- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS for all Hydrocarbon SF34HC Bottle Cooler Models 809-229A Rev 03/11/2023 SEE BACK COVER FOR 3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105 WARRANTY REGISTRATION Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web: beverage-air.com...
-
Page 2: Table Of Contents
If you meets the high standards set by Beverage-Air! You have have any questions, Please call our Technical Service made a quality investment that with proper maintenance Department at (800) 684-1199. -
Page 3: Safety
R290 equipment. • Clean a dirty condenser with a sharp object. • Use ONLY Beverage-Air factory service parts. Use of • Store gasoline, kerosene or any other flammable non OEM parts can be dangerous because of the design material near the cabinet. -
Page 4: Important Information
User Manual for SF34HC Refrigerators Beverage-Air IMPORTANT INFORMATION This unit is intended to be used in a commercial application. That includes bars and restaurants. If installed in a residence some commercial service companies may not be able to service it on site. -
Page 5: Product Information
User Manual for SF34HC Refrigerators Beverage-Air PRODUCT INFORMATION Cabinet Dimensions Stainless Full Load Power Cord Refrigerant Type / Model w x d x h (Inches) Steel Lids Amps Plug (NEMA) Charge (g) / (oz) SF34HC 34 X 28 X 33 5/8 5-15P R-290 / 85 / 2.88... -
Page 6: Clearance And Placement
User Manual for SF34HC Refrigerators Beverage-Air CLEARANCE AND PLACEMENT TOP MUST BE OPEN 0 INCHES MINIMUM CLEARANCE AT RIGHT SIDE AND BOTTOM. ÿ ÿ 5 ÿ 6 ÿ 4 5 ÿ 678 9 ÿ 8 ÿ... -
Page 7: Unpacking And Set Up
User Manual for SF34HC Refrigerators Beverage-Air UNPACKING AND SET UP Carefully inspect the shipping carton for damage. This is the only time that shipping damage may be claimed. If damage is suspected, open the carton immediately and, if there is damage, retain the carton and contact the shipper to make a claim. -
Page 8: Electrical
User Manual for SF34HC Refrigerators Beverage-Air ELECTRICAL This is a cord-connected unit, and must be connected to its own dedicated power supply. Check the dataplate on the machine to confirm the voltage and per the dataplate use the correct fuses or HACR circuit breakers. -
Page 9: Using The Unit
User Manual for SF34HC Refrigerators Beverage-Air USING THE UNIT To Adjust Cabinet Temperature Operation is simple, just keep it connected to the correct power supply and the refrigerator will maintain the Before making temperature adjustments, allow the unit internal temperature it has been set to. Keep the door to stabilize for 1 hour and verify that a temperature closed as much as possible to avoid unnecessary run time. -
Page 10: Sequence Of Operations Refrigerator
User Manual for SF34HC Refrigerators Beverage-Air SEQUENCE OF OPERATIONS REFRIGERATOR The refrigerator operates based on the air temperature measured by the probe located at the return air. COMPONENT OPERATION CONTROLLER ACTION OPERATION CONTROLLER ACTION The Compressor Compressor turns Compressor turns... -
Page 11: Cleaning And Maintenance
User Manual for SF34HC Refrigerators Beverage-Air CLEANING AND MAINTENANCE Cleaning Schedule: Cabinet Condenser coil Gaskets Routine maintenance Daily wipe down Quarterly cleaning Daily inspection, check Annually that hinges are tight to Weekly interior the cabinet. Daily Exterior Cleaning It is much easier to clean on a regular basis than to have to remove stains once they have built up. -
Page 12: Condenser Cleaning
User Manual for SF34HC Refrigerators Beverage-Air CONDENSER CLEANING The condenser coil is located right behind the back panel. It Chemical Cleaning should be inspected once a month and cleaned as required. 1. Remove power from the unit. 1. Remove power from the unit. -
Page 13: Methods For Cleaning Stainless Steel
User Manual for SF34HC Refrigerators Beverage-Air METHODS FOR CLEANING STAINLESS STEEL Cleaning Needed Cleaning Agent Method of Application Affect on Finish Satisfactory for use on all Areal 20, Lac-O-Nu, Lumin Wash Rub with cloth as directed finishes. Smears and fingerprints O’Cedar Cream Polish, Stainless... -
Page 14: Help
User Manual for SF34HC Refrigerators Beverage-Air HELP Trouble Diagnosis for the User Malfunction Possible Cause Likely Solution Connect to proper voltage circuit Unit not plugged in. Replace fuse or reset breaker. No cooling - unit is silent Fuse or circuit breaker tripped. -
Page 15: For The Service Tech - R290
User Manual for SF34HC Refrigerators Beverage-Air FOR THE SERVICE TECH - R290 Refrigeration service should only be attempted by a trained trade professional certified to work on R290 systems. Here are some critical service items. Other Information: This list does not qualify anyone to service the unit. It is a Evacuation: It is critical that a refrigeration system be reminder and checklist for the service tech. -
Page 16: For The Service Tech - Wiring Diagram
User Manual for SF34HC Refrigerators Beverage-Air FOR THE SERVICE TECH - WIRING DIAGRAM CONDENSER FAN CURRENT RELAY COMP *SEE CONTROLLER DETAIL COMPRESSOR DETAIL (115V 1PH) EVAP FANS POWER SUPPLY LIGHT SWITCH *NOT ALL MODELS* LAMP L.E.D. LAMP *NOT ALL MODELS* Beverage-Air Rev. -
Page 17: Limited Warranty
(87) months from the date of defective. shipment from Beverage-Air, provided upon receipt of the The labor warranty shall be for self-contained units compressor, manufacturer examination shows the sealed only and for standard straight time, which is defined as compressor to be defective. -
Page 18: Limited Warranty (Continued)
With the exception of Blast Chillers product is designed for LIMITATION OF LIABILITY: maintaining temperature and not bringing food to a desired Beverage-Air Corporation or their affiliates shall not be temperature therefore cannot be held responsible for this liable for any indirect, incidental, special or consequential function under warranty. - Page 19 User Manual for SF34HC Refrigerators Beverage-Air Warranty Registration Register your product online at beverage-air.com/parts-service or fill out and mail the form below. Cabinet Model Number: _____________________________________________ Date Of Installation: _________________ Cabinet Serial Number: _____________________________________________ Location Of Product Business Name: ____________________________________________________...
