EVK-JODY-W2

Evaluation kit for JODY-W2 host-based modules

User guide

Abstract

This document describes how to set up the EVK-JODY-W2 evaluation kit used to evaluate JODY-W2

series multiradio modules with Wi-Fi and Bluetooth.

UBX-19027118 - R06

C1 - Public

www.u-blox.com

Need help?

Do you have a question about the EVK-JODY-W2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ublox EVK-JODY-W2

Page 1 EVK-JODY-W2 Evaluation kit for JODY-W2 host-based modules User guide Abstract This document describes how to set up the EVK-JODY-W2 evaluation kit used to evaluate JODY-W2 series multiradio modules with Wi-Fi and Bluetooth. UBX-19027118 - R06 C1 - Public www.u-blox.com...
Page 2 EVK-JODY-W2 - User guide Document information Title EVK-JODY-W2 Subtitle Evaluation kit for JODY-W2 host-based modules Document type User guide Document number UBX-19027118 Revision and date 9-Nov-2022 Disclosure restriction C1 - Public This document applies to the following products: Product name...
Page 3 EVK-JODY-W2 - User guide Contents Document information ..........................2 Contents ................................3 Kit description ............................4 1.1 Overview ................................ 4 1.2 Kit includes ..............................5 1.3 Software ................................ 6 1.3.1 Driver source code ..........................6 1.4 System requirements ..........................7 1.5 Operating conditions ..........................
Page 4 Wi-Fi, Bluetooth, and Bluetooth Low Energy (LE) communication, and are ideal for automotive and industrial applications. EVK-JODY-W2 allows an external host processor to access several practical features for testing and evaluating the Wi-Fi and Bluetooth connectivity supported in JODY-W2 series modules, including: •...
Page 5 EVK-JODY-W2 - User guide 1.2 Kit includes Connectors for the use of different interfaces of the module are included in the evaluation kit. Table 2 shows the various components included in the EVK-JODY-W2. Part Description Outline Evaluation board (EVB) Evaluation board for JODY-W263 series modules.
Page 6 EVK-JODY-W2 - User guide 1.3 Software JODY-W2 series modules are based on the NXP 88W8987 chipset family. The drivers and firmware required to operate JODY-W2 series modules are developed by NXP and are already integrated into the Linux BSP for the NXP i.MX application processors and the MCUXpresso SDK for NXP MCU devices [8].
Page 7 ºC Ripple Noise Peak-to-peak voltage ripple on all supply lines. Table 3: EVK-JODY-W2 operating conditions ☞ The signal voltage for the SDIO interface of the JODY-W2 series module is powered from the 1V8 supply. A level shifter is required to operate the module in default Speed and High-Speed modes at 3.3 V signal voltage.
Page 8 ANT400 ANT401 J406 J408 J410 Figure 2: EVK-JODY-W2 connectors 2.1 Jumpers and connectors Table 4 provides a summary of the connectors and jumpers used to configure EVK-JODY-W2. UBX-19027118 - R06 Contents Page 8 of 25 C1 - Public...
Page 9 EVK-JODY-W2 - User guide Designator Connector Description J104-J106 Power supply selection Jumper settings for external power supply configuration (3.3.1) (power mux) J1 - J7 Input voltage Jumper settings for selecting the input voltage for the module (3.3.2) configuration J204 SDIO Connector ZIF connector for SDIO host interface on EVB (3.5)
Page 10 2.4 Host interface for Wi-Fi (3.3 V HS) By default, EVK-JODY-W2 operates with host interface voltage of 1.8 V. For the designs with host interface voltage 3.3 V, a level shifter is needed to convert the voltage level of the SDIO signals. Only SDIO High Speed (HS) mode is supported when using a 3.3 V interface voltage.
Page 11 EVK-JODY-W2 - User guide These resistors must be connected in vertical positions. Figure 5: Resistor modification to enable host connection through an adapter 2.5 Host interface for Bluetooth JODY-W2 series modules support a high-speed UART interface for Bluetooth communication. A USB-to-UART bridge (FTDI FT231X) is included on the evaluation board. Follow the procedure outlined below to connect the board to a host system through USB.
Page 12 EVK-JODY-W2. 3.1 Block diagram EVK-JODY-W2 design is organized between the module board and carrier board. The carrier board includes all the necessary peripherals and connectors. It also includes a slot for mounting the module board. The module board holds the JODY-W2 module.
Page 13 USB: If Bluetooth is connected through USB, the bus can also be used as a power supply. • External power supply: EVK-JODY-W2 can be powered by an external 5 V to 24 V supply using a terminal connector or power jack. In this case, a DC-DC converter is used for generating all the required internal voltages.
Page 14 EVK-JODY-W2 - User guide Figure 9 shows the external connectors and jumpers used for configuring the different power supply options. Jumper for power supply selection, for example via SDIO Power supply interface status LEDs Pins for voltage measurements Single external power...
Page 15 EVK-JODY-W2 - User guide Figure 10: EVB power supply tree ☞ The PCIe interface is not supported on JODY-W2 modules. 3.3.1 Selecting the EVB power supply Use jumpers J104–J106 to select the EVB power supply (power mux) for the EVB.
Page 16 EVK-JODY-W2 - User guide Table 5 shows the (J104–J106) jumper positions for selecting the power supply source for the EVB. Input voltage Jumper configuration 3.3 V from SDIO interface. Use SDIO adapter with the flat cable to connect to the host.
Page 17 EVK-JODY-W2 - User guide The input voltage options for selecting the JODY-W2 module supply are described in Table 6Error! Reference source not found.. Designator Module supply Source VBAT Can be connected to 3V3_DCDC or 3V3_EXT Can be connected to 1V8_VIO or VIO_EXT...
Page 18 EVK-JODY-W2 - User guide 3.4 Bootstrapping JODY-W2 supports the following host interface combinations: • SDIO-UART mode: Commands and data for the Wi-Fi traffic are transferred through the SDIO bus to the module. The Bluetooth traffic uses the high-speed UART interface.
Page 19 EVK-JODY-W2 - User guide Figure 14: SDIO interface connector All signals except VDD_SDIO are directly connected to the JODY-W2 module through 22 Ω series resistors connected on module board. VDD_SDIO is connected to the power supply connector (J105) and is used for supplying 3.3 V for VBAT from the SDIO interface.
Page 20 EVK-JODY-W2 - User guide Name Description Remarks UART_TXD UART TX signal Connect to Host RX UART_RXD UART RX signal Connect to Host TX UART_RTS UART RTS signal Connect to Host CTS UART_CTS UART CTS signal Connect to Host RTS Table 9: UART signal description...
Page 21 EVK-JODY-W2 - User guide 3.8 Control lines Connectors J301 and J303 provide several other interfaces from the JODY-W2 series module, such as host wake-up signals, GPIOs, and audio interfaces. See Schematics for more information. Pin no Module pin no Signal...
Page 22 Figure 18: Connection of pig-tail coaxial cables with the U.FL connectors for internal antennas (left) or SMA connectors (right). 3.10 LEDs Table 14 describes the function and description of the available LEDs on the EVK-JODY-W2 evaluation board. Function Description Designator...
Page 23 EVK-JODY-W2 - User guide 3.11 Schematics The schematics for the JODY-W2 evaluation board (carrier board, module board and level shifter) can be shared with the customers upon request. Contact your local support team for further information. UBX-19027118 - R06 Contents...
Page 24 EVK-JODY-W2 - User guide Appendix A Glossary Abbreviation Definition Evaluation board Evaluation kit Host controller interface Input / output Inter-Integrated circuit sound Light-Emitting Diode Low-dropout regulator Low-power oscillator Long-Term Evolution Medium access control MIMO Multiple input multiple output Multimedia card...
Page 25 4-Dec-2020 aheg Added full-sized SDIO adapter in Table 2: EVK-JODY-W2 component list; revised Wi- Fi host interface in sections 2.3 and 2.4; revised Figure 6 and Figure 18 to show carrier and module and pig-tail coaxial cable connections with U.FL adapters; removed obsolete WLAN/BT LED notifications in Table 14;...
