Carima's DLP 3D Printer IMD
is optimized for the dental
industry providing a
One-Stop Digital Workflow &
One-Day Clinic.
IMD is compatible with various
dental resins and
has excellent reproducibility.
24~25
Optimum production
FAST
for dental treatment (Crown/Model)
PRINTING
(Printing - Cleaning - Curing)
19-20mins
25
HIGH
PRECISION
Layer thickness(25μm)
Printing precison(30μm)
65
PIXEL SIZE
Ultra precision(X/Y)
X/Y
(FHD Resolution, 1920x1080)
99
REPRODUCIBILITY
Light uniformity
(Printing speed increased by minimizing light loss)
IMD
mins
2mins
3mins
μ m
μ m
%
www.carima.com
*Crown : 19mins/
Model : 20mins
Advertisement
Table of Contents
Related Manuals for Carima IMD
Summary of Contents for Carima IMD
- Page 1 Model : 20mins μ m HIGH PRECISION Layer thickness(25μm) Printing precison(30μm) μ m PIXEL SIZE Carima’s DLP 3D Printer IMD Ultra precision(X/Y) (FHD Resolution, 1920x1080) is optimized for the dental industry providing a One-Stop Digital Workflow & One-Day Clinic. REPRODUCIBILITY...
-
Page 2: Table Of Contents
This manual provides Specification instructions on how to Product Overview use the "IMD." Safety Warnings Understand how to Process Overview use "IMD" through the Compatible Resin manual and experience "IMD" easily and conveniently. Preparation and Setup Printing Preparation Using the LCD Panel... -
Page 3: Introduction
INTRODUCTION INTRODUCTION IMD Specification IMD is optimized for printing highly precise models. This ultra-precise DLP printer is suitable for dental. Printing Size(mm) [W x D x H] Precision 124 x 70 x 140 65 μm Product Size (mm) [W x D x H]... -
Page 4: Product Overview
Build Plate Module Resin Vat Build Plate Fixing FEP Film Base * Build plate, vat, FEP film, etc. are accessories. Vat Retention Knob To purchase additional accessories, please contact Carima. Actuator (located on both sides) IMD AGENCY MANUAL www.carima.com sales@carima.com 02-3663-8877... -
Page 5: Safety Warnings
To prevent injury on children and pets, please install the printer in a safe place. The warranty benefits of the printer will be forfeited if disassembled or modified artificially. Carima will not be held liable for the loss caused by this. For inquiries regarding “After Sale Service” and product warranty, please contact Carima. -
Page 6: Process Overview
Check to install. Set Vat Slicing File Fill vat with resin Set build plate Check the Carima Slicer manual (separate provision). Post- Load Data processing Load Set exposure time Clean build plate Control Setting IMD AGENCY MANUAL www.carima.com sales@carima.com 02-3663-8877... -
Page 7: Compatible Resin
Generally used for printing for prototype or life-size modeling. Nontoxic CMYK / Clear Biocompatible CMYK/W resin, being non-volatile and nontoxic, allows users to combine colors. The resin is compatible with Carima’s eco-friendly detergent (RD-229), allowing it to be washed with water. Yellow... -
Page 8: Preparation And Setup
Once it exceeds its usage time, improve the quality of the output by * Build plate, vat, FEP film, etc. are accessories. replacing it with a new lamp. To purchase additional accessories, contact Carima. IMD AGENCY MANUAL www.carima.com sales@carima.com... -
Page 9: Using The Lcd Panel
Step3 Print Select Resin Select Data Check Print Print Printer Setting Language Update Data Management Data Setting Printer Management Exposure light Build Plate Printer for Cleaning Movement Information Management Zero Position Setting Administrator Mode IMD AGENCY MANUAL www.carima.com sales@carima.com 02-3663-8877... - Page 10 This is a screen showing the printing progress. You can see the current printing progress. * When the remaining time is less than 10 minutes, it is displayed in yellow, and when printing is finished, it is displayed in red. IMD AGENCY MANUAL www.carima.com sales@carima.com 02-3663-8877...
- Page 11 This is the detailed information screen during printing. Power Off If you press the Main Home button on the main screen, the exit pop-up page appears. You can select the Restart or Power Off. IMD AGENCY MANUAL www.carima.com sales@carima.com 02-3663-8877...
- Page 12 Setting language and update. Printer Setting 日本語 Language 한국어 English Update USB Update Language : Change the language setting. The changed language is applied when the system restarts. Update : Update the software version. IMD AGENCY MANUAL www.carima.com sales@carima.com 02-3663-8877...
- Page 13 Select data and press the delete button to delete data. Delete All : Delete all data. Export Data Export You can export files from USB to Equipment. After selecting the data, click the Export button to complete the export. IMD AGENCY MANUAL www.carima.com sales@carima.com 02-3663-8877...
- Page 14 Exposure Light for Cleaning, Build Plate Movement, Printer Information, Log Management, Zero Position Setting and Administrator mode. Administrator Mode Used only by Carima technicians during "After Sale Service." This service is not available for users. For Customer Service, contact Carima. (82-2-3663-8877)
- Page 15 Zero Position Setting This function requires attention. Before setting the zero position, please refer to the user manual or contact Carima. * There is a risk of damage to the glass of the printer when setting the zero position, and the manufacturer is not responsible for this accident.
- Page 16 Please be careful whenever you use the Administrator Mode. Refer to the AGENCY Manual or contact Carima Co., Ltd.. Administrator Mode Carima Co., Ltd. is not responsible for any problems that occur when setting the administrator mode. Enter Password Enter password to enter the...
- Page 17 Select the resin to set parameters. You can delete, reset and add resins on the current page. Delete Select the resin, and click 'Delete' button to delete. Reset Reset the resin list. Add Resin Add the resin. IMD AGENCY MANUAL www.carima.com sales@carima.com 02-3663-8877...
- Page 18 Build Plate Parameter Setting Set the Build-plate parameters. After setting, click the 'Confirm' button to com- plete the resin parameter setting. After then, move to Step1 (Select Resin) page to change other resin prameter setting. Confirm IMD AGENCY MANUAL www.carima.com sales@carima.com 02-3663-8877...
- Page 19 Set the amount of light exposure. Light Uniformity Calibration Image : You can check whether the light is irradi-ated evenly or not. Focusing Image : You can check whether the light source is in focus or not. Confirm IMD AGENCY MANUAL www.carima.com sales@carima.com 02-3663-8877...
-
Page 20: Finishing Prints
Be aware, for the output should not be in alcohol for more than an hour. For detailed wash, use thin brush to remove resins. Use eco-friendly detergent or water when using Carima's Nontoxic resin(CMYK/W). * Use protective equipment when using toxic alcohol(IPA). - Page 21 UV curing. Wear glasses or goggles to protect air compressor or let it dry naturally. your eyes. * The air compressor is not sold in Carima. Be aware, for excessive curing affects the output. * Take caution while using the air compressor, for it may damage the output.
-
Page 22: Maintenance
If the resin leaks into the printer, wipe it with alcohol. If the engine lens is damaged, it can adversely affect the print quality. Contact Carima for technical help. Maintaining Other Accessories Basic printer accessories include resin vat and resin. - Page 23 Must be entrusted to waste disposal company. IMD Tool Set IMD Tool Set will be available when IMD is purchased. These set of tools will be useful when using the printer. Contact Carima for additional purchase of IMD Tool Set.
-
Page 24: Faq
What is the difference between "crv" and "stl" files? The crv file is the default file by carima slicer. Supporter and models are recognized separately and stored so that they can be modified at any time when the supporter work is completed and saved. In the case of the stl file, supporters are saved as one mass with the model and cannot be modified after saving. - Page 25 CARIMA DENTAL 3D PRINTER IMD Manual V1.0.0.14 l 2022. 01. 20 ⓒ All copyright is reserved by Carima Products and other inquiries 9:00 – 18:00 UTC+09:00 (Mon - Fri) Tel. 82-2-3663-8877 l sales@carima.com 1301, 551-17, Yangcheon-ro, Gangseo-gu, Seoul, Republic of Korea.
