Device Markings (Symbols)
Certain markings (symbols) can be found on the product and are defined as follows:
Symbol
CE marking: the device conforms to the requirements of applicable EC directives.
UKCA marking: the device conforms to the requirements of applicable Great Britain regulations.
Products must be disposed of at the end of their useful life according to local regulations.
UL marking: conforms to the requirements of the UL certification.
FCC marking: This device complies with FCC rules part 15, class B.
For indoor use only
Class III electrical appliance
Lead-free
Dimensions
Ø40 [1.6]
Millimeters [Inches]
Mounting Instructions
This product can be mounted directly into suspended ceiling, fixed by a supplied rear spring.
The EOL Termination and Subnet ID must be set before this product is installed. To do so, see
Topology and EOL Terminations [pg. 4]
1. Drill a Ø 1.3" (32 mm) hole into the suspended ceiling.
2. Introduce the product through the hole (recessed part first).
2 / 7
Description
Ø32 [1.3]
and
Device Addressing
[pg. 4].
25.0 [1.0]
3.7 [0.1]
8 [0.3]
33.4 [1.3]
Subnetwork Bus
