Edifier TO-U7 Pro - True Wireless In-Ear Headphones Manual

Power ON/OFF

Power ON when the case is opened.
Power OFF when placed in the case and the case is closed.

Note:
If there is no Bluetooth connection for 10 minutes after power on, the earbuds will turn off automatically; if there is no Bluetooth connection in noise cancellation or ambient sound mode, the earbuds will turn off automatically after 2 hours.

Pairing

Earbuds placed in the case and keep the case open.
Press and hold the button on the case for about 3s. LEDs will be lit one by one in a clockwise direction and then display circularly.
Select "EDIFIER TO-U7 Pro" in your device setting to connect. LEDs will blink once and then turn off when successfully.

1st Pairing

Earbuds placed in the case and keep the case open. LEDs will be lit one by one in a clockwise direction and then display circularly.
Select "EDIFIER TO-U7 Pro" in your device setting to connect. LEDs will blink once and then turn off when successfully.

Note:
For subsequent use, the earbuds will automatically connect to the device used last time.

Reset

Earbuds placed in the case and keep the case open.
Press the button on the case 3 times to re-enter left & right connection and clear pairing records. LEDs will blink twice and then turn off when successfully. Then, LEDs will be lit one by one in a clockwise direction and display circularly.
Select "EDIFIER TO-U7 Pro" in your device setting to connect LEDs will blink once and then turn off when successfully.

Charging

Charging case

Please connect the case to power source with the included Type-C charging cable for charging.
During charging, LEDs will be lit one by one, and then turn off gradually to the actual power level after all LEDs are lit; LEDs will be off after fully charged.

Note:
Please do not charge the earbuds when there is sweat or other liquids inside the charging port, which may damage the earbuds.

Input:
5V 200mA(Earbuds)
5V 1A(Charging case)

Controls

Note:

Default sound control: both earbuds-noise cancellation & ambient sound & noise cancellation off; single earbud-noise cancellation off & ambient sound.
Images are for illustrative purposes only and may differ from the actual product.
Download Edifier Connect App for more customizable control settings.

For more information, please visit our website:
www.edifier.com

@Edifierglobal

@Edifier_Global

Model: EDF280001
Edifier International Limited
P.O. Box 6264
General Post Office
Hong Kong

NOTICE:
For the need of technical improvement and system upgrade, information contained herein may be subject to change from time to time without prior notice.
Products of EDIFIER will be customized for different applications. Pictures and illustrations shown on this manual may be slightly different from actual product. If any difference is found, the actual product prevails.
