking and press the upper START/STOP button to turn on the power supply. -
Page 15: How To Install The Home Station
• Do not operate the Home Station if it has a damaged cord or plug, if it is not working prop- erly, or if it has been damaged or dropped. To avoid any electrical hazard, the cord must be replaced by LG Electronics, or a qualified service person. - Page 16 HOW TO TURN THE Roboking POWER SUPPLY ON & OFF Turning on the main power supply To turn the power supply on, turn the Roboking upside down on a smooth/soft surface and check whether the main power sup- ply switch is turned on. If the main power supply switch is turned off, turn on the switch.
-
Page 17: How To Start And Stop Cleaning
HOW TO START AND STOP CLEANING Using the buttons on the Roboking After the Roboking is turned on, press the START/STOP button to begin cleaning. A melody will sound and cleaning will begin. Press the START/STOP button during the cleaning cycle to stop cleaning. ※... -
Page 18: How To Charge The Battery
HOW TO CHARGE THE BATTERY Automatic charging The Roboking returns to the home station at the end of a cleaning cycle or when its battery is running low. ※ In the event that the unit returns to the Home Station due to a low battery, cleaning will be started, after the charging, from the near- est place of the area which has not been cleaned before. - Page 19 HOW TO CHARGE THE BATTERY Remaining Battery Charge Indicator The remaining battery charge can be confirmed from the charge indication lights, which will indicate charge as follows: • During charging, the charge remaining indication lights will flicker. • When charging is completed at the home station, only the battery icon will illuminate to save power. •...
-
Page 20: Cleaning Modes
CLEANING MODES Zigzag cleaning 수동 청소 With zigzag cleaning, total inside of the house will be cleaned with the repetition of zigzag traveling. If rapid cleaning is desired, use the zigzag cleaning. When pressing ‘ZIGZAG’ button of remote controller, zigzag cleaning will be started while zigzag cleaning icon is indicated at the state indication lamp. -
Page 21: Auxiliary Cleaning Modes
AUXILIARY CLEANING MODES Manual cleaning This method of cleaning involves manually moving the Roboking by pressing the directional (arrow) buttons on the remote control. The interior space will be cleaned by the Roboking as it is being moved to the front, rear, or rotated to the left and right side according to the input of the directional buttons. -
Page 22: Timer Cleaning
TIMER CLEANING Set the timer to schedule the cleaning and begin in 1-12 hours. 1. By pressing the TIMER button on the re- mote control or the Roboking, a clean- ing start time can be scheduled. 2. Adjust the time as much as desired by mul- tiple presses of the TIMER button. -
Page 23: Mop Cleaning (Option)
MOP CLEANING (option) By attaching the ultra microfiber mop, you can ef- Ultra microfiber mop fectively use the Roboking to remove dust. Mop plate When the mop plate is attached, the Roboking will not climb on to carpets or over thresholds, in order to prevent transferring dirt from the mop. -
Page 24: Cleaning The Dust Bin
CLEANING THE DUST BIN If the dust bin is full, suction power can be weakened. Clean the dust bin before and after each cleaning ses- sion. Clean the dust bin using the following sequence: 1. Open the dust bin cover by pressing the PUSH button on the Roboking. -
Page 25: Cleaning The Dust Bin Filter
CLEANING THE DUST BIN FILTER The dust bin filters are comprised of the HEPA filter and the sponge filter. Clean the HEPA filter and the sponge filter according to the following sequence: 1. Separate the HEPA filter and the inside sponge filter by removing the HEPA filter (as shown). -
Page 26: Cleaning The Brush
CLEANING THE BRUSH The brush, located on the bottom of the Roboking, helps with the suction of foreign objects. Perform the fol- lowing steps to clean the brush: Lay a smooth cloth on the floor. Separate the cover by press- Wearing gloves turn the brush Turn the Roboking over and ing the fixing hook and pulling... -
Page 27: Cleaning The Sensor/Charging Terminal
CLEANING THE SENSOR/CHARGING TERMINAL There are sensors on the Roboking that can detect obstacles, stairways and the home station for charging the battery. In order to maintain the performance of the Roboking, regularly clean the sensors and charging terminal as follows: 1. -
Page 28: Cleaning The Side Brush
CLEANING THE SIDE BRUSH Foreign objects/materials such as hair can easily adhere to the side brush. Remove such materials at least once a week. If excessive amounts of foreign materials are stuck to the brush, there is a risk of damage to the brushes. If the floor is rough or wall skirtings are frequently cleaned, the side brush may bend or become damaged. -
Page 29: Cleaning The Ultra Microfiber Mop (Option)
3. Use the mop only after allowing it to dry completely in a sunny, well-ventilated area. • To avoid product malfunction, only use the ultra microfiber mop provided with the Roboking. • Additional microfiber mops can be purchased by visiting a nearby LG Electronics service center. - Page 30 TROUBLESHOOTING When the voice, “Please check the wheels”, is announced. If the unit becomes stuck or suspended and the wheels do not allow the unit to move, the voice, “Please check the wheels”, will be announced. • Is a wheel trapped in the front door, balcony, stairway, etc? ▶...
- Page 31 TROUBLESHOOTING When the voice, “Please check the dust bin”, is announced When an abnormality is detected with the dust bin, the voice, “Please check the dust bin”, is announced. • Is the dust bin fitted correctly? ▶ Open the dust bin cover, and if check if the dust bin is actually fitted. The unit will not operate without the dust bin.
- Page 32 TROUBLESHOOTING When you hear “Please check the brush” When the Roboking detects that the brush is not functioning properly, you will hear the message “Please check the brush. ” Lay a smooth cloth on the floor, overturn the Roboking, and place it on the cloth. •...
- Page 33 BEFORE YOU CALL FOR SERVICE Confirm before reporting the failure of Roboking. Problem Solutions (Reference page) ▶ Confirm that the power switch is turned on. (page 14) The Roboking will not activate. ▶ Confirm that the battery has been charged. (page 17) ▶...
- Page 34 PRODUCT SPECIFICATIONS Item/model LG Roboking VR5901LVM, VR5902LVM Φ 360 mm X 90 mm External dimension Weight 3.2 kg Power consumption 18 W Battery (fully charged) DC 16.8 V Maximum Traveling Velocity 350 mm/sec Use time Approx. 75 minutes (1 time charging)
- Page 35 REFERENCE ITEMS Open source software notice To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http://opensource.lge.com . In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.
- Page 36 Disposal of waste batteries/accumulators 1. When this crossed-out wheeled bin symbol is attached to batteries/accumulators of Your product it means they are covered by European Directive 2006/06/EC. 2. This symbol may be combined with chemical symbols for mercury(Hg), cadmium(Cd) or lead(Pb) if the battery Con- tains more that 0.0005% of mercury, 0.002% of cadmium or 0.004% of lead.
