OPERATOR'S MANUAL
A Division of Snow Joe
, LLC
®
THANKS
OF A REMANUFACTURED PRODUCT.
To make sure you get the most out of
your product, be sure to register online at
ELECTRIC SNOW THROWER
R
18-INCH | 13.5-AMP | HALOGEN LIGHT
Model SJ621-RM
FOR
snowjoe.com
to enjoy full product support.
YOUR
PASTE UPC LABEL HERE
Form No. SJ-SJ621-RM-880E-V1
PURCHASE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SNOWJOE SJ621-RM
Summary of Contents for SNOWJOE SJ621-RM
- Page 1 18-INCH | 13.5-AMP | HALOGEN LIGHT OPERATOR’S MANUAL Model SJ621-RM A Division of Snow Joe , LLC ® Form No. SJ-SJ621-RM-880E-V1 THANKS YOUR PURCHASE OF A REMANUFACTURED PRODUCT. To make sure you get the most out of your product, be sure to register online at snowjoe.com...
-
Page 2: General Safety Warnings
OPERATOR’S MANUAL Model SJ621-RM A Division of Snow Joe , LLC ® Form No. SJ-SJ621-RM-880E-V1 IMPORTANT! refrigerators, microwave ovens and outer frames of heating equipment). Take necessary precautions to avoid Safety Instructions electric shock. There is an increased risk of electric shock if your body is earthed or grounded. -
Page 3: Personal Safety
Personal Safety operation clear of all spectators, particularly children and pets. 1. Stay alert – Watch what you are doing and use common • Excessive force – The snow thrower was designed to sense when operating the snow thrower. Do not use the respond at a certain rate for various snow conditions for machine when tired, ill or under the influence of drugs, optimum safety and performance. -
Page 4: Safety Symbols
Safety Symbols The following table describes safety symbols that may appear on this product. Read, understand and follow all instructions on the machine before attempting to assemble and operate. Symbols Descriptions Symbols Descriptions READ THE OPERATOR'S Disconnect the plug before MANUAL(S) – Read, conducting maintenance or when understand and follow all it is damaged or tangled. -
Page 5: Technical Data
Clearing Width 18 in. (46 cm) Weight (SJ620-RM) 31.5 lbs (14.3 kg) Clearing Depth 10 in. (25.4 cm) Weight (SJ621-RM with light) 32.9 lbs (14.9 kg) NOTE: The only difference between the SJ620-RM and SJ621-RM models is the halogen light system. -
Page 6: Getting Started
Instead, contact the Snow Joe + Sun Joe customer ® ® service center at 1-866-SNOWJOE (1-866-766-9563) for assistance. Handle with care during assembly so that electrical wiring does not become damaged. Getting Started 3. Secure the connection of the middle frame to the upper 1. - Page 7 2. Loosen the screw on the lower chute crank by hand Fig. 6 (Fig. 9). Fig. 9 3. Raise or lower the chute deflector to the desired height of the snow stream and tighten the knob (Fig. 7). NOTE: Do not overtighten the knob. 3.
-
Page 8: Operation
Operation 3. Insert the female end of the extension cord into the appliance's polarized male plug (Fig. 13). NOTE: Before using this machine, make sure that the power source you will use complies with the specifications detailed Fig. 13 in this manual. Before inserting the plug into the socket, verify that the snow thrower’s roll shaft and rubber plates are firmly secured with screws, and that the rubber plates are facing the correct direction. -
Page 9: Powering On/Off
(and thus back into your face and onto 4. On the SJ621-RM model, the halogen light can be used the just cleared path). to illuminate the forward road in the dark. To use the light, turn on the light switch located on the back side of the 6. - Page 10 9. Some parts of the snow thrower may freeze under NOTE: A little lubricant, such as WD-40, will provide a extreme temperature conditions. Do not attempt to smoother operation of the chute (spray at points A and B operate the snow thrower with frozen parts. If the parts as indicated in Fig.
-
Page 11: General Maintenance Tips
1. Detach the worn rubber plate assembly by removing the two sets of nuts and bolts used to secure it to the auger WARNING assembly (Figs. 21 & 22). Make sure that the chute deflector snaps and locks Fig. 21 Rubber plate assembly completely onto the discharge chute. An opening between the discharge chute and the chute deflector may allow foreign objects to be picked up by the snow thrower and thrown in the direction of the... - Page 12 Replacing the Scraper Bar Replacing the Belt + Pulley 1. The scraper bar is located at the base of the snow thrower NOTE: Determine the left and right hand side of the snow beneath the rotor housing (Fig. 24). thrower by standing behind the unit in the normal operating position Fig.
-
Page 13: Service & Support
(Fig. 27). If your Snow Joe SJ621-RM electric snow thrower ® requires service or maintenance, please call 1-866-SNOWJOE Replacing the Skid Shoes (1-866-766-9563) for assistance. The skid shoes are located at the bottom of the side panel. Model + Serial Numbers Unfasten the two screws on the side panel to remove the worn skid shoes (Fig. - Page 14 NOTE: Accessories are subject to change without any obligation on the part of Snow Joe + Sun Joe to provide notice of such ® ® changes. Accessories can be ordered online at snowjoe.com or via phone by contacting the Snow Joe + Sun Joe customer ® ®...
- Page 15 We’re here to help Monday through Friday from 9AM to 6PM EST. You can reach us at 1-866-SNOWJOE (1-866-766-9563), online EXCLUSIONS: at snowjoe.com, via email at help@snowjoe.com or tweet us • Wearing parts like belts, augers, chains and tines are @snowjoe.
- Page 16 WARNING! This product or its power cord contains chemicals, including lead, known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. For more information go to www.P65Warnings.ca.gov. WARNING! Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known [to the State of California] to cause cancer, birth defects, or other reproductive harm.
