Chapter 1
|
Introduction
Main Menu
Main Menu
Figure 7: Route to Internet
Manual Mode — Allows all configuration parameters to be manually
■
configured. Any wired module or radio module may be logically placed on
the WAN and LAN side of the access point.
The web interface Main Menu provides access to all the configuration settings
available for the AP.
To configure settings, click the relevant Main Menu item. Each Main Menu item is
summarized below with links to the relevant section in this guide where the
configuration parameters are described in detail:
◆
Dashboard — The dashboard shows basic settings for the AP, including
Internet status, local network settings, wireless radio status, and traffic graphs.
See
"Status Information" on page
◆
Network — Configures Internet, Ethernet, LAN, and Hotspot settings. See
"Network Settings" on page
◆
Wireless — Configures 5 GHz Radio, 2.4 GHz Radio, and VLAN settings. See
"Wireless Settings" on page 37
◆
System — Configures System (designation and location), Maintenance (such as
view log, firmware upgrade, and reset), User Accounts, and Services
(management access methods).
– 18 –
22.
28.
