Arrow Storage Products EPA104 Owner's Manual & Assembly Manual

Steel shed 10' x 4'
Hide thumbs Also See for EPA104:

Advertisement

Quick Links

Download this manual
731841021
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
Register • Enregistrer • Regístrate
/
ShelterLogic.com
product-registration
BUILDING DIMENSIONS
†
†
Approx.
Size
10' x 4'
35 Sq. Ft. 188 Cu. Ft.
3,0m x 1,2m
3,3m
* See Inside for Detailed Safety Information.
†
Size rounded off to the nearest foot
Exterior Dimensions
Storage
(Roof Edge to Roof Edge)
Area
Width
123 1/2"
2
5,3m 3
313,7 cm
Model No. EPA104
Visit our website for compatible accessories
Depth
Height
Width
47"
67 3/4"
118 1/4"
119,4 cm
172,1 cm
300,4 cm
Steel Shed
Steel Shed
10' x 4'
arrowsheds.com
121" x 45 1/4"
Base
307,3 cm x 114,9 cm
Size
For proper base construction see page 11
Interior Dimensions
(Wall to Wall)
Depth
Height
42 1/2"
66 9/16"
108,0 cm
169,1 cm
EN-01KR
Nominal Size
Door
Opening
Width
Height
55 1/2"
60"
141,0 cm
152,4 cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the EPA104 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arrow Storage Products EPA104

Summary of Contents for Arrow Storage Products EPA104

  • Page 1 EN-01KR 731841021 Owner’s Manual & Assembly Guide Steel Shed Steel Shed Gloves must be worn Model No. EPA104 at all times to reduce risk of injury! 10’ x 4’ Nominal Size Register • Enregistrer • Regístrate arrowsheds.com Visit our website for compatible accessories 121”...
  • Page 2 EN-04HN CAUTION • Care must be taken when handling various pieces of your building since many contain sharp edges. • Do NOT attempt to assemble your building before double checking that you have all the parts indicated in the parts lists. Any building left partially assembled may be seriously damaged by even light winds.
  • Page 3 EN-05HN ASSEMBLY • The best location is a level area with good drainage. • Allow enough space outside the building to be able to access the roof with a ladder. • Use Teamwork: Two or more people are required to assemble your building. CARE &...

  • Page 4: Hardware List

    HARDWARE LIST EN-05IO Part Qty. Part No. Part Views Description 65103 Hex Nut (#8-32) 65923 Small Bolt (#8-32 x 3/8) (10 mm) 65004 Small Screw (#8AB x 5/16) (8 mm) 65900 Black Screw (#10B x 1/2) (13 mm) 65109 Acorn Nut (#8-32) The fasteners used in each step are shown actual size at the top of each page.
  • Page 5 HARDWARE LIST EN-05KR Part Qty. Part No. Part Views Description 66045 Handle 66769 Door Slide 66646 Washer Sheet 66382 Lower Door Guide 10 66183L Left Roof Trim Cap 11 66183R Right Roof Trim Cap 12 30028 Nameplate 13 66775 Plug (Door Color)

  • Page 6: Parts List

    PARTS LIST EN-06KR Part Qty. Part No. Part Views Description 14 11569 Side Floor Frame 8936 Rear Floor Frame 8934 Ramp 9367 Front Floor Frame 6514 Corner Panel Wall Panel 9373 11570 Corner Panel 6515 Wall Panel 9917 Rear Wall Channel 11574 Side Wall Channel 9365...
  • Page 7 PARTS LIST EN-07KR Part Qty. Part No. Part Views Description 6403 Door Track Splice 9366 Door Track 11575 Front Header 31 10562 Right Gable 32 80015 Left Gable 33 11576 Roof Beam 34 11577 Right Roof Panel 35 80289 Left Roof Panel 36 11578 Roof Panel 37 10872 Roof Trim 38 80087 Roof Trim...
  • Page 8 PARTS LIST EN-09IO Part Qty. Part No. Part Views Description 3719 Door Handle Brace...
  • Page 9 ASSEMBLY BY KEY NO. EN-10IO...
  • Page 10 ASSEMBLY BY KEY NO. EN-11IO...
  • Page 11 CONSTRUCTING A FOUNDATION EN-12IO Wood Platform Concrete Slab IMPORTANT The base MUST be fl at and level to provide adequate support for your building, otherwise the PRE-DRILLED HOLES WILL NOT ALIGN AND IT CANNOT BE ASSEMBLED. No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an eff...
  • Page 12 EN-14IF 1: FLOOR FRAME 8936 65923 65103 65004 9367 8934 65923 65103 8936 8936 65103 65923 Finished Length Overlap Length 119 3/8” 303,2 cm 11 7/8” 30,2 cm 9367 65004 8934 8934 9367 Front Finished Length 119 3/8” 303,2 cm...
  • Page 13 1: FLOOR FRAME EN-15IO (2)9367+8934 11569 65004 65923 65103 8936+8936 NOTES: Do NOT fasten your Floor Frames to your Base at this time. You will anchor your 65103 building after it is erected. 9367 The Floor Frame must be BOTH square AND level or the holes will not line up properly.

  • Page 14: Pre-Assembly

    2: PRE-ASSEMBLY EN-16IO 11573 9917 65923 65103 65923 11573 11573 65103 118 1/8” (300,0 cm) Finished Length 65923 9917 9917 65103 118 1/8” (300,0 cm) Finished Length...
  • Page 15 2: PRE-ASSEMBLY EN-17IO 65923 65103 11576 65103 11576 11576 65923 11576 65103 65103 11576 65923 65923 119 7/8” (304,5 cm) Finished Length...
  • Page 16 2: PRE-ASSEMBLY EN-19IB 65004 9366 66769 6403 9366 6403 Painted Part 118 1/8” (300,0 cm) Finished Length 65004 9366 END VIEW CORRECT INCORRECT Long Leg on top. 66769 Door Slide Slides should be installed in Door Track prior to installation. However, if this step is overlooked or if the Slides need to be removed for maintenance, the following procedure may be used.
  • Page 17 2: PRE-ASSEMBLY EN-19IO 65923 66646 65103 65004 11575 (2)9366+6403 11575 65103 66646 11575 65923 11575 65004 9366 11575 6403 9366 Long Leg on Top. 9366 Short Leg on Bottom.
  • Page 18 3: CORNER PANELS EN-18KR 6515 6514 9373 65004 66646 65923 66646 65103 11570 65004 65004 66646 66646 6514 11570 6515 9373 65103 65103 65923 65923 66646 66646...
  • Page 19 3: CORNER PANELS EN-19KR 65004 66646 65923 66646 65103 6514+9373 6515+11570 11570 6514 6515 6515 9373 11570 6514 9373 65103 65923 66646 Front 65004 66646...
  • Page 20 4: WALL ANGLE EN-22IO 11572 11573+11573 65004 66646 11573 11572 66646 65004 11572 11573+11573 11572 Front...
  • Page 21 5: FRONT HEADER EN-23IO 65004 66646 66646 65004 Door Track / Front Header Front...
  • Page 22 6: WALL PANELS EN-22KR 65923 66646 65103 6515 65004 66646 Uncrimped Rib Whenever a crimped rib and an uncrimped rib meet, the crimped rib should be placed UNDER the uncrimped rib if possible. Crimped Rib 6515 6515 65923 65103 66646 66646 65004 Rear...
  • Page 23 7: DOOR JAMB EN-23KR 9369 65004 66646 65923 66646 65103 65109 9369 9369 9369 9369 65923 66646 65103 65109 Front 66646 65004...
  • Page 24 8: WALL CHANNEL EN-26IO 65004 11574 9917+9917 9365 65004 66646 65004 11574 9365 9917+9917 11574 65004 66646 9365 Front...
  • Page 25 9: ROOF BEAMS EN-27IO 65923 65103 11576+11576 11576 11576 65103 11576 65923...
  • Page 26 10: ROOF PANELS EN-28IO 11578 65923 66646 65103 65004 66646 11577 80289 65004 66646 80289 11577 Front 65004 65923 66646 11578 66646 11578 65103 Front...
  • Page 27 10: ROOF PANELS EN-29IO 11578 65923 66646 65103 65004 66646 65004 11578 66646 65923 66646 65103 Front 65004 66646 11578 65923 66646 65103 11578 Front...
  • Page 28 11: GABLES EN-30IO 10562 65923 66646 65103 80015 65004 66646 65103 66646 66646 65923 10562 65004 10562 65004 66646 11572 10562 Front 65103 66646 65923 80015 66646 80015 65004 65004 66646 11572 80015 Front...
  • Page 29 12: ROOF TRIM EN-31IO 65004 65004 66646 10872 80087 66183R 66183L 65004 66183L 65004 10872 66646 66183R 80087 80087 66183R 10872 66183L Front...

  • Page 30: Door Assembly

    13: DOOR ASSEMBLY EN-30KR 80253 6278 66045 3719 65004 66646 65923 65103 66775 Plug (Door Color) 65004 66646 80253 6278 65923 65103 66045 3719 66775...
  • Page 31 13: DOOR ASSEMBLY EN-31KR 10497 66382 65923 66646 65103 10497 65103 65923 Right Door Assembly 66646 10497 66382 65923 66646 65103 66382 10497 80253 10497 66382...
  • Page 32 13: DOOR ASSEMBLY EN-32KR 80253 6278 66045 3719 65004 66646 65923 65103 30028 30028 65004 66646 80253 66045 6278 65923 65103 3719...
  • Page 33 13: DOOR ASSEMBLY EN-33KR 10497 66382 65923 66646 65103 10497 65103 65923 Left Door Assembly 66646 10497 66382 65923 66646 65103 66382 10497 80253 10497 66382...
  • Page 34 13: DOOR ASSEMBLY EN-40IF 65900 Front Header Door Slide Door Track INSIDE BUILDING Door Front Floor Frame Door Adjustment If Doors do not align, raise or lower one side of the Door by placing the Door screws through a diff erent set of holes in the Door Slide.
  • Page 35 EN-48HK ANCHORING OPTIONS IMPORTANT • If you have swing doors, they must hang and swing level before anchoring building. • • Anchor your building at this time. Use appropriate 1/4”(6mm) X 1 1/2”(38,1mm) length Anchor your building this time. approprate 1/4”...
