EDIFIER TO-U7 Pro Manual

True Wire le ss N oise Ca nce ll at ion In- Ear H eadp ho nes
EN 1. Power ON/OFF
1.Power ON when the case is opened.
2.Power OFF when placed in the case and the case is closed.
Note:
If there is no Bluetooth connection for 10 minutes after power on, the
earbuds will turn off automatically; if there is no Bluetooth connection in
noise cancellation or ambient sound mode, the earbuds will turn off
automatically after 2 hours.

2. Pairing

1.Earbuds placed in the case and keep the case open.
2.Press and hold the button on the case for about 3s. LEDs will be lit
one by one in a clockwise direction and then display circularly.
3.Select "EDIFIER TO-U7 Pro" in your device setting to connect. LEDs
will blink once and then turn off when successfully.
1st Pairing
1.Earbuds placed in the case and keep the case open. LEDs will be lit
one by one in a clockwise direction and then display circularly.
2.Select "EDIFIER TO-U7 Pro" in your device setting to connect. LEDs
will blink once and then turn off when successfully.
Note:
For subsequent use, the earbuds will automatically connect to the device
used last time.

3. Reset

1.Earbuds placed in the case and keep the case open.
2.Press the button on the case 3 times to re-enter left & right connection
and clear pairing records. LEDs will blink twice and then turn off when
successfully.Then, LEDs will be lit one by one in a clockwise direction
and display circularly.
3.Select "EDIFIER TO-U7 Pro" in your device setting to connect. LEDs
will blink once and then turn off when successfully.

4. Charging

5. Controls

Left Touch Panel
Note:
1.Default sound control:both earbuds-noise cancellation & ambient sound
& noise cancellation off; single earbud-noise cancellation off & ambient
sound.
2.Images are for illustrative purposes only and may differ from the
actual product.
3.Download Edifier Connect App for more customizable control settings.
For more information, please visit our website:
@Edifierglobal
Model: EDF280001
Edifier International Limited
P.O. Box 6264
General Post Office
Hong Kong
www.edifier.com
2022 Edifier International Limited. All rights reserved.
Printed in China
NOTICE:
For the need of technical improvement and system upgrade,
information contained herein may be subject to change from time
to time without prior notice.
Products of EDIFIER will be customized for different applications.
Pictures and illustrations shown on this manual may be slightly
different from actual product. If any difference is found, the actual
product prevails.
TO -U7 Pro
Manual
Indicator
Indicator
Indicator
Charging case
1. Please connect the case to power source
with the included Type-C charging cable for
charging.
2. During charging, LEDs will be lit one by one,
and then turn off gradually to the actual
power level after all LEDs are lit; LEDs will
be off after fully charged.
Note:
Please do not charge the earbuds when there
is sweat or other liquids inside the charging
port, which may damage the earbuds.
Input: 5V
x2
x2
x2
x3
www.edifier.com
@Edifier_Global
Button
Button
200mA(Earbuds)
5V 1A(Charging case)
x2
x2
x2
x3
x3
Right Touch Panel
@Edifier_Global
3s
