Wireless Status

The Wireless Status section shows information about the radio settings and
associated clients.

Figure 16: Wireless Status

The following items are displayed in this section:
◆
Radio # — Indicates the 5 GHz or 2.4 GHz wireless interface.
Radio Status — Shows if the wireless interface is enabled or disabled.
■
Op Mode — Shows if the unit is configured to operate as an access point
■
(manually configured), an AP in bridge mode, or an AP in router mode.
Channel — The radio channel the access point uses to communicate with
■
wireless clients. The available channels depend on the 802.11 Mode
Channel Bandwidth
IEEE Mode — The 802.11 wireless LAN standards supported by the access
■
point.
1. See "Radio Settings" on page
"Setup Wizard" on page 15
2. See
– 25 –
Chapter 2
1
, and Country Code settings
37.
.
| Status Information
Wireless Status
1
,
2
.
