  • Page 1 System Manual 1+n technology...
  • Page 2 Video interfacing relay door loudspeaker AS-TVKa-64/2 with VAR 602-... AS-Ta-64/1 Siedle Classic with VKA 511-... and VMO 511-...72 AS-Ta-64/1 Siedle Steel AS-Ta-64/1 with Siedle Vario 8 Servicing DoorCom Analog DCA 612-... Exchange/extension AS-Ta-64/2 Siedle Vario HTS/HTC 711 with 2 door stations...
  • Page 3 2 Safety remarks 1 1+n technology Danger System description Wire-saving Wire-saving 1+n system with 1+n system video transmission Configuration Configuration The wire-saving 1+n system is based The 1+n system can be combined Mounting, installation and on an installation with a common with video.
  • Page 4 3 Configuration, conductor lengths 1+n system without video Configuration of the 1+n system Functions The basic installation is performed as • Door call: Ringing at the front door a side circuit installation.The door (door station) and speech stations and in-house telephones are connection routed to the sub-distributor.
  • Page 5 For the entire conductor length in the 1+n system, the following applies: with cable material YR or J-Y(St)Y with 0.8 mm diameter • max. 500 m/1640 ft between the door station and the most distant in- house telephone • max. 100 m/328 ft between the line rectifier and the most distant door station •...
  • Page 6 3 Structure, conductor lengths 1+n system with video Structure of the 1+n system with the in-house telephone to which the video door call was placed. The basis for a 1+n system with video is installation of a camera Power supply module in the door station and The line rectifier NG 602-…...
  • Page 8 3 Overview Parallel door stations Connection of the telephone Secondary signal unit Up to 8 door stations can be system A secondary signal unit NS 711-... connected in parallel without the One or more door stations using can be connected in parallel to an need for any further accessories.
  • Page 10 4 Device overview 1+n Door loudspeakers, call buttons TLM 612-01 Door loudspeaker module for the 1+n system. The loudspeaker and microphone are integrated, illumi- nated light button, integrated door release and light contact (Dr/Li). Contact load max. 15 V AC/30 V DC, 2 A, switching time for the door release fixed at 3 seconds, switching time for the light fixed at 0.8...
  • Page 11 4 Appliance overview 1+n Door loudspeakers Siedle Classic consumption LED lighting for the CL A 01 N - CL A 08 N bell buttons, 20 mA, 12 V AC each Door station with stainless steel per button. front, door loudspeaker and illuminated call buttons.
  • Page 12 4 Appliance overview 1+n Cameras CMC 612-... Colour camera module for the 1+n system. Integrated 2-step heating system, day/night switchover, infrared lighting and video signal transformer. Supply via the video line rectifier VNG 602-... supply to the heating 12 V AC, 100 mA. Supply 20-30 V DC, current consumption max.
  • Page 13 4 Appliance overview 1+n Video distributor VMO 511-2 Video distributor with amplifier, 1 input, 1 output and 1 throughput for integration in 70 mm junction box or distributor mounting. This amplifier is required if several monitors are operated in one system and the coaxial cable is laid as a side circuit, e.g.
  • Page 14 4 Appliance overview 1+n Power supply, line rectifiers NG 602-... Bus line rectifier in a 6-grid housing. Primary: 230 V AC, 50/60 Hz Secondary: 12 V AC, 1.6 A and 23.3 V DC - 0.3 A stabilized. Supply to the 1+n system, door release and lighting for the call button modules.
  • Page 15 4 Appliance overview 1+n Controller SFC 602-... Switching/remote controller in 3-grid housing for the execution of 4 switching/ control functions. 1 relay with changeover contact and 3 relays with 1 working contact each. Actuation using buttons 1–6, light or door release possible. Supply 12 V DC, max.
  • Page 16 4 Appliance overview 1+n DoorCom DCA 612-0 DoorCom-Analog for connection of one or more door stations to an analog PBX extension of a telephone system. Up to 3 call buttons can be connected. 12 V AC supply to terminals b/c, connection to the 1+n system using cores 1 and 7.1-7.3.
  • Page 17 4 Appliance overview 1+n In-house telephones, accessories HTS 811-0 Standard in-house telephone with the functions: • Calling, speech, door release and storey call • Door release and light button • Rotary controller for ring tone volume with integrated muting • Door call as 3-tone call, storey call as 2-tone call •...
  • Page 18 4 Appliance overview 1+n Accessories NS 711-... Secondary signal unit to indicate door and storey calls in large rooms or corridors. Connection to the wire- saving 1+n system. Call volume steplessly adjustable up to max. 86 dB (A). Call differentiation for door calls and storey calls.
  • Page 19 5 Door station installation Door station installation The door loudspeaker module (TLM 612-... and call button module TM 612-...) are each inserted in the relevant terminal block. The circuit diagram illustrates the two terminal blocks of the TLM 612-... and TM 612-...
  • Page 20 5 Installation AS-Ta-64/1 Siedle-Vario...
