- Page 1 Product Code: 1070T OWNER’S MANUAL PRODUCT CODE: 1070T HYDRAULIC BENCH PRESS 30,000kg Working Capacity Height Width Depth Bed Gap Weight 30,000kg 1490mm 600mm 700mm 530mm 110kg...
-
Page 2: Table Of Contents
Product Code: 1070T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. Failure to observe any of the instructions contained in the manual could result in severe personal injury to the user or bystanders, or cause damage to the equipment and property. Keep this manual in a convenient and safe place for future reference. Whilst every effort has been made to ensure accuracy of information contained in this manual, the TQB Brands Pty Ltd policy of continuous improvement determines the right to make modifications without prior warning. -
Page 3: Safety Instructions
If you detect anything that may indicate imminent structural failure, stop using the hydraulic bench press immediately and inspect thoroughly. Only use this hydraulic bench press on a surface that is stable, level, dry and non-slippery, and capable of sustaining the load. Keep the surface clean, tidy and free from unrelated materials and ensure that there is adequate lighting. Do not use this hydraulic bench press to compress springs or any other item that could disengage and cause a potential hazard. Keep hands and feet away from bed area at all times. Do not modify any component of this equipment. Only use this device for the purpose for which it has been designed. When servicing, use only Tradequip identical replacement parts. Use of any other parts will void the warranty. Use the right product for the job. There are certain applications for which the Hydraulic bench press was designed. Do not modify the Hydraulic bench press and do not use the Hydraulic bench press for a purpose for which it was not intended. Page 3... -
Page 4: Assembly, Operation, Preventitive Maintenance
Product Code: 1070T ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES This 30,000kg Tradequip Hydraulic Workshop Press is great for straightening, stamping, bending and pressing any component that is hard to handle. Polished inner cylinder walls extend the life of the hydraulic seals to minimize abrasion and wear, while the cylinder ram and pistons are also polished and chromed, guided by high performance seals, wear rings and dust seals. Adjustable lower bolster. The hydraulic power unit on this press is conveniently fitted with a gauge to increase safety and piece of mind when tackling larger jobs. Some assembly required. - Page 5 Product Code: 1070T 3. BEFORE USE Prior to each use conduct a visual inspection by checking for abnormal conditions, such as cracked and damaged, loose, or missing parts. Installation Securely attach the press to a flat, firm, level surface taking into account clearance for working pieces. Before operating the press, purge the hydraulic system in order to eliminate any air that may have built up during transit. Open the release valve and pump the handle several times and close the release valve. Should the system malfunction at any time, repeating this process may resolve the problem. DANGER! Models are purpose designed to withstand greater loads than the hydraulic units can develop. For safety reasons, always ensure the workpiece and press tools are secured on the table and will not flex or suddenly “give way” causing danger to operator or the component. Also ensure you have read and understood safety instructions.
- Page 6 Product Code: 1070T 6. MAINTENANCE Check all fittings are tight before each use. Lubricate all moving parts at regular intervals. Always keep the press clean, dry, and protected from harsh conditions. Should you need to replace the oil ensure the piston is fully retracted. An excess of oil will render the press inoperative. Use only appropriate hydraulic jack oil. DO NOT use brake fluid. Contact your local dealer for details. - Purge the system to remove any air. 7. SERVICE & REPAIR Any Hydraulic Workshop Press found damaged in any way, or found to be worn or operates abnormally should be removed from service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product may...
-
Page 7: Parts List
Product Code: 1070T PARTS LIST Part # Description QTY Part # Description QTY Upper Crossbeam Rod Bolt M16x35 Spreader Flat Washer Ø16 Angle Steel Leg Nut M16 Bolt M12x30 Spring Flat Washer Ø12 Bottle Jack Nut M12 Jack Base Socket Head Bolt M8x12 Hook Jack handle Post Brace Flat Washer Ø8 Bolt M10X25 Nut M8 Flat Washer Ø10 Press Plate Nut M10 Press Platform Gauge Page 7... -
Page 8: Warranty
Product Code: 1070T WARRANTY Tradequip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
