Basic Operation
Warning: If a power source of 220V is connected to the input voltage
terminal/receptacle, do not connect a110V device to the output load
terminal/receptacle.
Using Receptacles
1. Plug one end of the power cord into the input receptacle and plug the other end into
the wall outlet.
2. Plug the device to be tested into the output load receptacle. The display will show the
W, PF, V, and A for the device under test.
Note 2: W= VA, 1KW = 1KVA = 1000W = 1000VA, when PF = 1.
Warning: The input receptacle and terminal are connected in parallel (as are the
outputs). To avoid electrical shock, do not touch any metal part of the receptacle
or terminal.
d Quality Products Online at:
3
GlobalTestSupply
www.
380801_803-en-GB_V7.4 10/18
