INSTRUCTIONS FOR SIOUX 1290, 1290LK, 1290L, & 1297 SANDERS
Read and understand these instructions before operating this tool.
Everyone using, maintaining, changing accessories or working near this tool must read, understand and follow these Safety Instructions!
Tools left connected to the air supply while making adjustments, changing accessories, or doing any maintenance or service on tool
Always remove tool from air supply and activate trigger to bleed air line before making any adjustments, changing accessories, or
AIR SUPPLY
The efficiency and life of this tool depend on the proper supply of clean, dry, lubricated air at a maximum of 90 psig (6.2 bars) max. The use of a line filter,
pressure regulator, and lubricator is recommended.
Before connecting the tool to the air line, blow out the line to remove any water or dirt which may have accumulated.
HOSE AND HOSE CONNECTIONS
A 3/8" (10 mm) I.D. air supply hose is recommended. Extension hoses should not be less than 1/2" (13 mm) I.D.
3/8" (10 mm) I.D. couplings and fitting are recommended.
LUBRICATION
Air Motor
Use Sioux No. 288 air motor oil. An airline lubricator, set to deliver 1 to 2 drops per minute is recommended. If an airline lubricator is not used, add .08 oz (2.4
cc, 25 to 30 drops) of oil to the air inlet twice daily.
Gear Case
Lubricate the gears after every 40 hours of operation with Sioux 1232 grease. Lubricate the gears through the grease fitting at the end of the spindle.
GENERAL OPERATION
Start the tool by depressing the trigger or lever.
Maintain a slight angle between the sanding disc and the work.
Do not use excessive pressure. Excessive pressure will cause the tool to slow down. Sanders work best at higher speeds.
To install a sanding disc:
INSTRUCTIONS FOR BACKING PAD
1. Place disc holder, backing disc and retainer on to the spindle.
2. Place the abrasive disc on to the spindle.
3. Thread the lock nut on to the spindle.
4. Hold the spindle with the 1" (24.5 mm) open wrench and turn the abrasive disc until it is tight on the spindle.
250 Snap-on Drive • PO Box 1596 • Murphy, NC 28906 • USA • Phone: 828-835-9765 •www.siouxtools.com
Form ZCE480
SAVE THESE INSTRUCTIONS!
WARNING
When used improperly power tools can create hazardous situations.
Improperly used power tools can cause injury or death.
WARNING
This sander is not guarded for use with a grinding wheel.
Do not operate this sander with a grinding wheel.
Operating this sander with a grinding wheel can cause injury.
WARNING
doing any maintenance or service on tool.
Tools starting unexpectedly can cause injury.
WARNING
Always remove the tool from the air supply be for installing or changing sanding discs!
DISC
TOOL
HOLDER
SPINDLE
Original
Instructions
can start unexpectedly.
BACKING
ABRASIVE
DISC
DISC
RETAINER
LOCK NUT
1
Form ZCE480
Date 2003June20/C
Page 1 of 16
2003June20/C
Date

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1290 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sioux Tools 1290

Summary of Contents for Sioux Tools 1290

  • Page 1 Form ZCE480 Original Instructions Date 2003June20/C Page 1 of 16 INSTRUCTIONS FOR SIOUX 1290, 1290LK, 1290L, & 1297 SANDERS Read and understand these instructions before operating this tool. SAVE THESE INSTRUCTIONS! WARNING When used improperly power tools can create hazardous situations.

  • Page 2: Declaration Of Conformity

    *per ISO 8662-4 DECLARATION OF CONFORMITY We, Sioux Tools Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, declare under our sole responsibility that the products 1290, 1290-3000, 1290B, 1290B3000, 1290LK, 1290LT, 1290LKX, 1290X to which this declaration relates are in conformity with the following standard or standards or other normative document or documents: EN 792 (draft), EN 292 Parts 1&2, ISO 8662, Pneurop PN8NTC1...
  • Page 3 Übersetzung Der Original Anleitungen ANWEISUNGEN FÜR SIOUX SCHWINGSCHLEIFER 1290, 1290LK, 1290L UND 1297 Lesen Sie diese Bedienungsanleitung, bevor Sie dieses Werkzeug in Betrieb nehmen. BEWAHREN SIE DIESE ANLEITUNG AUF! WARNUNG Unsachgemäßer Gebrauch von Werkzeugen kann zu gefährlichen Situationen führen. Jede Person, die dieses Werkzeug gebraucht, wartet, Zubehör auswechselt oder in der Nähe dieses Werkzeugs arbeitet, muss diese Sicherheitshinweise lesen, verstanden haben und befolgen! Unsachgemäßer Gebrauch von Werkzeugen kann zu Verletzungen oder zum Tod führen.
  • Page 4 *per ISO 8662-4 KONFORMITÄTSERKLÄRUNG Wir, Sioux Tools, Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, erklären hiermit alleinverantwortlich, daß die Produkte 1290, 1290-3000, 1290B, 1290B3000, 1290LK, 1290LT, 1290LKX, 1290X auf die sich diese Erklärung bezieht, mit den Anforderungen der folgenden Standards oder Normen oder Dokumenten übereinstimmen: EN 792 (Entwurf) EN 292 Teile 1&2, ISO 8662, Pneurop PN8NTC1...

  • Page 5: Aspectos Generales

    Traducción De Las Instrucciones Originales INSTRUCCIONES PARA LIJADORAS SIOUX 1290, 1290LK, 1290L y 1297 Lea y entienda estas instrucciones antes de usar esta herramienta. ¡NO PIERDA ESTAS INSTRUCCIONES! ADVERTENCIA Una herramienta motorizada puede ser peligrosa si no se usa correctamente.

  • Page 6: Declaracion De Conformidad

    *según PN8NTC1 *según ISO 8662-4 DECLARACION DE CONFORMIDAD Nosotros, Sioux Tools, Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, declaramos bajo nuestra única responsabilidad que los productos 1290, 1290-3000, 1290B, 1290B3000, 1290LK, 1290LT, 1290LKX, 1290X con los cuales se relaciona esta declaración están en conformidad con las siguiente(s) norma(s) u otro(s) documento(s) normativo(s): EN 792 (anteproyecto) EN 292 Partes 1&2, ISO 8662, Pneurop PN8NTC1...
  • Page 7 Traduzione Delle Istruzioni Originali ISTRUZIONI PER LE LEVIGATRICI SIOUX 1290, 1290LK, 1290L, e 1297 Leggere attentamente queste istruzioni prima di usare l'attrezzo. CONSERVARE QUESTE ISTRUZIONI! AVVERTIMENTO Utensili a motore non usati correttamente possono creare condizioni di rischio.. Chiunque usi, mantenga, sostituisca accessori o lavori vicino a quest’utensile deve leggere attentamente e seguire queste istruzioni di sicurezza! L’uso diverso dal previsto di questi utensili a motore può...
  • Page 8 *secondo ISO 8662-4 CERTIFICAZIONE DI CONFORMITA’ La Sioux Tools, Inc, con sede al 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, solennemente dichiara sotto la propria e sola responsabilità che i prodotti 1290, 1290-3000, 1290B, 1290B3000, 1290LK, 1290LT, 1290 LKX, 1290X...

  • Page 9: Fonctionnement General

    Traduction Des Instructions Originales INSTRUCTIONS POUR PONCEUSES 1290, 1290LK, 1290L, & 1297 Veuillez lire et comprendre ces instructions avant d'utiliser cet outil. CONSERVEZ CES INSTRUCTIONS ! AVERTISSEMENT Une utilisation incorrecte d’outils électriques risque d’engendrer des situations dangereuses. Toute personne susceptible d’utiliser, d’entretenir, de remplacer des accessoires ou de travailler à proximité de cet outil doit avoir lu et compris les instructions de sécurité...

  • Page 10: Declaration De Conformite

    *selon la norme ISO 8662-4 DECLARATION DE CONFORMITE La société Sioux Tools, Inc., située à : 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, affirme que les produits 1290, 1290-3000, 1290B, 1290B3000, 1290LK, 1290LT, 1290LKX, 1290X dont cette fiche fait l’objet, sont conformes aux normes, documents normatifs et autres références : EN 792 (ébauche) Parties 1 et 2 de la norme EN 292, ISO 8662, Pneurop PN8NTC1...
  • Page 11 Vertaling Van De Oorspronkelijke Instructies INSTRUCTIES VOOR SIOUX SCHUURMACHINES 1290, 1290LK, 1290L, & 1297 Zorg dat u deze instructies hebt gelezen en begrepen voordat u dit gereedschap gebruikt. BEWAAR DEZE INSTRUCTIES! WAARSCHUWING Bij verkeerd gebruik kunnen elektrische werktuigen gevaarlijke situaties teweegbrengen.
  • Page 12 *conform PN8NTC1 *conform ISO 8662-4 CONFORMITEITSVERKLARING Ondergetekende, Sioux Tools, Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, verklaart met inachtneming van de eigen aansprakelijkheid desbetreffend, dat de produkten 1290, 1290-3000, 1290B, 1290B3000, 1290LK, 1290LT, 1290LKX, 1290X waarop deze verklaring van toepassing is, conform zijn met de hierna genoemde norm, normen en/of andere regels en voorschriften:...
  • Page 13 Översätt Från Original Instruktionerna ANVISNINGAR FÖR SIOUX 1290, 1290LK, 1290L, & 1297 YTSLIPNINGSMASKINER Läs och förstå dessa anvisningar innan du använder detta verktyg. SPARA DESSA ANVISNINGAR! VARNING Felaktig användning av motordrivna verktyg kan förorsaka risksituationer. Alla som använder, underhåller, byter tillbehör på eller arbetar nära detta verktyg måste läsa, sätta sig in i och följa dessa säkerhetsanvisningar!

  • Page 14: Försäkran Om Överensstämmelse

    *enligt ISO8662-4 FÖRSÄKRAN OM ÖVERENSSTÄMMELSE Vi, Sioux Tools, Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, förklarar under eget ansvar att produkterna 1290, 1290-3000, 1290B, 1290B3000, 1290LK, 1290LT, 1290LKX, 1290X som denna försäkran gäller uppfyller följande standard eller standarder eller andra normgivande dokument:...
  • Page 15 MEMO 2003June20/C Form ZCE480 Date...
  • Page 16 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. WARNUNG Der durch Elektrosanden, -sägen, -schleifen und -bohren sowie durch andere Bauarbeiten anfallende Staub enthält Chemikalien, die nachweislich Krebs sowie Geburts- bzw.
  • Page 17 This pdf incorporates the following model numbers: 1290, 1290L, 1290LK, 1297...
