TradeQuip 9845 Owner's Manual

24v 1/2" drive cordless impact wrench
Hide thumbs

Advertisement

Quick Links

Download this manual
Product Code: 9845
OWNER'S MANUAL
PRODUCT CODE: 9845
24V 1/2" DRIVE CORDLESS IMPACT WRENCH
Battery
Charge
Maximum
Impact
No-Load
LED
Power
Time
Torque
Rate
Speed
Work Light
2x 24V Li
1 Hour
450Nm
0-3,000min
0-2,200min
Yes
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9845 and is the answer not in the manual?

Questions and answers

Related Manuals for TradeQuip 9845

Summary of Contents for TradeQuip 9845

  • Page 1 Product Code: 9845 OWNER’S MANUAL PRODUCT CODE: 9845 24V 1/2" DRIVE CORDLESS IMPACT WRENCH Battery Charge Maximum Impact No-Load Power Time Torque Rate Speed Work Light 2x 24V Li 1 Hour 450Nm 0-3,000min 0-2,200min Made in China to TQB Brands Pty Ltd specifications...
  • Page 2 Product Code: 9845 WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this power tool. Do not allow anyone to use or operate this power tool until they have read this manual and have developed a thorough understanding of how this tool works.
  • Page 3 Product Code: 9845 SAFETY INSTRUCTIONS WARNING FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL INJURY. SAFETY OPERATNG INSTRUCTIONS The term "power tool" in the warnings refers to your battery-operated (cordless) power tool.  Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust.
  • Page 4 Product Code: 9845  Use personal protective equipment. Always wear eye protection. Protective equipment such as a hearing protection, hand protection and non-skid safety shoes for appropriate conditions will reduce personal injuries.  Prevent unintentional starting. Ensure the switch is in the off-position before picking up or carrying the power tool.
  • Page 5 Product Code: 9845 Batteries  Never attempt to open the battery for any reason.  Do not store in locations where the temperature may exceed 45°C.  Charge only at ambient temperatures between 4°C and 45°C.  Charge only using the compatible charger for this battery.
  • Page 6 Product Code: 9845 Chargers  Only use the charger suitable for this tool to charge the battery pack  Never attempt to charge non-rechargeable batteries.  Have defective cords replaced immediately.  Do not expose to water.  Do not open the charger.
  • Page 7 The 2.0Ah battery packs deliver more work per charge and longer pack life. The 9845 Cordless 1/2in Drive Impact Wrench features a 1/2in. pin detent anvil for maximum socket retention, an LED light to illuminate work surfaces, and includes 2 Lithium Ion 2.0Ah batteries, 240V fast charger and carrying case.
  • Page 8 Product Code: 9845 3. ASSEMBLY Selecting correct socket Always use the correct size socket for bolts and nuts. An incorrect size socket will result in inaccurate and inconsistent fastening torque and /or damage to the bolt or nut. Installing or removing socket ...
  • Page 9 Product Code: 9845 4. OPERATION Charging the battery pack (Fig. 2) The battery packs for this power tool will be supplied in a low charge condition to prevent possible problems, therefore, you have to charge the battery pack before first use.
  • Page 10 Product Code: 9845 Direction of rotation (Fig. 6)  To select forward rotation, release the ON/OFF switch trigger (6) and push the forward/reverse knob (2) to the left side of the tool.  To select reverse rotation, push the forward/reverse knob (2) to the right side of the tool.
  • Page 11 Product Code: 9845 7. MAINTENANCE  Always REMOVE THE BATTERY PACK before clean or repair.  Always be sure that the tool is switched off and battery pack is removed before performing any inspection ,maintenance or cleaning.  Keep the ventilation slots of the machine free from dust and dirt to prevent overheating of the engine.
  • Page 12 Product Code: 9845 WARRANTY Tradequip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
