INSTRUCTIONS FOR SIOUX 1292, 1296, 1292L, 1296L POLISHERS
Read and understand these instructions before operating this tool.
Everyone using, maintaining, changing accessories or working near this tool must read, understand and follow these Safety Instructions!
Make sure polishing pad has a higher speed rating than the tool. Do not exceed rated air pressure.
Tools left connected to the air supply while making adjustments, changing accessories, or doing any maintenance or service on tool
Always remove tool from air supply and activate trigger to bleed air line before making any adjustments, changing accessories, or
AIR SUPPLY
The efficiency and life of this tool depend on the proper supply of clean, dry, lubricated air at a maximum of 90 psig (6.2 bars) max. The use of a line filter,
pressure regulator, and lubricator is recommended.
Before connecting the tool to the air line, blow out the line to remove any water or dirt which may have accumulated.
HOSE AND HOSE CONNECTIONS
A 3/8" (10 mm) I.D. air supply hose is recommended. Extension hoses should not be less than 1/2" (13 mm) I.D. 3/8" (10 mm) I.D. couplings and fitting are
recommended.
LUBRICATION
Use Sioux No. 288 air motor oil. An airline lubricator, set to deliver 1 to 2 drops per minute is recommended. If an airline lubricator is not used, add .08 oz (2.4
cc, 25 to 30 drops) of oil to the air inlet twice daily.
GENERAL OPERATION
Start tool by depressing trigger or lever.
We, Sioux Tools Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, declare under our sole responsibility that the products
to which this declaration relates are in conformity with the following standard or standards or other normative document or documents:
June 1, 2003
Murphy, North Carolina, USA
Date and place of issues
250 Snap-on Drive • PO Box 1596 • Murphy, NC 28906 • USA • Phone: 828-835-9765 •www.siouxtools.com
Form ZCE483
SAVE THESE INSTRUCTIONS!
When used improperly power tools can create hazardous situations.
Improperly used power tools can cause injury or death.
This polisher is not guarded for use with a grinding wheel.
Do not operate this polisher with a grinding wheel.
Operating this polisher with a grinding wheel can cause injury.
Polishing pads that rotate at excessive speed can burst.
Polishing pads that burst can cause injury.
doing any maintenance or service on tool.
Tools starting unexpectedly can cause injury.
SOUND AND VIBRATION READINGS
Catalog No. *Sound Pressure dBA
1292 80.2
1296 80.2
1292L 80.2
1296L 80.2
*per PN8NTC1
DECLARATION OF CONFORMITY
1292, 1296, 1292L, 1296L
EN 792 (draft), EN 292 Parts 1&2, ISO 8662, Pneurop PN8NTC1
following the provisions of
89/392/EEC as amended by 91/368/EEC & 93/44/EC Directives.
Gerald E. Seebeck
Name and position of issuer
Original
Instructions
WARNING
WARNING
WARNING
WARNING
can start unexpectedly.
*Sound Power dBA
92.6
92.6
92.6
92.6
*per PN8NTC1
President
Sioux Tools Inc.
1
Form ZCE483
Date 2003 June 23/C
Page 1 of 8
*Vibration m/s
2
7.5
7.5
7.5
7.5
*per ISO 8662-8
Signature of issuer
2003 June 23/C
Date
