- Page 1 UFO LIGHTING FIBRE OPTIC & LED LIGHTING SYSTEMS REVISION MICROLED 2000 LIGHT SOURCE USER GUIDE PLEASE READ THIS USER GUIDE BEFORE INSTALLING OPERATING OR PERFORMING MAINTENANCE ON THE LIGHT SOURCE UNIT...
- Page 2 Please read these instructions fully before connecting your unit to the electrical supply, and keep them for future reference. The UFO MicroLED range of light sources utilises an RGBW LED array and is suitable for use with either glass or polymer fibre-optic harness The MicroLED is powered by a 100-240 VAC remote desktop power supply unit.
-
Page 3: Installation
Unit. Remove the SW4047B desk top PSU from its box. This PSU is a multi-plug device catering for UK, European and USA plugs. DO NOT FIT BATTERIES TO THE REMOTE CONTROL UNTIL YOU HAVE FULLY READ THE INSTRUCTIONS ON PAGE 4 UFO LIGHTING... - Page 4 White is displayed. The light source is now in Cycle 1 speed A as detailed below. Each push reduces the speed. On the third push the colour Red will be displayed. The light source is now in Cycle 2 speed A. MICROLED 2000 USER GUIDE...
-
Page 5: Dmx Operation
Pin no. White White White White Colour Orange Blue Green Brown Orange Green Blue Brown DMX+ DMX Function Spare Spare Spare Spare Ground Ground (HOT) (COLD) DMX XLR Pin 3 Pin 2 Pin 1 Pin 1 Equivalent UFO LIGHTING... - Page 6 From OFF at 0 to BRIGHT AT 255 Colour GREEN 0255 From OFF at 0 to BRIGHT at 255 Colour BLUE 0255 From OFF at 0 to BRIGHT AT 255 Colour WHITE 0255 From OFF at 0 to BRIGHT at 255 MICROLED 2000 USER GUIDE...
- Page 7 Congo (B93) Violet (V43) Magenta (M56) Pink (M63) White Please note that Canary (bright yellow) is difficult to achieve using the composite colours, and as such is a poor match. UFO LIGHTING...
-
Page 8: Maintenance Log
MAINTENANCE MAINTENANCE LOG Date Maintenance Undertaken Note: A record of all maintenance MUST be kept in the table above, indicating what maintenance was undertaken and when. This MUST be dated for warranty purposes. MICROLED 2000 USER GUIDE... -
Page 9: Troubleshooting
PSU failed Replace PSU Unit is dead no LED array failure Contact UFO light output but LED power Recycle power to light source or switch on Switched off via remote control unit indicator is still... -
Page 10: Technical Specifications
2.1 x 5.5 x 12mm Remote Control Range 30m, depending on environment Remote Control Power 2 x AAA batteries Material Aluminum Finish Anodised Silver Dimensions (L x W x H) / Weight (L) 190mm x (W) 68mm x (H) 75mm MICROLED 2000 USER GUIDE... - Page 11 NOTES UFO LIGHTING...
- Page 12 NOTES UFO LIGHTING...
- Page 13 • DESIGN SPECIFY BUILD INSTALL UFO Licht GmBH Universal Fiber Optic lighting LLC Universal Fibre Optics Ltd Das Runde Haue GBR 6119A Clark Center Avenue Home Place Gewerbering Ost 5b Sarasota, FL34238 Coldstream, TD12 4DT 93155 Hemau, Deutschland...
