- Page 1 IMPORTANT INFORMATION BZ13 SERIES This cooler has passed the QUALITY CONTROL INSPECTION and meets the high standards at Beverage-Air. This inspection includes complete refrigeration system, cabinet construction & finish IMPORTANT PLEASE RETAIN FOR YOUR RECORDS SALES OFFICE: P.O. BOX 5932 SPARTANBURG, S.C. 29304-5932...
- Page 2 BEVERAGE-AIR ® Installation and Operating Instructions Model BZ13 Installation a. Receiving Inspection Standard items packaged in the cabinet interior are: Shelves – (3) each, Product Organizers – (3) each, Glide Mats – (3) each and Shelf Support Clips – (6) each. Cabinet accessories, such as additional Shelves and cabinet Rollers, are also packaged in the cabinet interior.
- Page 3 b. Initial Start-Up Verify temperature control setting to be at the 2 o-clock position (reference single scribe mark on adjuster plate) and connect cabinet electrical cord to electrical supply. Refrigeration system operation can be verified by the audible sound of the compressor start-up and the presence of air movement exiting the compressor compartment and in the cabinet interior.
- Page 5 See pictures below. Caution: Improperly installed lamps may cause damage to the lighting circuit. Beverage-Air shall have no liability whatsoever for equipment or component failures or other damages or losses which arise as a result of improper installation. Bi-pin lamp end Properly installed lamp without shield.
-
Page 9: Refrigeration System
SERVICE AND REFRIGERATION ANALYSIS CHART SYSTEM MALFUNCTION POSSIBLE CAUSE SOLUTION 1. Line cord not plugged in. Compressor will 1. Plug in line cord. 2. Replace fuse. 2. Fuse removed or blown. not start — no hum 3. Refer to electrical section. 3. - Page 10 4. Higher than normal cabinet temperature. Purge excessive refrigerant from the system very carefully in small amounts waiting several minutes for the system to balance. FEDERAL LAW REQUIRES THAT REFRIGERANTS BE RECOVERED PRIOR TO SERVICING. BEVERAGE-AIR ILA-1591 REV B-SHT 2...
- Page 11 SERVICE RECORD...
