1. Specifications

Type
Model name
Power supply
Available voltage range
Rated
Cooling
Min.—Max.
Capacity
Rated
Heating
Min.—Max.
Rated
Cooling
Max.
Input power
Rated
Heating
Max.
Cooling
Current Rated
Heating
Cooling
Power factor
Heating
EER Cooling
COP Heating
Moisture removal
Cooling
Maximum operating current *1
Heating
Cooling
Airflow rate
Fan
Heating
Type × Q'ty
Motor output
Static pressure range
Cooling
Sound pressure level *2
Heating
Cooling
Sound power level
Heating
Dimensions (H × W × D)
Fin pitch
Heat exchanger type Rows × Stages
Pipe type
Fin type
Material
Enclosure
Color
Net
Dimensions
(H × W × D) Gross
Net
Weight
Gross
Liquid
Size
Connection pipe Gas
Method
Material
Drain hose
Size
Cooling
Operation range
Heating
Remote controller type
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Standard static pressure: 35 Pa.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum current:
– The maximum value when operated within the operation range.
– The total current of indoor unit and outdoor unit.
• *2: Sound pressure level:
– Measured values in manufacturer's anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
kW
Btu/h
kW
Btu/h
kW
Btu/h
kW
Btu/h
kW
A
%
kW/kW
L/h (pints/h)
A
HIGH
MED
LOW
QUIET
3
m /h
HIGH
MED
LOW
QUIET
W
Pa
HIGH
MED
LOW
QUIET
dB (A)
HIGH
MED
LOW
QUIET
HIGH dB (A)
mm
mm
kg
mm (in)
mm
°C
%RH
°C
- 2 -
Inverter heat pump
ARHG24LMLA
230 V ~ 50 Hz
198—264 V
6.8
23,200
0.9—8.0
3,100—27,300
8.00
27,300
0.90—9.10
3,100—31,000
2.21
2.85
2.26
3.19
9.7
9.9
99.1
99.3
3.08
3.54
2.5 (4.4)
14.7
15.7
1,100
910
750
580
1,100
910
750
580
Sirocco × 2
106
30 to 150
31
29
27
25
31
29
27
25
60
62
294 × 1,000 × 39.9
1.40
3 × 14
Copper
Aluminum
Steel
—
270 × 1,135 × 700
300 × 1,320 × 790
38
44
Ø 6.35 (Ø 1/4 in.)
Ø 15.88 (Ø 5/8 in.)
Flare
Steel
Ø35.7 (I.D.), Ø38.1 (O.D.)
18 to 32
80 or less
16 to 30
Wired [Wireless (option)]
