Daikin VISTA FXZQ TBVJU Engineering Data

2 × 2 cassette unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EDUS392209-F9
202202
Engineering Data
VISTA™ 2 × 2 Cassette Unit
FXZQ_TBVJU
60 Hz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISTA FXZQ TBVJU and is the answer not in the manual?

Questions and answers

Related Manuals for Daikin VISTA FXZQ TBVJU

Summary of Contents for Daikin VISTA FXZQ TBVJU

  • Page 1 EDUS392209-F9 202202 Engineering Data VISTA™ 2 × 2 Cassette Unit FXZQ_TBVJU 60 Hz...

  • Page 3: Table Of Contents

    FXZQ_TBVJU EDUS392209-F9 Table of Contents 1. Features and Benefits ................2 2. Specifications .....................3 3. Simplified Dimensions ................6 4. Dimensions ....................7 4.1 FXZQ_T (with VISTA Decoration Panel BYFQ60C3W2W) ....7 4.2 FXZQ_T (with Legacy Decoration Panel BYFQ60B3W1) ....8 5. Center of Gravity ..................9 6. Piping Diagrams ..................10 7. Wiring Diagrams ..................11 8. Electric Characteristics ................13 9. Safety Devices Setting ................14 10. C apacity Tables ..................15 10.1 Cooling Capacity at Te: 43°F (6°C) ..........15 10.2 Heating Capacity ................15 10.3 Correction Factor for Cooling Capacity at Te: 48°F (9°C) ....16...

  • Page 4: Features And Benefits

    FXZQ_TBVJU EDUS392209-F9 1. Features and Benefits The VISTA™ 2 × 2 Cassette Unit for VRV systems seamlessly integrates into 2 × 2 ceiling grids with a remarkable blend of iconic design and engineering excellence. „ Redesigned decoration panel eliminates overlap of adjacent tiles and simplifies coordination „ Low profile panel design measures a mere 5/16” (8 mm) deep „ Incorporation of DC fan motor reduces operational power input up to 48%* „ Independently motorized louvers allow for greater air distribution flexibility „ 4-way, 3-way, and 2-way blow configurability „ Auto** fan speed control optimizes fan energy input by intelligently controlling fan speed „ Configurable auxiliary heat control allows for a high degree of control of heater on/off temperatures „ Direct integration of outside air „ The decoration panel is available in white (BYFQ60C3W2W) „ Backed by 10 year parts limited warranty*** *When compared vs previous generation FXZQ_MVJU9 **Requires BRC1E73 or iTouch Manager ***Complete warranty details available from your local dealer or at www.daikincomfort.com The decoration panel design allows VISTA to be easily The VISTA decoration panel depth measures a mere placed near lighting or other devices.

  • Page 5: Specifications

    FXZQ_TBVJU EDUS392209-F9 2. Specifications VISTA™ 2 × 2 cassette unit Model FXZQ05TBVJU FXZQ07TBVJU Power supply 1 phase, 60 Hz, 208/230 V 1 phase, 60 Hz, 208/230 V Btu/h 5,800 (1.7) 7,500 (2.2) H1, H3 Cooling capacity (kW) Btu/h 6,500 (1.9) 8,500 (2.5) H2, H3 Heating capacity (kW) Casing Galvanized steel plate Galvanized steel plate Dimensions: (H × W × D) in. (mm) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575) Rows × Stages × FPI 2 × 12 × 22 2 ×...
  • Page 6 FXZQ_TBVJU EDUS392209-F9 VISTA™ 2 × 2 cassette unit Model FXZQ09TBVJU FXZQ12TBVJU Power supply 1 phase, 60 Hz, 208/230 V 1 phase, 60 Hz, 208/230 V Btu/h 9,500 (2.8) 12,000 (3.5) H1, H3 Cooling capacity (kW) Btu/h 10,500 (3.1) 13,500 (4.0) H2, H3 Heating capacity (kW) Casing Galvanized steel plate Galvanized steel plate Dimensions: (H × W × D) in. (mm) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575) Rows × Stages × FPI 2 × 12 × 22 2 × 16 × 22 Coil (cross fin coil) Face area...
  • Page 7 FXZQ_TBVJU EDUS392209-F9 VISTA™ 2 × 2 cassette unit Model FXZQ15TBVJU FXZQ18TBVJU Power supply 1 phase, 60 Hz, 208/230 V 1 phase, 60 Hz, 208/230 V Btu/h 15,000 (4.4) 18,000 (5.3) H1, H3 Cooling capacity (kW) Btu/h 17,000 (5.0) 20,000 (5.9) H2, H3 Heating capacity (kW) Casing Galvanized steel plate Galvanized steel plate Dimensions: (H × W × D) in. (mm) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575) 10-1/4 × 22-5/8 × 22-5/8 (260 × 575 × 575) Rows × Stages × FPI 2 × 16 × 22 3 × 16 × 22 Coil (cross fin coil) Face area...

  • Page 8: Simplified Dimensions

    FXZQ_TBVJU EDUS392209-F9 3. Simplified Dimensions FXZQ05-18TBVJU...

  • Page 9: Dimensions

    FXZQ_TBVJU EDUS392209-F9 4. Dimensions FXZQ_T (with VISTA Decoration Panel BYFQ60C3W2W) FXZQ05-18TBVJU...

  • Page 10: Fxzq_T (With Legacy Decoration Panel Byfq60B3W1)

    FXZQ_TBVJU EDUS392209-F9 FXZQ_T (with Legacy Decoration Panel BYFQ60B3W1) FXZQ05-18TBVJU...

  • Page 11: Center Of Gravity

    FXZQ_TBVJU EDUS392209-F9 5. Center of Gravity FXZQ05-18TBVJU Unit: in. (mm) 4D137350...

  • Page 12: Piping Diagrams

    FXZQ_TBVJU EDUS392209-F9 6. Piping Diagrams FXZQ05-18TBVJU 4D137354 Unit: in. (mm) Model Liquid FXZQ05TBVJU FXZQ07TBVJU FXZQ09TBVJU f1/2 (f12.7) f1/4 (f6.4) FXZQ12TBVJU FXZQ15TBVJU FXZQ18TBVJU...

  • Page 13: Wiring Diagrams

    FXZQ_TBVJU EDUS392209-F9 7. Wiring Diagrams FXZQ05-18TBVJU...
  • Page 14 FXZQ_TBVJU EDUS392209-F9 FXZQ05-18TBVJU INDOOR UNIT PRINTED CIRCUIT BOARD (CONTROL) C105 CAPACITOR FUSE FUSE FLASHING LAMP (SERVICE MONITOR GREEN) MOTOR (INDOOR FAN) MOTOR (DRAIN PUMP) M1S · M2S MOTOR (SWING BLADE) M3S · M4S SWITCHING POWER SUPPLY THERMISTOR (AIR) R2T · R3T THERMISTOR (COIL) FLOAT SWITCH DIODE BRIDGE TERMINAL BLOCK TERMINAL BLOCK ELECTRONIC EXPANSION VALVE NOISE FILTER FERRITE CORE FERRITE CORE FERRITE CORE WIRELESS REMOTE CONTROLLER (RECEIVER/DISPLAY UNIT) PRINTED CIRCUIT BOARD PRINTED CIRCUIT BOARD PUSH BUTTON SWITCH (ON/OFF) PILOT LAMP (ON-RED) PILOT LAMP (TIMER-GREEN) PILOT LAMP (FILTER SIGN-RED) PILOT LAMP (DEFROST-ORANGE) SELECTOR SWITCH (MAIN/SUB) SELECTOR SWITCH (WIRELESS ADDRESS SET)

  • Page 15: Electric Characteristics

    FXZQ_TBVJU EDUS392209-F9 8. Electric Characteristics FXZQ05-18TBVJU Power supply Input [W] Model SCCR Voltage Voltage range Cooling Heating FXZQ05TBVJU 0.05 FXZQ07TBVJU 0.05 SCCR kA rms, FXZQ09TBVJU 0.05 Max. 253 V 208/230 V Symmetrical Min. 187 V FXZQ12TBVJU 0.05 @600V MAX:5 FXZQ15TBVJU 0.05 FXZQ18TBVJU 0.05 Symbol: MCA: MINIMUM CIRCUIT AMPACITY (A) MOP: MAXIMUM OVERCURRENT PROTECTIVE DEVICE (A) KW: FAN MOTOR RATED OUTPUT (kW) FLA: FULL LOAD AMPERE (A) IFM: INDOOR FAN MOTOR SCCR: S HORT-CIRCUIT CURRENT RATING Note:...

  • Page 16: Safety Devices Setting

    FXZQ_TBVJU EDUS392209-F9 9. Safety Devices Setting Model FXZQ05TBVJU FXZQ07TBVJU FXZQ09TBVJU FXZQ12TBVJU FXZQ15TBVJU FXZQ18TBVJU Printed circuit board fuse 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A Fan motor thermal fuse °F (°C) – – – – – – Fan motor thermal protector °F (°C) – – – – – – Drain pump fuse °F (°C) – – –...

  • Page 17: Capacity Tables

    FXZQ_TBVJU EDUS392209-F9 10. Capacity Tables 10.1 Cooling Capacity at Te: 43°F (6°C) Indoor air temp. °FWB (°CWB) (Te: 43°F (6°C)) 61 (16.1) 64 (17.8) 67 (19.4) 70 (21.1) 72 (22.2) 75 (23.9) Model FXZQ05TBVJU FXZQ07TBVJU FXZQ09TBVJU 10.2 FXZQ12TBVJU 10.9 12.0 12.5 12.7 13.0 FXZQ15TBVJU 11.9 13.5 10.4 15.0 10.8 15.7 10.4 16.1 10.1 16.3 FXZQ18TBVJU 14.3...

  • Page 18: Correction Factor For Cooling Capacity At Te: 48°F (9°C)

    FXZQ_TBVJU EDUS392209-F9 10.3 Correction Factor for Cooling Capacity at Te: 48°F (9°C) Refer to the correction factor table below when a mini-split indoor unit is connected to a VRV Heat Pump system using a Branch Port box. Indoor air temp. °FWB (°CWB) (Te: 48°F (9°C)) Model 57 (13.9) 61 (16.1) 64 (17.8) 67 (19.4) 70 (21.1) 72 (22.2) 75 (23.9) FXZQ05TBVJU 0.65 1.21 0.72 1.15 0.76 1.12 0.82 1.06 0.84 1.05 0.85 1.04 0.87 1.03 FXZQ07TBVJU 0.65 1.20 0.72 1.15...

  • Page 19: Air Velocity And Temperature Distributions (Reference Data)

    FXZQ_TBVJU EDUS392209-F9 11. Air Velocity and Temperature Distributions (Reference Data) 11.1 Cooling Mode FXZQ05TBVJU <Cooling mode> 4D137361...
  • Page 20 FXZQ_TBVJU EDUS392209-F9 FXZQ07TBVJU <Cooling mode> 4D137362...
  • Page 21 FXZQ_TBVJU EDUS392209-F9 FXZQ09TBVJU <Cooling mode> 4D137363...
  • Page 22 FXZQ_TBVJU EDUS392209-F9 FXZQ12TBVJU <Cooling mode> 4D137364...
  • Page 23 FXZQ_TBVJU EDUS392209-F9 FXZQ15TBVJU <Cooling mode> 4D137365...
  • Page 24 FXZQ_TBVJU EDUS392209-F9 FXZQ18TBVJU <Cooling mode> 4D137366...

  • Page 25: Heating Mode

    FXZQ_TBVJU EDUS392209-F9 11.2 Heating Mode FXZQ05TBVJU <Heating mode> 4D137367...
  • Page 26 FXZQ_TBVJU EDUS392209-F9 FXZQ07TBVJU <Heating mode> 4D137368...
  • Page 27 FXZQ_TBVJU EDUS392209-F9 FXZQ09TBVJU <Heating mode> 4D137369...
  • Page 28 FXZQ_TBVJU EDUS392209-F9 FXZQ12TBVJU <Heating mode> 4D137370...
  • Page 29 FXZQ_TBVJU EDUS392209-F9 FXZQ15TBVJU <Heating mode> 4D137371...
  • Page 30 FXZQ_TBVJU EDUS392209-F9 FXZQ18TBVJU <Heating mode> 4D137372...

  • Page 31: Sound Levels (Reference Data)

    FXZQ_TBVJU EDUS392209-F9 12. Sound Levels (Reference Data) FXZQ05-07TBVJU 3D137355...
  • Page 32 FXZQ_TBVJU EDUS392209-F9 FXZQ09TBVJU 3D137356...
  • Page 33 FXZQ_TBVJU EDUS392209-F9 FXZQ12TBVJU 3D137357...
  • Page 34 FXZQ_TBVJU EDUS392209-F9 FXZQ15TBVJU 3D137358...
  • Page 35 FXZQ_TBVJU EDUS392209-F9 FXZQ18TBVJU 3D137359...

  • Page 36: Accessories

    FXZQ18TBVJU BYFQ60C3W2W ― Decoration panel ― BYFQ60B3W1 *1 Relay wire harness adaptor for panel ― BER01A1 Sensor kit BRYQ60AAW ― Panel spacer ― KDBQ44BA60A Sealing member of air discharge outlet BDBHQ44C60 Replacement long life filter KAFQ441BA60 Fresh air intake kit KDDQ44XA60 Note: *1. This panel requires Relay wire harness adaptor BER01A1 for connection. C: 4D137353 13.2 Optional Accessories (for Controls) Refer to latest Controls Engineering Manual. The latest controls engineering manual is available in Daikin City and can be downloaded using the path below. Document Library  Product Category  VRV  VRV  Engineering Data Manual  “EM-Controls Optional Accessories”...
  • Page 40 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
