04/20
Product Code: 3032T
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment
by
Trade" reliability, 'TradeQuip' branded products offer the very best in performance for an
affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
professional
users.
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
BLASTING UNIT
Specifications
Tank Capacity: 75 Litre
Working Pressure: 60 - 125psi
Air delivery; 400-600 Litres per minute @ 90psi
4 Ceramic Nozzle Tips: 2.0 2.5 3.0 3.5mm
Hose Length: 2400mm
Hose OD: 24mm
Hose ID: 12mm
Wheel Diameter: 150mm
Nett Weight: 23kg
Carton: 880 x 460 x 420mm
Gross Weight: 25kg
Replacement Ceramic Tip Set (4pk) Product #3008/3
Replacement Hose: Product #3008-25
With
proven
and
Product Code: 3032T
MOBILE
trusted "Made
for
the
Advertisement
Related Manuals for TradeQuip 3032T
Summary of Contents for TradeQuip 3032T
- Page 1 Gross Weight: 25kg Replacement Ceramic Tip Set (4pk) Product #3008/3 Replacement Hose: Product #3008-25 About the TradeQuip brand The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment professional users. With proven trusted “Made Trade”...
-
Page 2: Table Of Contents
Keep this manual in a convenient and safe place for future reference. Whilst every effort has been made to ensure accuracy of information contained in this manual, the TradeQuip policy of continuous improvement determines the right to make modifications without prior warning. - Page 3 Product Code: 3032T DO NOT use this machine unless you have been trained and assessed to a competent level in its sate use and operation, and have been given permission to use this Long loose hair must be contained when operating...
-
Page 4: Assembly, Operation & Preventative Maintenance
ASSEMBLY, OPERATION & PREVENTATIVE MAINTENANCE 1. FEATURES The TradeQuip "Made for the Trade" Mobile Abrasive Blasting Kit is perfect for a wide variety of surface preparation jobs such as removing paint, scale, rust and oxidation. Ideal for surface preparation on cars, trucks, machinery, steel, glass etching and much more. - Page 5 Product Code: 3032T Step 4, assembly of the media outlet valve into the opening at the bottom of the tank. Attach in order; nipple connector (17), media metering valve (19B), nipple connector (17), and media outlet pipe (25). Step 5, assembly of the blast gun nozzle. In this assembly process select one of the four nozzles (35/36).
- Page 6 Abrasive Selection: The type of media you choose will greatly influence the amount of time needed to clean a given surface area. TradeQuip’s recommended blasting media materials include garnet, glass beads, steel grit and soda bi-carbonate. Some of these will absorb moisture much more readily than the others depending on the humidity.
- Page 7 Product Code: 3032T To Stop Blasting 1. Whilst continuing to press and hold the blasting gun, turn the abrasive control valve to the closed position 2. When noticing only air is coming through the gun, stop the air flow by releasing the gun To Release Pressure from Tank 1.
-
Page 8: Troubleshooting
Product Code: 3032T TROUBLESHOOTING PROBLEM POSSIBLE CAUSE ACTION Air pressure to low See “lack of air pressure” Surging of Blast Flow Too much media Adjust abrasive control valve Abrasive control valve open too far Close slightly Excessive Media Consumption ... -
Page 9: Parts List Blast Gun Nozzle
Product Code: 3032T PARTS LIST BLAST GUN NOZZLE Part # Description Part # Description Body Upper Screw ST 4.2x12 Body Lower On/Off Control Lever Metal Pipe Spring Pin Intake Connector Spring Adaptor Rubber Pad Gasket Screw M3x25 Ceramic Nozzle Hard Alloy Pad... -
Page 10: Parts List
Product Code: 3032T PARTS LIST Part # Description Part # Description Tank Water Trap Wheels 3/8” Brass Air Supply Valve Cotter Pin 3/8” Brass Throttling Valve Front Arm 3/8” Steel Abrasive Control Valve Wheel Axle Air Inlet Connector Handle Bar... -
Page 11: Warranty
WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
