Summary of Contents for Sencor SSS 6400N TE SIRIUS
- Page 1 SSS 6400N TE SIRIUS User Manual Bluetooth speaker Uživatelská příručka Bluetooth reproduktor Používateľská príručka Bluetooth reproduktor Felhasználói kézikönyv Bluetooth hangszóró Instrukcja obslugi Głośnik bluetooth...
-
Page 2: Table Of Contents
Table of contents Safety Instructions .................. 3 Supply content ..................6 BT speaker description ................6 Putting into operation ................7 LED indicator ..................8 Pairing devices via Bluetooth .............. 8 TWS function ................... 9 NFC feature .....................10 Audio AUX IN ..................10 Reset button ...................10 Play/Pause button ..................11 Volume and track playback control ............11 Charging ....................12... -
Page 3: Safety Instructions
Safety Instructions This product has been designed with the utmost safety in mind. However, incorrect use may lead to electric shock or fire. This is why users should observe the following instructions when using this device. This device uses a semiconductor unit and contains no user serviceable parts. - Page 4 Connecting other devices Before connecting other devices to this unit, please make sure to disconnect power. Otherwise damage to the unit or personal injury might occur. Faults to be repaired If any of the following problems occurs, please disconnect power to the unit and contact a qualified service technician. Power cord or plug is damaged.
- Page 5 Safety check When done with the maintenance, ask your service technician to perform an on-site safety check to make sure that the unit’s operation is safe. Note: Before using this product, read these instructions carefully and keep it well for future use. EN 5 Copyright ©...
-
Page 6: Supply Content
Supply content BT speaker 3.5mm audio jack Micro USB charging cable User’s manual BT speaker description 6 EN Copyright © 2022, Fast ČR, a. s. Revision 02/2022... -
Page 7: Putting Into Operation
LED indicator NFC chip Audio AUX IN mini jack (3.5mm) socket, Reset button. Charging socket (micro USB) Volume increase button/next track “Play/Pause” button, call answering/rejecting, sound mode changing Volume decrease button/previous track Power On button Putting into operation Before first use, be sure to read the safety instructions contained in this user's manual carefully. -
Page 8: Led Indicator
LED indicator The LED indicator shows the following states of the BT speaker: Blinking blue - the unit is ready to be paired via Bluetooth and the source of the audio signal is not connected Solid blue - the BT speaker is paired with another device via Bluetooth ... -
Page 9: Tws Function
TWS function If you buy another Bluetooth speaker („SSS 6400N TE“), you can pair both speakers together for optimum stereo sound. First, make sure your device is not connected to any BT speaker. Turn on both speakers. If you are using the TWS function for the first time, press the On button twice on one speaker. -
Page 10: Nfc Feature
NFC feature Enable your device’s NFC feature, if equipped, and place your device near the NFC chip on the BT speaker. Follow the instructions on your device. If the connection is established successfully, your device and the BT speaker will be connected automatically. -
Page 11: Play/Pause Button
Play/Pause button Press the Play/Pause button to start or stop music playback during a Bluetooth connection. The incoming call to a Bluetooth connected paired device will be accompanied by an acoustic signal which will interrupt the music being played back. To answer/hang up an incoming call, press the Play/Pause button briefly. -
Page 12: Charging
Charging A charged battery provides power for several hours of operation at normal volume levels. A high volume consumes more battery power; therefore, we recommend listening at normal volume levels. To charge the BT speaker, please connect the charging adapter to the mains and then to the BT speaker. Caution: For charging, use only the original accessories supplied with the appliance. -
Page 13: Ingression Protection (Ipx6)
Ingression protection (IPX6) The unit has an increased protection class. The IPX6 water ingress protection ensures that the unit is protected against splashing water. Caution: Remember to always seal the BT speaker’s inputs with original blind plugs (No.3-4 in figure “description of the BT speaker”) and make sure the plugs are not damaged. -
Page 14: Technical Specifications
Technical specifications Features Water-resistant speaker with IPX6 protection The speaker cover is made of superior fibres Easy connection via NFC TWS function (True Wireless Stereo) Status LED indicator Sound: Maximum speaker output 30 W (Impedance: 4 Ω) Total power output (RMS) 25W 2 speakers + 2 passive radiators Digital Sound Processor (DSP) Frequency response: 80Hz-16kHz... -
Page 15: Instructions And Information About The Disposal Of Discarded Package
Bluetooth: Version 5. 3 Maximum transmitter output power: 100mW @ 2.4GHz-2.4835GHz Codec: SBC Profiles: HFP V1.5;A2DP V1.2;AVRCP V1.4,GAVDP V1.2; AVDTP V1.2;SPP V1.2;AVCTP V1.2 NFC: Operating frequency: 13.56MHz INSTRUCTIONS AND INFORMATION ABOUT THE DISPOSAL OF DISCARDED PACKAGE Return the packaging to a collection centre for disposal. DISPOSAL OF DISCARDED ELECTRICAL AND ELECTRONIC EQUIPMENT This symbol placed on the product, accessories or... - Page 16 The product meets the respective EU requirements. FAST ČR, a.s. hereby declares that the radio equipment type SSS 6400N TE SIRIUS conforms to the 2014/53/EUDirective. For full version of the EU declaration of conformity, please refer to www.sencor.eu website.
- Page 17 Cases when the claiming product cannot be indentified according to the presented documents (e.g. the serial number or the warranty seal has been damaged). Authorized service centers Visit www.sencor. for detailed information about authorized service centers. EN 17 Copyright © 2022, Fast ČR, a. s.
