Summary of Contents for Sencor SSS 6800 TE
- Page 1 SSS 6800 TE User Manual Bluetooth speaker Uživatelská příručka Bluetooth reproduktor Používateľská príručka Bluetooth reproduktor Felhasználói kézikönyv Bluetooth hangszóró Podręcznik użytkownika Głośnik Bluetooth...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions .................. 3 Supply content ..................6 Description of the BT speaker .............6 Putting into operation ................7 Charging ....................8 LED indicators ..................9 Pairing devices via Bluetooth .............. 9 TWS function ..................10 Power bank feature ................11 Audio AUX-IN ..................12 Play/Pause button .................12 Volume and track playback control ...........13... -
Page 3: Safety Instructions
Safety Instructions This product has been designed with the utmost safety in mind. However, incorrect use may lead to electric shock or fire. This is why users should observe the following instructions when using this device. This device uses a semiconductor unit and contains no user serviceable parts. - Page 4 Connecting other devices Before connecting other devices to this unit, please make sure to disconnect power. Otherwise damage to the unit or personal injury might occur. Faults to be repaired If any of the following problems occurs, please disconnect power to the unit and contact a qualified service technician. Power cord or plug is damaged.
- Page 5 Safety check When done with the maintenance, ask your service technician to perform an on-site safety check to make sure that the unit’s operation is safe. Note: Before using this product, read these instructions carefully and keep it well for future use. EN 5 Copyright ©...
-
Page 6: Supply Content
Supply content Supplied package contents: BT speaker Audio jack 3.5 mm connection cable USB-C charging cable Detachable strap User’s manual Description of the BT speaker 0 qa 6 EN Copyright © 2022, Fast ČR, a. s. Revision 03/2022... -
Page 7: Putting Into Operation
Power on/off button Battery charging status display Source switching (Bluetooth/AUX-IN) „-“/Volume down/previous track button “Play/Pause” button Call answer/reject/hang up/redial Indoor/outdoor mode change „+“/Volume up/next track button Bluetooth connection LED indicator Battery charging level LED indicator Microphone Reset button Charging socket (USB-C) USB port AUX-IN mini jack (3.5mm) socket Putting into operation... -
Page 8: Charging
Charging A charged battery provides power for several hours of operation at normal volume levels. A high volume consumes more battery power; therefore, we recommend listening at normal volume levels. To charge the BT speaker, please connect the charging adapter to the mains and then to the BT speaker. Caution: For charging, use only the original accessories supplied with the appliance. -
Page 9: Led Indicators
Pairing devices via Bluetooth Turn on the BT speaker and search for its Bluetooth name "SSS 6800 TE" in the device to which you wish to pair and start the pairing process. If you are requested to enter a pairing code while your device and the BT speaker are pairing, use the code: “0000”. -
Page 10: Tws Function
TWS function If you buy another Bluetooth speaker („SSS 6800 TE“), you can pair both speakers together for optimum stereo sound. First, make sure your device is not connected to any BT speaker. -
Page 11: Power Bank Feature
It is not possible to pair the device with another type of BT speaker with TWS function, even within re-editions of products with a different Bluetooth name. The TWS on the SSS 6800 TE is not compatible with the SSS 6800 and SSS 6800 SE. Power bank feature The BT speaker can be used as a power bank to charge... -
Page 12: Audio Aux-In
Audio AUX-IN The BT speaker is equipped with a 3.5mm jack. Your device can be connected to the BT speaker via the supplied audio cable. First connect the audio plug to your device and then to the BT speaker’s jack. Caution: Before connecting your device to the BT speaker, please make sure that the output signal from your device is set to its minimum (minimum output volume). -
Page 13: Volume And Track Playback Control
Press the Play/Pause button shortly twice to switch between Indoor and Outdoor playback modes. Note: The reception of the BT speaker’s microphone may be attenuated due to the device’s water resistance. To improve the reception, please speak loud and in the vicinity of the BT speaker. -
Page 14: Ingression Protection (Ipx6)
Ingression protection (IPX6) The unit has an increased water protection class. The IPX6 protection class will protect the device against jets of water. Caution: Remember to always seal the BT speaker’s inputs (No. 8–11 on “BT speaker description“ figure) with the original sealing plug and make sure that the plug is not damaged. -
Page 15: Technical Specifications
Technical specifications Features Waterproof Speaker with IPX6 Protection Premium Fabric Speaker Cover TWS Function (True Wireless Stereo) LED Status Indicator (Connection/Battery Status) Powerbank Function Sound Maximum Speaker Power 60W Total Power Output (RMS) 50W 4 Speakers (2 Bass & Mid-Range, 2 Tweeters) + 2 Passive Radiators Digital Sound Processor DSP Frequency Response: 40Hz - 16KHz... - Page 16 Bluetooth Version Maximum Transmitter 100mW @ 2.4GHz - Power 2.4835GHz Codec Profiles HFP V1.5;A2DP V1.2;AVRCP V1.4,GAVDP V1.2;AVDTP V1.2;SPP V1.2;AVCTP V1.2 16 EN Copyright © 2022, Fast ČR, a. s. Revision 03/2022...
-
Page 17: Instructions And Information About The Disposal Of Discarded Package
INSTRUCTIONS AND INFORMATION ABOUT THE DISPOSAL OF DISCARDED PACKAGE Return the packaging to a collection centre for disposal. DISPOSAL OF DISCARDED ELECTRICAL AND ELECTRONIC EQUIPMENT This symbol placed on the product, accessories or package notifies that the product must not be treated as household waste. - Page 18 FAST ČR, a.s. hereby declares that the radio equipment type SSS 6800 TE conforms to the 2014/53/EU Directive. For full version of the EU declaration of conformity, please refer to www.sencor.eu website. Changes in the text, design and technical specifications may be made without prior notice and we reserve the right to make such changes.
- Page 19 Cases when the claiming product cannot be indentified according to the presented documents (e.g. the serial number or the warranty seal has been damaged). Authorized service centers Visit www.sencor. for detailed information about authorized service centers. EN 19 Copyright © 2022, Fast ČR, a. s.
