Arrow Storage Products EPA104 Owner's Manual & Assembly Instructions

Storage area: 35 sq. ft. 188 cu. ft. 3,3 m2 5,3 m3
Hide thumbs Also See for EPA104:
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
YU01
Model No.
716450510
Storage Area: 35 Sq. Ft.
3,3 m
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
10' x 4'
121" x 45 1/4"
3,0 m x 1,1 m 307,3 cm x 114,9 cm
EPA104
188 Cu. Ft.
5,3 m
2
3
* Size rounded off to the nearest foot
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
123 1/2"
313,1 cm
119,4 cm
Interior Dimensions
Height
Width
47"
67 3/4"
118 1/4"
172,1 cm
300,4 cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
(Wall to Wall)
Depth
Height
42 1/2"
66 9/16"
108,0 cm
169,1 cm
Door
Opening
Width
Height
55 1/2"
60"
141,0 cm
152,4 cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EPA104 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arrow Storage Products EPA104

Summary of Contents for Arrow Storage Products EPA104

  • Page 1 Owner's Manual & Assembly Instructions YU01 Model No. EPA104 716450510 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE Storage Area: 35 Sq. Ft. 188 Cu. Ft. MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES 3,3 m 5,3 m TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
  • Page 2 BEFORE YOU BEGIN..XA02 Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Instructions are supplied in this manual and contain all Assembly Instructions: appropriate information for your building model.

  • Page 3: Tools And Materials

    PLAN AHEAD..XA03 Be sure the day you select to install your building is dry and calm. Watch the Weather: Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Whenever possible, two or more people should work together to assemble Teamwork: your building.
  • Page 4 SAFETY FIRST..XA04 Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
  • Page 5 CARE & MAINTENANCE..XA05 For long lasting finish, periodically clean and wax the exterior surface. Touch- Finish: up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Keep roof clear of leaves and snow with long handled, soft-bristled broom.
  • Page 6 Base YU06 The Base For Your Building OPTION 1: Wood Platform If you decide to build your own base, be sure to select the appropriate materials. These are the recommended materials for your base: ● 2 x 4's (38 mm x 89 mm) Pressure Treated Lumber ●...
  • Page 7 Anchoring XA07 Anchoring Down The Building It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) dia.
  • Page 8 Hardware YU08 Remove from bag of screws and save for the last step 65900A 65923 #10Bx1/2" (13 mm) 65004 65103 #8-32x3/8" (10 mm) Black Screw (8) #8Ax5/16" (8 mm) Bolt (60) #8-32 Hex Nut (60) (Packed with Screws) Screw (246) 65109 66646 66045...

  • Page 9: Parts List

    Parts List YU09 Assembly Part Part Quantity Check Key No. Number Description in CartonList 10567 Rear Wall Angle 6403 Door Track Splice 10497 Horizontal Door Brace 10574 Front Header 10557 Roof Panel 10562 Right Gable 80015 Left Gable 6892 Right Roof Trim 10558 Right Roof Panel 80011...
  • Page 10 Assembly by Key No. YU10...
  • Page 11 ● ● ● ● ● 8934 Ramp (1) ● Parts Needed For ● Step 1 ● ● ● ● ● 9367 Front Floor Frame (2) Floor Frame Assemblies ● ● ● ● ● 8936 Rear Floor Frame (2) YU11 9367 The front floor frame is made up of 8934 three pieces.

  • Page 12: Frame Assemblies

    ● Parts Needed For ● ● ● ● ● ● 10567 Rear Wall Angle (2) Step 2 ● ● ● ● ● 9917 Rear Wall Channel (2) Frame Assemblies YU12 Rear Wall Channel 118 1/8" 300,0 cm 9917 The main frame pieces reinforce the 9917 walls.
  • Page 13 ● Parts Needed For ● Step 3 ● ● ● ● ● 10571 Roof Beam (2) Roof Beam Assemblies YU13 The roof beams support the roof pan- 10571 els. The roof beam is made up of two pieces overlapped at the center. 10571 Hint: These pieces are force-fitted, 119 7/8"...

  • Page 14: End View

    ● Parts Needed For ● ● ● ● ● ● 6403 Door Track Splice (1) Step 4 Door Track / Header ● ● ● ● ● 9366 Door Track (2) ● ● ● ● ● 10574 Header (2) Assembly YU14 NOTE: Door Track Splice (painted part) (14)
  • Page 15 ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● Step 5 ● ● ● ● ● 10544 Side Floor Frame (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) YU15 RIGHT REAR 10544 STEP 10544...

  • Page 16: Top View

    ● Parts Needed For ● ● ● ● ● ● 6515 Wall Panel (2) Step 6 ● ● ● ● ● 9373 Front Wall Panel (2) Corners ● ● ● ● ● 6020 Corner Panel (4) YU16 Narrow Side 6020 (38) Wide Side NOTE...
  • Page 17 ● ● ● ● ● Rear Wall Angle Assembly (1) ● Parts Needed For ● ● ● ● ● ● Rear Wall Channel Assembly (1) Step 7 ● ● ● ● ● 10545 Side Wall Channel (2) Frames ● ● ● ● ● 10564 Side Wall Angle (2) ●...
  • Page 18 ● Parts Needed For ● Step 8 ● ● ● ● ● 6515 Wall Panel (2) Wall Panels YU18 Fasten the wall panels at the top and bottom with screws. (30) Fasten the center of each panel to the wall channel with screws. Each wall panel has a crimped rib on Fasten overlapping ribs as before.
  • Page 19 ● Parts Needed For ● ● ● ● ● ● 9369 Door Jamb (2) Step 9 ● ● ● ● ● 9365 Front Wall Channel (2) Front Channel/Door Jamb YU19 9365 (18) The door jambs reinforce the door STEP opening and provide an attractive trim.
  • Page 20 ● Parts Needed For ● Step 10 ● ● ● ● ● Roof Beam Assembly (1) Roof Beam YU20 The dimension stated below mea- sures from the end of the angle to- wards the front of the building. Fas- ten the roof beam assembly, small holes on top, to the side wall angle with a bolt and nut.
  • Page 21 ● Parts Needed For ● Step 11 ● ● ● ● ● 10558 Right Roof Panel (1) Right/Left Roof Panels ● ● ● ● ● 80011 Left Roof Panel (1) YU21 Position a right roof panel at the right side and fasten to the header, (18) roof beam and rear wall angle using screws as shown.

  • Page 22: Roof Panel

    ● Parts Needed For ● Step 12 ● ● ● ● ● 10557 Roof Panel (2) Roof Panel ● ● ● ● ● 10559 Roof Panel (1) YU22 Screws To Rear Wall Angle (36) Install a wide roof panel 10557, narrow roof panel 10559, and a Fasten At wide roof panel 10557 in the posi-...
  • Page 23 ● Parts Needed For ● ● ● ● ● ● 10562 Right Gable (1) Step 13 ● ● ● ● ● 80015 Left Gable (1) Gables YU23 Fasten to the right roof panel, side wall angle and front header using screws, bolts and nuts as shown.
  • Page 24 ● Parts Needed For ● ● ● ● ● ● 6892 Right Roof Trim (2) Step 14 ● ● ● ● ● 80019 Left Roof Trim (2) Roof Trim YU24 Using your thumb and index fin- ger, overbend the bottom flange of the roof trim at the corner inward enough so the right and left roof trim caps fit onto right and left cor-...

  • Page 25: Door Assembly

    ● ● ● ● ● 3719 Door Handle Brace (2) ● Parts Needed For ● ● ● ● ● ● 10475 Right and Left Doors (2) Step 15 ● ● ● ● ● 10497 Horizontal Door Brace (4) Door Assembly ●...
  • Page 26 ● Parts Needed For ● ● ● ● ● ● Right Door Assembly (1) Step 16 ● ● ● ● ● Left Door Assembly (1) Door Installation & Adjustment YU26 Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the building) behind door jamb into the...
  • Page 27 EPA104 YU28 Anchoring Anchor your building at this time. SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
