G3S21_02 LATERAL
RAISE (GM12C)
STRENGTH
SERVICE MANUAL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LATERAL RAISE STRENGTH G3S21 02 and is the answer not in the manual?

Questions and answers

Related Manuals for Matrix LATERAL RAISE STRENGTH G3S21 02

Summary of Contents for Matrix LATERAL RAISE STRENGTH G3S21 02

  • Page 1 G3S21_02 LATERAL RAISE (GM12C) STRENGTH SERVICE MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CHAPTER 1: SERIAL NUMBER LOCATION …………………………………..3 CHAPTER 2: ASSEMBLY INSTRUCTIONS 2.1 G3S21_02 Lateral Raise Assembly Instructions............4 CHAPTER 3: TROUBLESHOOTING 3.1 Troubleshooting - Belt issues ……………………………………………….….. …...11 Troubleshooting - The incremental adjustment rod is deflection .…….….. 12 CHAPTER 4: PART REPLACEMENT INSTRUCTIONS 4.1 Hand Grip Foam Replacement................13 4.2 Seat Pad Replacement..................14 4.3 Back Pad Replacement..................14...

  • Page 3: Chapter 1: Serial Number Location

    CHAPTER 1: SERIAL NUMBER LOCATION 1.1 SERIAL NUMBER LOCATION The serial number is located at the bottom of the weight stack frame.

  • Page 4: Chapter 2: Assembly Instructions

    2.1 G3S21_02 LATERAL RAISE ASSEMBLY INSTRUCTIONS UNPACKING G3S21_02 LATERAL RAISE Thank you for purchasing a MATRIX Fitness product. This machine is an EN957-1 and EN957-2 complaint Class S product. Your MATRIX G3S21_02 LATERAL RAISE is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact packaging of the machine. Prior to assembly, confirm all the components by matching them with the exploded diagrams.
  • Page 5 THE STANDARD OF THE SCREW TORQUE Nom Diameter Torque (kg/cm) Torque (lbs/in) 1380 1197 2190 1901 3420 2968 4700 4079 2.1 G3S21_02 LATERAL RAISE ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 6 2.1 G3S21_02 LATERAL RAISE ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 7 2.1 G3S21_02 LATERAL RAISE ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 8 2.1 G3S21_02 LATERAL RAISE ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 9 2.1 G3S21_02 LATERAL RAISE ASSEMBLY INSTRUCTIONS - CONTINUED...
  • Page 10 2.1 G3S21_02 LATERAL RAISE ASSEMBLY INSTRUCTIONS - CONTINUED...

  • Page 11: Chapter 3: Troubleshooting

    CHAPTER 3: TROUBLESHOOTING 3.1 TROUBLESHOOTING - BELT ISSUES BELT IS LOOSE POSSIBLE CAUSES 1. The belt fix bolts are loose. SOLUTION 1. Tighten the 4 bolts of the flat belt plate. Torque required 49 lbs/in (Figure A). 2. Loosen the 2 bolts on the top weight plate (Figure B). 3.

  • Page 12: Troubleshooting - The Incremental Adjustment Rod Is Deflection

    3.2 TROUBLESHOOTING – INCREMENTAL ADJUSTMENT ROD ISSUES THE INCREMENTAL ADJUSTMENT ROD IS DEFLECTION POSSIBLE CAUSES 1. The incremental adjustment rod fix bolts are loose. 2. The incremental adjustment rod is bent at an incorrect angle. SOLUTION 1. Tighten the 2 bolts of the incremental adjustment rod. Torque required 84 lbs/in (Figure A). 2.

  • Page 13: Chapter 4: Part Replacement Instructions

    CHAPTER 4: PART REPLACEMENT INSTRUCTIONS 4.1 HAND GRIP FOAM REPLACEMENT 1) To loose the screws of end cap of handlebar (Figure A). 2) To take off the end cap and cut off the original foam (Figure B). 3) Using tape to seal up the handlebar tube to avoid the oil or suds into the tube (Figure C). 4) To bent and hold the end of foam then put oil or suds into the inside of foam (Figure D).

  • Page 14: Seat Pad Replacement

    4.2 SEAT PAD REPLACEMENT 1) Using 8MM L-Shaped Allen Wrench to take off 3 bolts of the old seat pad (Figure A) 2) Replace new pad and fix the 3 bolts (Figure B). FigureA Figure B 4.3 BACK PAD REPLACEMENT 1) Using 8MM L-Shaped Allen Wrench to take off 4 bolts of the old back pad (Figure A) 2) Replace new pad and fix the 4 bolts (Figure B).

  • Page 15: Head Pad Replacement

    4.4 HEAD PAD REPLACEMENT Using 8MM L-Shaped Allen Wrench to take off 4 bolts of the old head pad (Figure A) 2) Replace new pad and fix the 4 bolts (Figure B). Figure A Figure B 4.5 HAND PAD REPLACEMENT 1) Using 8MM L-Shaped Allen Wrench to take off 4 bolts of the old hand pad (Figure A) 2) Replace new pad and fix the 4 bolts (Figure B).

  • Page 16: Seat Pad Adjustment Handle Replacement

    4.6 SEAT PAD ADJUSTMENT PIN REPLACEMENT 1) Please disconnect the stopper screw , then take out the seat sleeve (Figures A & B ). 2) Loose the screw with Phillips Screwdriver and take out the cap. (Figure C & D) 3) Remove the C ring with C ring plier (Figure E) 4) Loose two screws and in the same time prevent the small metal plate from drop with you finger.
  • Page 17 Figure (E ) Figure (F) Figure (G) Figure (H) Figure ( J ) Figure ( K )

  • Page 18: Seat Sleeve Replacement

    4.7 SEAT SLEEVE REPLACEMENT 1） Please disconnect the stopper screw , then take out the seat sleeve (Figures A & B ). 2) Loose the screw with Phillips Screwdriver and take out the cap. (Figure C & D) 3) Remove the C ring with C ring plier (Figure E) 4) Loose two screws and in the same time prevent the small metal plate from drop with you finger.
  • Page 19 Figure (E ) Figure (F) Figure (G ) Figure (H ) Figure (J) Figure (K )
  • Page 20 Figure (L) Figure (M) Figure (N) Figure (O) Figure ( P ) Figure ( Q )
