Courtyard Creations TMS38LW Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
TMS38LW-CS05-1
2
TMS38LW-CS04-1

Step 1:

Place the table top (#1) onto a non-abrasive surface, such
as a carpet, with its underside facing upwards. Fasten the
legs (#2) to the underside of the table top (#1) rim by
using bolts (#3). Make sure that all of the bolts have been
tightened completely.
! Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely assembled.
Do not sit or stand on this table.
!
A weighted umbrella base must be used when using an umbrella with this table.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
!
required.
! Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
V-3
INTENDED FOR RESIDENTIAL USE ONLY.
PART
TABLE TOP
LEG
See Figure 1.
SERVICE CENTER TOLL FREE NO.
DON'T RETURN TO STORE!
STOP
TMS38LW
3
Q'TY
1
4
5
4

FIGURE 1

2
TEL: 1-877-539-7436
FAX: 1-877-539-7439
PAGE 1 OF 2
17C40A0705001YX
BOLT M6*15
17KAA0101----Y4
HEX. KEY WRENCH 4MM
17KAC3101----Y3
HEX. KEY WRENCH 10MM
3
3
2
2
1
