12-2. Others
Exterior
(×1)
(×1)
507 mm
Part name
(×2)
External control
set
(×2)
Remote sensor
unit
Square flange
Round flange
Long-life filter
Drain pump unit UTZ-PX1NBA
- 35 -
Model name
Use to connect with various
UTD-ECS5A peripheral devices and air conditioner
PCB. (Set of 6)
Thermo-sensor for sensing the
UTY-XSZX temperature of arbitrary place in the
room.
UTD-SF045T
Both the Square flange and the
Round flange can be selected.
Round flange is also used when the
fresh-air duct is installed.
UTD-RF204
Long-life filter can be mounted to the
UTD-LF25NA
indoor unit.
Optional drain lift up mechanism
allows more flexible installation.
Summary
