ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1
37LA71075
2
TMS24TY-CS04-1
3
47LA04787
4
17C01A0712001Y4
5
17C33A0706001Y4
Attention:
Make sure that each bolt needed for all steps
matches the corresponding figure to ensure proper
assembly.
Step 1:
Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Fasten the legs (#2) to the underside of the table top
(#1) rim by using bolts (#4), washers (#6) and plastic
nuts (#7). Keep the bolts loose. See Figure 1.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
!
Do not sit or stand on this table.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
TMS24TY-
PART
Q'TY
1
TABLE TOP
4
LEG
1
CENTER CONNECTOR
4
BOLT M6*35
4
BOLT M6*16
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
STOP
DON'T RETURN TO STORE!
PAGE 1 OF 2
WM
6
17FA05040301-Y4
7
18000C23001
8
18000337001
18000337004
9
10
17KAA0101----Y4
11
17KAB1101----Y4
FIGURE 2
7
6
35
COURTYARD CREATIONS INC.
WASHER d6.5*D13*1.0
PLASTIC NUT M6*P1.0
BOLT CAP M6
BOLT CAP
HEX.KEY WRENCH 4MM
NUT WRENCH 10&13MM
2
2
2
4
1
8
#4 BOLT M6*35
12
4
4
4
1
1
2
