- Page 1 Technical Manual GN ReSound A/S Global Technical Operations RS Custom Product Platform https://gto.gnresound.com Coyote 6 CIC Lautrupbjerg 7 DK-2750 Ballerup Denmark...
-
Page 2: Table Of Contents
Doc 0452940 rev. A Table of Contents Form-factor-matrix .......................... 3 Part lists ............................4-5 Installing programming module on faceplate ................6 Faceplate & programming cable ....................7 Faceplates assemblies C6 CIC ......................8 Microphone assembly ........................9 Receiver assembly ..........................10 Wiring diagram C6 .........................11 Final device ............................12 Test equipment ..........................13 Test procedure CIC .........................14... -
Page 3: Form-Factor-Matrix
Form-factor-matrix C6 CIC Resound One Doc 0452940 rev. A Below is a form-factor-matrix of available models for each HI family. This Tech Man contains the necessary repair process for each mentioned model Power Battery Single Tele Auto Cambridge Custom (C6) -
Page 4: Part Lists
Part List for C6 CIC Doc 0452940 rev. A Item Part No Item Part No TUBING,Q-FLEX,.062ID,.095OD 10049101 SLEEVE,WIRE Uncut 11834-001 (for LP REC) (Orange FOR MIC) TUBING,SILICONE,.100ID X.116OD 11509-000 TYGON TUBING .035X.062 0198602 (for MP-HP REC) (MIC TUBE) TUBING,SILICONE,.120ID X.136OD 10929-000 TUBING TYGON 0198601... - Page 5 Part List Faceplates - Battery Doors - Push Buttons C6 CIC Doc 0452940 rev. A Blank FP 10A UNIVERSAL (Raw) Part No Program Module (I-Block module) Part No FP,10A,UNIV,LHT 19184600 (LIGHT BEIGE) Light (LHT) 19184900 FP,10A,UNIV,DRK 19184602 (BROWN) Medium Brown (MBR) 19184905 FP,10A,UNIV,BGE 19184604...
-
Page 6: Installing Programming Module On Faceplate
Installing Programming Module on faceplate Doc 0452940 rev. A Raw blank faceplate w/o module Using a tweezer, Pick up module Insert module into slot in face- Ensure that the I-Block prog by contact to avoid damaging the plate. Contacts point toward module is placed evenly (both plastic hinge pin... -
Page 7: Faceplate & Programming Cable
Faceplates with Prog Module for C6 Doc 0452940 rev. A Programming Module (I-BLOCK) Stop feature Longer connecting strip Faceplate with Programming Module Stop guide feature New CS63 Flex Old CS63 flex CS53 Adapter Flex 3-PIN cable strip cable strip P/N 19533900 P/N 19181700 Note: Please make sure to use the new CS63 flex cable with a longer strip connection P/N 19181700 or Adapter Flex,3-PIN CS53 P/N 19533900. -
Page 8: Faceplates Assemblies C6 Cic
Faceplates Assemblies C6 CIC Doc 0452940 rev. A 10A FP ASM C6 CIC Picture shown is example of the assembly of different configurations. Page 8 of 14 Not subject to issue control when printed... -
Page 9: Microphone Assembly
Microphone Assembly C6 CIC Doc 0452940 rev. A Solder wires as shown above Install orange sleeve (2.5mm) to the Mic wire. NOTE: Peters coat must be added after soldering Page 9 of 14 Not subject to issue control when printed... -
Page 10: Receiver Assembly
Receiver Assembly C6 CIC Doc 0452940 rev. A For LP For - MP-HP Solder the wires - Paste Rec Insulation Tape Paste Rec Insulation Tape in the solder joint of REC Q-flex tubing Silicone tubing p/n 10049101 p/n 10929-000 Wrap Rec with Tubing,silicone p/n 10929-000. Place the Q-flex tubing as shown. -
Page 11: Wiring Diagram C6
NEW Wiring Diagram for C6 CIC Doc 0452940 rev. A Please Note: The hybrid C6 does not support Volume Control. Left Right Faceplate Faceplate (Batt. compartment) (Batt. compartment) H 19 H 19 H 20 H 20 H 16 H 17 H 16 H 17 Push Button... -
Page 12: Final Device
Final Device C6 CIC Doc 0452940 rev. A Page 12 of 14 Not subject to issue control when printed... -
Page 13: Test Equipment
Test Equipment C6 CIC Doc 0452940 rev. A Programming cable sets mentioned can be used Adapt Flex, CS44 cable 3 PIN CS53 Connect the flex to the prog cable Hi-Pro Programming cable CS44: Hi-Pro Programming cable CS44: by using the flex end marked with p/n 9022 907 69029, Left (Blue) p/n 9022 907 69029, Left (Blue) an arrow... -
Page 14: Test Procedure Cic
Test Procedure CIC Doc 0452940 rev. A 1- Open Test Control. (DSA 6000) 2- Ensure Acoustical Calibration and Validation System (Doc# 0202830) have been calibrated prior to testing hearing instruments. 3- Wrap the canal tip with Fun-tak including the vent hole. 4- Leave vent on faceplate side open.
