Owner's Manual & Assembly Instructions
CY01
Model No. EN108 A
709290218
Storage Area: 74 Sq. Ft. 401 Cu. Ft.
6,9 m
2
BUILDING DIMENSIONS * Size rounded o to the nearest foot
*Approx.
Size
10' x 8'
121" x 92 3/4"
3,0 m x 2,3 m
307,3 cm x 235,6 cm
NP108
VN108 A
EN108G
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
11,4 m
3
Exterior Dimensions
Base
(Roof Edge to Roof Edge)
Size
Width
123 1/4"
313,1 cm
HM108 A
PD108 A
697.68538 A
EN108GEU
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Depth
Height
Width
95 1/4"
70 7/8"
118 1/4"
241,9 cm
180,0 cm
300,4 cm 228,6 cm 176,8 cm
MN108 A
SA108 A
697.68704 A
HM108FB A
697.76084
Interior Dimensions
(Wall to Wall)
Depth
Height
90"
69 5/8"
Door
Opening
Width
Height
55 1/2"
58"
141,0 cm
147,3 cm
