TradeQuip 1002 Procedure

The usual symptoms of a Bottle Jack Workshop Press with air in the bottle jack system are as follows;
-
No resistance in the pump stroke while pumping to the load face [handle feels light].
-
Most of the down stroke of the pump taken up but no movement of the bottle jack Ram.
-
Little or no handle resistance when applying force to the load point.

Bleeding Instructions

Ensure the bottle jack ram is fully retracted prior to performing the following
steps;
1. Carefully loosen the return spring fasteners positioned either side of the
bottle jack, leaving the springs attached by taking tension off the spring.
2. Remove the bottle jack base mount screws and gently remove the jack from
the frame and place on a suitable work bench for the bleeding procedure to
continue.
3. Remove the Filler Bung and if required, refill with *32 Grade Hydraulic until the
oil is lapping the bottom of the filler hole then replace the Filler Bung.
4. Start with the Pump Socket Assembly in the horizontal position.
Bottle Jack Workshop Press
Bleeding Procedure
www.tqbbrands.com.au
Product Code/s: 1002 1060T 1186T
Aug20
