- Page 1 Serials BWM410 Voltage Single-Axis Inclinometer Technical Manual...
- Page 2 BWM 410 Voltage Single-Axis Inclinometer Introduction Designed by Bewis Sensing Technology LLC, BWM410 is a cost-effective single-axis inclinometer with MEMS technology and voltage output. It has a measuring range of ± 180° and a full-scale accuracy of 0.05° and a operating temperature of -40℃~+85℃. The product uses a high-accuracy MEMS accelerometer and a high-resolution differential digital-to-analog converter with built-in automatic compensation and filtering algorithms to reduce errors caused by environmental changes.
-
Page 3: Specifications
BWM 410 Voltage Single-Axis Inclinometer Specifications Electrical Specifications Typical Conditions Units Parameters Power supply(DC) Operating current Non-loaded KΩ Output load Resistivity Capacitive Operating ℃ temperature +100 ℃ Store temperature Performance Specifications Units Conditions BWM410 Parameters ° 0~±180 Measuring range Measuring axis °... - Page 4 BWM 410 Voltage Single-Axis Inclinometer Mechanical Characteristic Metal connector（standard cable is 1.5m） Connector Protection level IP67 Magnesium alloy anodizing Shell material Installation Four M4 screws Package size Product Size: L90*W40.5*H26(mm) 4.5 通孔 Bare plate product size Product size: L47*W36*H15(mm) Note: ±1mm error for length and width dimensions, please refer to actual size. 孔Φ...
-
Page 5: Installation Direction
BWM 410 Voltage Single-Axis Inclinometer Installation direction The correct installation method can avoid measurement error. The following points should be made when installing the sensor: First of all, to ensure that the sensor mounting surface and the measured surface completely close, the measured surface should be as horizontal as possible, can not have the angle shown in Figure A and Figure C, the correct installation is shown in Figure B and Figure D. -
Page 6: Electrical Connections
BWM 410 Voltage Single-Axis Inclinometer Electrical connections Electrical interfaces GREEN YELLOW BLACK BROWN GRAY Cable color & Function Output RS232 TXD RS232 RXD U XOUT ground DC 12-35V 12-35V Output GRAY ground GREEN YELLOW U XOUT BROWN BLACK RS232 Electrical interfaces BLUE BLACK GREEN... - Page 7 BWM 410 Voltage Single-Axis Inclinometer Debug software Users can directly download serial assistant on official website (Supports-Download). You can also use more convenient and intuitive PC software. BWM410 supporting serial debugging software can be connected to the inclinometer on the computer for angle display.
- Page 8 BWM 410 Voltage Single-Axis Inclinometer Protocol 1Data Frame Format： （8 data bits，1 stop bit，No parity check，default baud rate 9600） Identifier Frame Length Address Code Command Checksum Data （1byte） （1byte） （1byte） （1byte） (1byte) (nbyte) 0x77 Data Format: Hexadecimal Identifier: Fixed to 77 Frame Length: Length from Frame Length to Checksum（included）...
- Page 9 BWM 410 Voltage Single-Axis Inclinometer 2.3 Set relative / absolute zero Command：77 05 00 05 00 0A Identifier Frame Length Data Address Code Checksum Command （1byte） （1byte） （1byte） （1byte） (1byte) （1byte） 0x00: absolute zero 0x77 0x05 0x00 0x05 0x01: relative zero Command response：...
- Page 10 BWM 410 Voltage Single-Axis Inclinometer 2.6 Set output mode Command：77 05 00 0C 00 11 Identifier Frame Length Address Code Command Data Checksum （1byte） （1byte） （1byte） （1byte） （1byte） （1byte） 0x00: question and answer Mode 0x01: 5Hz Data Rate 0x02: 10Hz Data Rate 0x00 0x0C...
-
Page 11: Ordering Information
BWM 410 Voltage Single-Axis Inclinometer Ordering Information Package condition Product number Way of communication Voltage/R 2 IP67 Package/Metal Connector S 32 BWM410-180-05 IP67 Package/Metal Connector Voltage/R 2 BWM410-180-10 S 32 Executive standard ● Enterprise Quality System Standard: ISO9001:2008 Standard (Certificate No.:10114Q16846ROS) ●... - Page 12 Serials BWM410 Voltage Single-Axis Inclinometer Wuxi Bewis Sensing Technology LLC Address: Building 30, No. 58 Xiuxi Road, Binhu District, Wuxi City Hotline: 400-618-0510 Tel: +86 510 85737178-801 Email: sales@bwsensing.com Website: www.bwsensing.com...
