Owner's Manual & Assembly Instructions
CJ01
Model No. EP84
716761217
Storage Area: 28 Sq. Ft.
2,6 m
2
BUILDING DIMENSIONS
*Approx.
Size
8' x 4'
97 1/2" x 45 1/4"
2,4 m x 1,1 m
247,7 cm x 114,9 cm
PTG84
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
150 Cu. Ft.
4,2 m
3
* Size rounded o to the nearest foot
Exterior Dimensions
Base
(Roof Edge to Roof Edge)
Size
Width
100"
254,0 cm
PT84
PTG84EU
Depth
Height
Width
47"
67 3/4"
94 3/4"
119,4 cm 172,1 cm
240,7 cm 108,0 cm
PT84EU
EPA84
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Depth
Height
42 1/2"
66 9/16"
169,1 cm
Door
Opening
Width
Height
43 1/2"
60"
110,5 cm 152,4 cm
Advertisement
Related Manuals for Arrow Storage Products EP84
Summary of Contents for Arrow Storage Products EP84
- Page 1 Owner's Manual & Assembly Instructions CJ01 Model No. EP84 PT84 PT84EU PTG84 PTG84EU EPA84 Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests. 716761217 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE Storage Area: 28 Sq.
- Page 3 BEFORE YOU BEGIN..Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.
- Page 4 PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
- Page 5 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
- Page 6 CARE & MAINTENANCE..Finish: For long lasting nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
- Page 7 ACCESSORIES..FLOOR FRAME KITS ROOF STRENGTHENING (heavy snow load) KITS Extra roof beams and gable braces designed for added protection against heavy snow accumulation. Increases the strength of your roof. BEFORE AFTER ANCHOR KITS Model No. AK4 MODELS FB47410, FB5465, FB106-A Anchor Kit contains heavy-duty steel FB109-A and FB1014-A augers, 60' (18 m) of steel cable and...
- Page 8 ORDERING ACCESSORIES..02/13 We recommend that you purchase accessory items from your local storage building dealer whenever possible; however, because the full line of accessories is not always available from all dealers, Arrow is o ering them to you on a direct basis. There are two ways to order Arrow Storage Building Accessories: Option 1 Option 2...
- Page 9 Base ABX09 The Base For Your Building OPTION 1: Wood Platform If you decide to build your own base, be sure to select the appropriate materials. These are the recommended materials for your base: 2 x 4's (38 mm x 89 mm) Pressure Treated Lumber 5/8"...
- Page 10 Anchoring Anchoring Down The Building It is important that the entire oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
- Page 11 Hardware ABX11 Remove from bag of screws and save for the last step 65900A 65923 #10Bx1/2" (13 mm) 65004 #8-32x3/8" (10 mm) 65103 Black Screw (8) #8Ax5/16" (8 mm) #8-32 Hex Nut (62) Bolt (62) (Packed with Screws) Screw (234) 66646 66775 65109...
- Page 12 Parts List ABX12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 10566 Rear Wall Angle 6617 Door Track Splice 10498 Horizontal Door Brace 10573 Front Header 10557 Roof Panel 10562 Right Gable 80015 Left Gable 9316 Right Roof Trim 10560 Right Roof Panel...
- Page 13 Assembly by Key No. ABX13...
- Page 14 Step 1 8941 Ramp (1) Parts Needed For 9379 Front Floor Frame (2) Floor Frame Assemblies 9377 Rear Floor Frame (2) B14 ctr 9379 The front oor frame is made up of 8941 three pieces. The rear oor frame is made up of two pieces.
- Page 15 Step 2 Parts Needed For 10566 Rear Wall Angle (2) Frame Assemblies 9924 Rear Wall Channel (2) ABX15 Rear Wall Channel 94 5/8" 240,3 cm 9924 The main frame pieces reinforce 9924 the walls. These pieces will later be installed in the center and at the top edge of the rear wall.
- Page 16 Step 3 Parts Needed For 10570 Roof Beam (2) Roof Beam Assemblies ABX16 The roof beams support the roof 10570 panels. The roof beam is made up of two pieces overlapped at the center. 10570 Hint: These pieces are force-fitted, 96 3/8"...
- Page 17 Parts Needed For Step 4 6617 Door Track Splice (1) Door Track / Header 9378 Door Track (2) ABX17 10573 Header (2) Assembly NOTE: Door Track Splice (painted part) (16) The door track/header assembly 6617 supports the sliding doors and rein- forces the front wall.
- Page 18 Step 5 Front Floor Assembly (1) Parts Needed For 10544 Side Floor Frame (2) Floor Frame Rear Floor Assembly (1) ABX18 RIGHT REAR 10544 STEP 10544 9377 Assemble the four corners of the oor frame using two screws at each corner as shown.
- Page 19 Step 6 Parts Needed For 9381 Front Corner Panel (2) Corners 9385 Rear Corner Panel (2) ABX19 Wide Side (14) 9385 Narrow Side NOTE STEP The remainder of the building assembly REAR requires many hours and more than one 9385 person.
- Page 20 Rear Wall Angle Assembly (1) Step 7 Parts Needed For Rear Wall Channel Assembly (1) 10545 Side Wall Channel (2) Frames 10564 Side Wall Angle (2) Door Track/Header Assembly (1) ABX20 STEP (24) The main frame pieces give rigidity to Side Wall Angles the side walls and provide a surface 13/16"...
- Page 21 Step 8 Parts Needed For 6243 Wall Panel (2) Wall Panels 10563 Wall Panel (4) ABX21 Fasten the wall panels at the top and bottom with screws. (84) Fasten the center of each panel to the wall channel with screws. The wall panels come in two widths.
- Page 22 Step 9 Parts Needed For 9369 Door Jamb (2) Door Jamb ABX22 STEP (3) bolts TOP VIEW Door Track Hex Nut Acorn Nut Plug The door jambs reinforce the door 9369 opening and provide an attractive Bolt trim. Follow these steps for both door jambs.
- Page 23 Step 10 Parts Needed For Roof Beam Assembly (1) Roof Beam ABX23 The dimension stated below measures from the end of the angle towards the front of the building. Fasten the roof beam assembly, small holes on top, to the side wall angle with a bolt and nut.
- Page 24 Step 11 Parts Needed For 10560 Right Roof Panel (1) Right/Left Roof Panels 80013 Left Roof Panel (1) ABX24 Position a right roof panel at the right side and fasten to the header, roof beam and rear wall angle using screws as shown.
- Page 25 Step 12 Parts Needed For 10557 Roof Panel (3) Roof Panel ABX25 Screws To Rear Wall Angle (36) Install the roof panels 10557, in the positions shown. Fasten middle Fasten At of rib overlap with a bolt and nut. Overlap With Bolt NOTE Narrow roof panel crimped rib is...
- Page 26 Step 13 Parts Needed For 10562 Right Gable (1) Gables 80015 Left Gable (1) ABX26 Fasten to the right roof panel, side wall angle and front header using screws, bolts and nuts as shown. (10) Repeat steps 1 and 2 for the left Position the right gable at the gable.
- Page 27 Step 14 Parts Needed For 9316 Right Roof Trim (2) Roof Trim 80017 Left Roof Trim (2) ABX27 Using your thumb and index nger, overbend the bottom ange of the roof trim at the corner inward enough so the right and left roof trim caps t onto right and left corners.
- Page 28 Step 15 Parts Needed For 10478 Right and Left Doors (2) 10498 Horizontal Door Brace (4) Door Assembly 6278 Vertical Door Brace (2) ABX28 (12) 66045 10498 6278 66045 10498 The steps on this page tell how to 6278 assemble the right door. You will perform exactly the same procedures for the left door.
- Page 29 Step 16 Parts Needed For Right Door Assembly (1) Door Installation & Adjustment Left Door Assembly (1) ABX29 Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the building) behind door jamb into the front frame track.
- Page 30 NOTES GZ46...
- Page 31 NOTES GZ46...
- Page 32 EP84 PT84 PT84EU PTG84 PTG84EU EPA84 CJ32 Anchoring Anchor your building at this time. SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
